Introduction
About This Manual...........................................7
Symbols Glossary
.............................................7
Data Recording
..................................................9
California Proposition 65..............................11
Perchlorate.........................................................11
Ford Credit
..........................................................11
Replacement Parts Recommendation
........................................11
Special Notices................................................12
Mobile Communications Equipment.....................................................12
Export Unique Options
..................................12
Child Safety
General Information
.......................................13
Installing Child Seats
.....................................14
Booster Seats
..................................................20
Child Seat Positioning...................................22
Child Safety Locks
.........................................24
Safety Belts
Principle of Operation..................................26
Fastening the Safety Belts..........................27
Safety Belt Height Adjustment
.................29
Safety Belt Warning Lamp and Indicator Chime.............................................................30
Safety Belt Minder.........................................30
Child Restraint and Safety Belt Maintenance................................................32
Personal Safety System ™
Personal Safety System ™
..........................33
Supplementary Restraints System
Principle of Operation..................................34
Driver and Passenger Airbags....................35
Front Passenger Sensing System............36
Side Airbags
.....................................................38 Driver Knee Airbag
.........................................39
Side Curtain Airbags
.....................................39
Crash Sensors and Airbag Indicator
.........41
Airbag Disposal................................................41
Keys and Remote Controls
General Information on Radio Frequencies..................................................42
Remote Control
..............................................42
Replacing a Lost Key or Remote Control...........................................................46
MyKey ™
Principle of Operation...................................47
Creating a MyKey
............................................47
Clearing All MyKeys.......................................48
Checking MyKey System Status..............49
Using MyKey With Remote Start Systems.........................................................49
MyKey Troubleshooting...............................49
Locks
Locking and Unlocking
..................................51
Manual Liftgate
...............................................54
Keyless Entry....................................................55
Interior Luggage Compartment Release...........................................................57
Security
Passive Anti-Theft System
........................58
Anti-Theft Alarm
............................................59
Steering Wheel
Adjusting the Steering Wheel....................61
Audio Control....................................................61
Voice Control...................................................62
Cruise Control
..................................................62
Wipers and Washers
Windshield Wipers.........................................63
1
Fiesta (CCT), enUSA, Second Printing Table of Contents
Page 31 of 423
Pregnant women should always wear their
safety belt. The lap belt portion of a
combination lap and shoulder belt should
be positioned low across the hips below
the belly and worn as tight as comfort will
allow. The shoulder belt should be
positioned to cross the middle of the
shoulder and the center of the chest.
Safety Belt Locking Modes
WARNINGS
After any vehicle crash, the safety
belt system at all passenger seating
positions must be checked by an
authorized dealer to verify that the
automatic locking retractor feature for
child seats is still functioning properly. In
addition, all safety belts should be checked
for proper function. Belt and retractor assembly must be
replaced if the safety belt assembly
automatic locking retractor feature
or any other safety belt function is not
operating properly when checked by an
authorized dealer. Failure to replace the
belt and retractor assembly could increase
the risk of injury in crashes. All safety restraints in the vehicle are
combination lap and shoulder belts. The
driver safety belt has the first type of
locking mode, and the front outboard
passenger and rear seat safety belts have
both types of locking modes described as
follows:
Vehicle Sensitive Mode
This is the normal retractor mode, which
allows free shoulder belt length
adjustment to your movements and
locking in response to vehicle movement.
For example, if the driver brakes suddenly
or turns a corner sharply, or the vehicle
receives an impact of about 5 mph
(8 km/h) or more, the combination safety
belts will lock to help reduce forward
movement of the driver and passengers.
In addition, the retractor is designed to lock
if the webbing is pulled out too quickly. If
this occurs, let the belt retract slightly and
pull webbing out again in a slow and
controlled manner.
Automatic Locking Mode
In this mode, the shoulder belt is
automatically pre-locked. The belt will still
retract to remove any slack in the shoulder
belt. The automatic locking mode is not
available on the driver safety belt.
When to Use the Automatic Locking
Mode
This mode should be used any time a child
safety seat, except a booster, is installed
in passenger front or rear seating positions.
Children 12 years old and under should be
properly restrained in a rear seating
position whenever possible. See
Child
Safety (page 13).
28
Fiesta (CCT), enUSA, Second Printing Safety BeltsE142590
Page 38 of 423
DRIVER AND PASSENGER
AIRBAGS
WARNINGS
Never place your arm or any objects
over an airbag module. Placing your
arm over a deploying airbag can
result in serious arm fractures or other
injuries. Objects placed on or over the
airbag inflation area may cause those
objects to be propelled by the airbag into
your face and torso causing serious injury. Airbags can kill or injure a child in a
child seat. Never place a rear-facing
child seat in front of an active airbag.
If you must use a forward-facing child seat
in the front seat, move the seat upon which
the child seat is installed all the way back. The driver and front passenger airbags will
deploy during significant frontal and near
frontal crashes.
The driver and passenger front airbag
system consists of:
•
Driver and passenger airbag modules.
• Front passenger sensing system. · Crash sensors and monitoring
system with readiness indicator.
See Crash Sensors and Airbag
Indicator (page 41). Proper Driver and Front Passenger
Seating Adjustment WARNING
National Highway Traffic Safety
Administration (NHTSA)
recommends a minimum distance
of at least 10 inches (25 centimeters)
between an occupant’ s chest and the
driver airbag module. To properly position yourself away from
the airbag:
•
Move your seat to the rear as far as you
can while still reaching the pedals
comfortably.
• Recline the seat slightly (one or two
degrees) from the upright position.
After all occupants have adjusted their
seats and put on safety belts, it is very
important that they continue to sit
properly. A properly seated occupant sits
upright, leaning against the seat back, and
centered on the seat cushion, with their
feet comfortably extended on the floor.
Sitting improperly can increase the chance
of injury in a crash event. For example, if
an occupant slouches, lies down, turns
sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the
chance of injury during a crash is greatly
increased.
Children and Airbags WARNING
Airbags can kill or injure a child in a
child seat. Never place a rear-facing
child seat in front of an active airbag.
If you must use a forward-facing child seat
in the front seat, move the seat upon which
the child seat is installed all the way back. 35
Fiesta (CCT), enUSA, Second Printing Supplementary Restraints SystemE151127
Page 109 of 423
Adjusting the Height of the Driver
Seat
Recline Adjustment
REAR SEATS
Folding the Seatback
WARNING
When folding the seatback down,
take care not to get your hands
caught between the seatback and
the frame, catches or mechanism. Failure
to take care may result in personal injury. Note:
Fully lower the head restraints. Your
vehicle may have folding rear head
restraints. Fold these before you fold the
seatback. See Head Restraints (page 103). 1. Press the unlock buttons down and
hold them there.
2. Push the seatback forward.
106
Fiesta (CCT), enUSA, Second Printing SeatsE70730 E70731 E156656
2
11
Page 416 of 423
Creating a MyKey............................................47
Programming or Changing Configurable
Settings............................................................... 48
Cruise Control..................................................62
Principle of Operation....................................... 139
Cruise control See: Using Cruise Control................................ 139
Cup Holders.....................................................110
Customer Assistance..................................162
D
Data Recording
..................................................9
Event Data Recording........................................... 9
Service Data Recording........................................ 9
Daytime Running Lamps.............................67
Digital Radio...................................................257 HD Radio Reception and Station
Troubleshooting............................................ 258
Direction Indicators
.......................................68
Driver and Passenger Airbags....................35 Children and Airbags........................................... 35
Proper Driver and Front Passenger Seating Adjustment........................................................ 35
Driver Knee Airbag.........................................39
Driving Aids......................................................141
Driving Hints
...................................................154
Driving Through Water................................155
DRL See: Daytime Running Lamps......................... 67
E
Economical Driving......................................154
Emission Control System...........................119 On-Board Diagnostics (OBD-II)................... 120
Readiness for Inspection/Maintenance (I/M) Testing..................................................... 121
End User License Agreement..................379 SYNC End User License Agreement
(EULA).............................................................. 379
Engine Block Heater
.....................................114
Using the Engine Block Heater....................... 115
Engine Coolant Check................................183 Adding Engine Coolant.................................... 184
Checking the Engine Coolant......................... 183
Recycled Engine Coolant................................. 185
Severe Climates.................................................. 185Engine Immobilizer
See: Passive Anti-Theft System..................... 58
Engine Oil Check...........................................182 Adding Engine Oil............................................... 183
Engine Oil Dipstick - 1.0L EcoBoost™..................................................182
Engine Oil Dipstick - 1.6L Duratec-16V Ti-VCT (Sigma)
..........................................182
Engine Oil Dipstick - 1.6L EcoBoost™..................................................182
Engine Specifications
..................................241
Drivebelt Routing................................................ 241
Entertainment...............................................327 AM/FM Radio...................................................... 328
Bluetooth Audio................................................. 344
Browsing Device Content................................ 327
CD........................................................................\
.... 338
SD Card Slot and USB Port........................... 339
SIRIUS® Satellite Radio (If Activated)........................................................ 333
Supported Media Players, Formats and Metadata Information................................ 344
Event Data Recording See: Data Recording.............................................. 9
Export Unique Options
..................................12
Extended Service Plan (ESP).................394 SERVICE PLANS (CANADA ONLY)............395
SERVICE PLANS (U.S. Only)......................... 394
Exterior Mirrors
.................................................72
Fold-Away Exterior Mirrors................................ 73
Integrated Blind Spot Mirrors........................... 73
Power Exterior Mirrors......................................... 72
F
Fastening the Safety Belts..........................27 Safety Belt Extension Assembly.................... 29
Safety Belt Locking Modes............................... 28
Using Safety Belts During Pregnancy...........27
Floor Mats
........................................................155
Fog Lamps - Front See: Front Fog Lamps......................................... 67
Ford Credit
..........................................................11
(U.S. Only)................................................................. 11
Front Fog Lamps............................................67
Front Passenger Sensing System............36
Fuel and Refueling........................................116
413
Fiesta (CCT), enUSA, Second Printing Index
Page 419 of 423
Manual Seats.................................................105
Adjusting the Height of the Driver
Seat.................................................................... 106
Adjusting the Lumbar Support..................... 105
Moving the Seat Backward and Forward............................................................. 105
Recline Adjustment........................................... 106
Manual Transmission - 1.6L Duratec-16V Ti-VCT (Sigma)/1.0L EcoBoost™.......122
Parking Your Vehicle.......................................... 123
Recommended Shift Speeds......................... 122
Reverse.................................................................... 122
Using the Clutch.................................................. 122
Manual Transmission - 1.6L EcoBoost™..................................................123
Parking Your Vehicle.......................................... 124
Recommended Shift Speeds......................... 123
Reverse................................................................... 124
Using the Clutch.................................................. 123
Media Hub......................................................263
Message Center See: Information Displays................................. 83
Mirrors See: Heated Windows and Mirrors...............101
See: Windows and Mirrors................................ 70
Mobile Communications Equipment
.......12
Moonroof...........................................................74 Moonroof Sliding Shade.................................... 74
Opening and Closing the Moonroof..............74
Venting the Moonroof......................................... 74
Motorcraft Parts
...........................................242
MyFord Touch ™..........................................306
General Information......................................... 306
MyFord Touch ™ Troubleshooting
.........370
MyKey Troubleshooting...............................49
MyKey ™.............................................................47
Principle of Operation......................................... 47N
Navigation......................................................362
cityseekr................................................................ 363
Map Mode............................................................ 366
Navigation Map Updates............................... 368
Navigation Voice Commands....................... 368
Point of Interest (POI) Categories..............363
Quick-touch Buttons....................................... 368
Setting a Destination....................................... 362
Setting Your Navigation Preferences.........365
Normal Scheduled Maintenance..........399
O
Oil Change Indicator Reset
.......................183
Resetting the Oil Life Monitoring
System............................................................... 183
Oil Check See: Engine Oil Check....................................... 182
Opening and Closing the Hood
................177
Closing the Hood................................................ 178
Opening the Hood............................................... 177
Ordering Additional Owner's Literature......................................................166
Obtaining a French Owner ’s Manual..........166
P
Parking Aid
......................................................135
Rear Sensing System........................................ 136
Parking Aids....................................................135 Principle of Operation....................................... 135
Parking Brake
..................................................131
All Vehicles............................................................. 131
Vehicles With Automatic Transmission.................................................... 131
Vehicles With Manual Transmission............131
Passive Anti-Theft System
........................58
SecuriLock®........................................................... 58
PATS See: Passive Anti-Theft System..................... 58
Perchlorate.........................................................11
Personalized Settings
...................................87
Measure Units........................................................ 87
Switching Chimes Off......................................... 87
416
Fiesta (CCT), enUSA, Second Printing Index
Page 420 of 423
Personal Safety System
™..........................33
How Does the Personal Safety System
Work?................................................................... 33
Phone...............................................................345 Making Calls......................................................... 347
Pairing Subsequent Cell Phones.................346
Pairing Your Cell Phone for the First Time.................................................................. 346
Phone Menu Options....................................... 348
Phone Settings................................................... 350
Phone Voice Commands................................. 351
Receiving Calls.................................................... 347
Text Messaging................................................... 349
Power Door Locks See: Locking and Unlocking.............................. 51
Power Steering Fluid Check.....................186
Power Windows
..............................................70
Accessory Delay..................................................... 71
Bounce-Back......................................................... 70
One-Touch Down................................................. 70
One-Touch Up....................................................... 70
Window Lock......................................................... 70
R
Rear Seats.......................................................106 Folding the Seatback....................................... 106
Unfolding the Seatback................................... 107
Rear Under Floor Storage..........................142 Adjustable Load Floor....................................... 142
Rear View Camera........................................137 Turning the Rear View Camera Off..............138
Turning the Rear View Camera On...............137
Using the Display................................................. 137
Rear View Camera See: Rear View Camera.................................... 137
Rear Window Wiper and Washers..........64 Intermittent Wipe................................................ 64
Rear Window Washer......................................... 64
Reverse Gear Wipe.............................................. 64
Refueling...........................................................117 Easy Fuel ™ Capless Fuel System.................118 Remote Control
..............................................42
Car Finder................................................................ 46
Integrated Keyhead Transmitter..................... 42
Intelligent Access Transmitter........................ 43
Replacing the Battery......................................... 43
Reprogramming the Unlocking Function.............................................................. 43
Sounding a Panic Alarm.................................... 46
Removing a Headlamp..............................188
Repairing Minor Paint Damage................214
Replacement Parts Recommendation.........................................11
Collision Repairs..................................................... 11
Scheduled Maintenance and Mechanical Repairs................................................................... 11
Warranty on Replacement Parts..................... 12
Replacing a Lost Key or Remote Control............................................................46
Reporting Safety Defects (Canada Only)...............................................................167
Reporting Safety Defects (U.S. Only)..............................................................166
Roadside Assistance
...................................157
Vehicles Sold in Canada: Getting Roadside
Assistance......................................................... 157
Vehicles Sold in Canada: Using Roadside Assistance......................................................... 157
Vehicles Sold in the United States: Getting Roadside Assistance..................................... 157
Vehicles Sold in the United States: Using Roadside Assistance..................................... 157
Roadside Emergencies...............................157
Running-In See: Breaking-In.................................................. 154
S
Safety Belt Height Adjustment.................29
Safety Belt Minder.........................................30 Belt-Minder™........................................................ 30
Safety Belts......................................................26 Principle of Operation........................................ 26
Safety Belt Warning Lamp and Indicator Chime..............................................................30
Conditions of operation..................................... 30
Safety Precautions
.......................................116
417
Fiesta (CCT), enUSA, Second Printing Index
