UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
!INSTRUMENT PANEL FEATURES..........142
!INSTRUMENT CLUSTER.................143
!INSTRUMENT CLUSTER DESCRIPTIONS.....144
!DRIVER INFORMATION DISPLAY (DID).....156
▫DID Display.........................158
▫Driver Information Display (DID) Messages . . .161
▫DID Yellow Telltales....................162
▫DID Red Telltales......................163
▫DID Green Telltales....................165
▫Driver Information Display (DID) Selectable
Menu Items..........................165
!Uconnect® SETTINGS....................174
▫Buttons On the Faceplate................175
▫Buttons On The Touchscreen..............175
▫Customer Programmable Features/Personal
Settings — Uconnect® 8.4 System Settings . . . .175
▫SRT Performance Pages.................189
!Uconnect® RADIOS — IF EQUIPPED........193
!iPod®/USB/MP3 CONTROL — IF EQUIPPED . .194
4

NOTE:Leaving the hazard flashers on for extended
periods will wear down the battery.
5. Electronic Stability Control (ESC) Activation/
Malfunction Indicator Light — If Equipped
The “ESC Activation/Malfunction Indicator
Light” in the instrument cluster will come on
when the ignition is cycled to the ON/RUN
position. It should go out with the engine
running. If the “ESC Activation/Malfunction Indicator
Light” comes on continuously with the engine running, a
malfunction has been detected in the ESC system. If this
light remains on after several ignition cycles, and the
vehicle has been driven several miles (kilometers) at
speeds greater than 30 mph (48 km/h), see your autho-
rized dealer as soon as possible to have the problem
diagnosed and corrected.
NOTE:
•The “ESC Off Indicator Light” and the “ESC
Activation/Malfunction Indicator Light” come on
momentarily each time the ignition is cycled to
ON/RUN.
•Each time the ignition is cycled to ON/RUN, the
ESC system will be ON, even if it was turned off
previously.
•The ESC system will make buzzing or clicking
sounds when it is active. This is normal; the sounds
will stop when ESC becomes inactive following the
maneuver that caused the ESC activation.
6. Driver Information Display (DID) Menu Set (Select-
able ICONS)
The DID displays are located in the center portion of the
cluster and consists of eight section:
•Speedometer (Digital or Analog) (km/h or mph)
4
UNDERSTANDING YOUR INSTRUMENT PANEL 145

•Main Screen — The inner ring of the display will
illuminate in gray under normal conditions, yellow
for non critical warning, red for critical warnings and
white for on demand information.
•Selectable Information (Compass, Temp, Range, to
Empty, Trip A, TripB–ifequipped, Average MPG)
•Menu Titles / Odometer
•U.S. Federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser
the correct mileage that the vehicle has been driven.
If your odometer needs to be repaired or serviced,
the repair technician should leave the odometer
reading the same as it was before the repair or
service. If s/he cannot do so, then the odometer must
be set at zero, and a sticker must be placed in the
door jamb stating what the mileage was before the
repair or service. It is a good idea for you to make a
record of the odometer reading before the repair/
service, so that you can be sure that it is properly
reset, or that the door jamb sticker is accurate if the
odometer must be reset at zero
•Menu Set (Selectable Icons)
•Reconfigurable Telltales
•Audio / Phone Information
•Sub-menu Current Position — Whenever there are
sub-menus available, the position within the sub-
menus is here
Refer to Driver Information Display (DID) in this section
for further information.
7. Brake Warning Light
This light monitors various brake functions,
including brake fluid level and parking brake
application. If the brake light turns on, it may
146 UNDERSTANDING YOUR INSTRUMENT PANEL

15. Electronic Speed Control Indicator Lights
•Electronic Speed Control ON Indicator
This light will turn on when the electronic
speed control is ON. Refer to “Electronic
Speed Control” in “Understanding The
Features Of Your Vehicle” for further
information.
•Electronic Speed Control SET Indicator
This light will turn on when the electronic
speed control is SET. Refer to “Electronic
Speed Control” in “Understanding The
Features Of Your Vehicle” for further infor-
mation.
16. Cruise Speed Set Value
Speed value shown when set.
17. DID Amber Telltale Lights
When the appropriate conditions exist, the following DID
Amber Telltale Lights will display:
•Windshield Washer Fluid Low Indicator — If
Equipped
This light will turn on to indicate the wind-
shield washer fluid is low.
•Low Fuel Light
When the fuel level reaches approximately 3.0
gal (11.0 L), this light will turn on and remain
on until fuel is added.
152 UNDERSTANDING YOUR INSTRUMENT PANEL

18. DID Red Telltale Lights
When the appropriate conditions exist, the following DID
Red Telltale Lights will display:
•Engine Temperature
This telltale warns of an overheated engine
condition. As temperatures rise and the gauge
approachesH, or 260°F, this telltale will illu-
minate, and a single chime will sound after reaching
a set threshold. Further overheating will cause the
temperature gauge to passH, or 260°F.A continuous
chime will occur until the engine is allowed to cool.
If the telltale turns on while driving, safely pull over
and stop the vehicle. If the A/C system is on, turn it
off. Also, shift the transmission into NEUTRAL and
idle the vehicle. If the temperature reading does not
return to normal, turn the engine off immediately and
call for service. Refer to “If Your Engine Overheats” in
“What To Do In Emergencies” for more information.
•Charging System
This telltale shows the status of the electrical
charging system. If the telltale stays on or
comes on while driving, turn off some of the vehicles
non-essential electrical devices or increase engine
speed (if at idle). If the charging system telltale
remains on, it means that the vehicle is experiencing
a problem with the charging system. Obtain SERVICE
IMMEDIATELY. See an authorized dealer.
Refer to “Jump Starting Procedures” in “What To Do
In Emergencies” if jump starting is required.
•Oil Pressure Warning
This telltale indicates low engine oil pressure.
If the light turns on while driving, stop the
vehicle and shut off the engine as soon as possible. A
chime will sound for four minutes when this light
turns on.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 153

DRIVER INFORMATION DISPLAY (DID)
The Driver Information Display (DID) features a driver-
interactive display that is located in the instrument
cluster.
This system allows the driver to select a variety of useful
information by pushing the switches mounted on the
steering wheel. The DID consists of the following:
•Tachometer
•MPH/KMH
•Vehicle Information
•Fuel Economy
•Trip A
•Trip B
•Audio
•Stored Messages
•Screen Setup
•Performance
•Diagnostics
•Hibernation
Driver Information Display (DID)
156 UNDERSTANDING YOUR INSTRUMENT PANEL

The system allows the driver to select information by
pushing the following buttons mounted on the steering
wheel:
•UP Arrow Button
Push and release the UP arrow button to scroll
upward through the main menu and sub-
menus (Fuel Economy, Trip A, Trip B, Audio,
Stored Messages, Screen Set Up).
•DOWN Arrow Button
Push and release the DOWN arrow button to
scroll downward through the main menu and
submenus (Fuel Economy, Trip A, Trip B, Au-
dio, Stored Messages, Screen Set Up).
•RIGHT Arrow Button
Push and release the RIGHT arrow button to
access/select the information screens or sub-
menu screens of a main menu item. Push and
hold the RIGHT arrow button for two seconds
to reset displayed/selected features that can be reset.
DID Steering Wheels Controls
4
UNDERSTANDING YOUR INSTRUMENT PANEL 157

•LEFT Arrow Button
Push and release the LEFT arrow button to
return to the main menu from an info screen or
submenu item.
NOTE:Pushing the LEFT arrow button will override the
DID “pop up” messages and return you to the menu
screen.
DID Display
DID Display
