2015 DODGE JOURNEY headlamp

▫Brake System........................567
▫Automatic Transmission................570
▫Rear Drive Assembly (RDA) –
AWD Models Only....................574
▫Power Transfer Unit (PTU) –
AWD Models Only....................574
▫Appearance Care And Protection From
Corrosion...........................575
▫Cleaning The Cupholders...............581
!FUSES..............................581
▫Interior Fuses........................582
▫Underhood Fuses (Power Distribution Center) . .585
!REPLACEMENT BULBS.................589
!BULB REPLACEMENT..................591
▫Front Low/High Beam Headlamp, Turn
Signal/Park Lamp, And Side Marker Lamp . .591
▫Front Fog Lamp......................592
▫Rear Turn Signal And Backup Lamp........593
▫License Plate Lamp....................596
!FLUID CAPACITIES....................597
!FLUIDS, LUBRICANTS AND GENUINE
PA R T S . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..598
▫Engine.............................598
▫Chassis............................601
540 MAINTAINING YOUR VEHICLE

Cavity
Car-
tridge
Fuse
Mini-
FuseDescription
F151 30 Amp
Pink
– Headlamp Washer
Motor – If
Equipped
F152 – 25 Amp
Clear
Diesel Fuel Heater
– If Equipped
F153 – 20 Amp
Yellow
Fuel Pump
F156 – 10 Amp
Red
Brake/Electronic
Stability Control
Module
F157 – 10 Amp
Red
Power Transfer
Unit Module – If
Equipped
Cavity
Car-
tridge
Fuse
Mini-
FuseDescription
F158 – 10 Amp
Red
Active Hood Mod-
ule – If Equipped
F159 – 10 Amp
Red
Spare
F160 – 20 Amp
Yellow
Interior Lights
F161 – 20 Amp
Yellow
Horn
F162 40 Amp
Red/20
Amp Lt.
Blue
– Cabin Heater #1/
Vacuum Pump – If
Equipped
F163 50 Amp
Red
– Cabin Heater #2 –
If Equipped
7
MAINTAINING YOUR VEHICLE 587

Exterior Bulbs
Bulb Number
Low Beam Headlamp9006
High Beam Headlamp9005
Front Park/Turn Signal3757AK
Side Marker Lamp168
Front Fog LampPSX24W or 2504
Center High Mounted
Stop Lamp (CHMSL)
LED (Serviced at Autho-
rized Dealer)
License Lamp168
Exterior Bulbs – Rear (LED Version)
Bulb Number
Rear Tail/Stop Lamp LED (Serviced at Autho-
rized Dealer)
Rear Tail (Liftgate) Lamp LED (Serviced at Autho-
rized Dealer)
Rear Turn Signal Lamp WY21W or 7440A
Backup LampW21W or 7440
Exterior Bulbs – Rear (Bulb Version)
Bulb Number
Rear Tail/Stop/Turn Sig-
nal Lamp
P27/7W or 3157
Rear Tail (Liftgate) Lamp P27/7W or 3157
Backup LampP27/7W or 3157
590 MAINTAINING YOUR VEHICLE

BULB REPLACEMENT
NOTE:Lens fogging can occur under certain atmo-
spheric conditions. This will usually clear as atmospheric
conditions change to allow the condensation to change
back into a vapor. Turning the lamps on will usually
accelerate the clearing process.
Front Low/High Beam Headlamp, Turn
Signal/Park Lamp, And Side Marker Lamp
1. Open the hood.
NOTE:It may be necessary to remove the air cleaner
filter housing and position the Totally Integrated Power
Module (TIPM) aside to replace certain lamps in the left
headlamp housing.
2. Rotate the applicable bulb and connector assembly¼
turn counterclockwise and remove the assembly from
the headlamp housing.3. Disconnect the bulb from the harness connector and
then connect the replacement bulb.
1—FrontTurnSignal/ParkLampBulb2—SideMarkerLampBulb3—LowBeamHeadlampBulb4—HighBeamHeadlampBulb
7
MAINTAINING YOUR VEHICLE 591

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean the
bulb with rubbing alcohol.
4. Install the bulb and connector assembly into the
headlamp housing and rotate it¼turn clockwise to
lock it in place.
Front Fog Lamp
NOTE:Turn the steering wheel to the right if replacing
the left front fog lamp or to the left if replacing the right
front fog lamp to allow for easier access to the front of the
wheel well.
1. Remove the fasteners retaining the front lower wheel
well access panel and remove the access panel.
2. Remove the electrical connector from the fog lamp
housing.
3. Squeeze the two tabs on the side of the bulb socket and
pull straight out from the fog lamp.
Front Fog Lamp Electrical Connector
592 MAINTAINING YOUR VEHICLE
