2015 DODGE CHALLENGER SRT mirror controls

Power Mirrors
The power mirror controls are located on the driver-side
door trim panel.The power mirror controls consist of mirror select but-
tons and a four-way mirror control switch. To adjust a
mirror, push either the L (left) or R (right) to select the
mirror that you want to adjust.
NOTE:
A light in the selected button will illuminate
indicating the mirror is activated and can be adjusted.
Folding MirrorsPower Mirror Controls
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

4. AUTO Operation Button
Automatically controls the interior cabin temperature by
adjusting airflow distribution and amount. Performing
this function will cause the system to switch between
manual mode and automatic modes. Refer to “Automatic
Operation” for more information.
5. Front Defrost Button
Press and release to change the current airflow setting to
Defrost mode. The indicator illuminates when this fea-
ture is ON. Air comes from the windshield and side
window demist outlets. When the defrost button is
selected, the blower level will increase. Use Defrost mode
with maximum temperature settings for best windshield
and side window defrosting and defogging. Performing
this function will cause the ATC to switch into manual
mode. If the front defrost mode is turned off the climate
system will return the previous setting.6. Rear Defrost Button
Press and release this button to turn on the rear window
defroster and the heated outside mirrors (if equipped).
An indicator will illuminate when the rear window
defroster is on. The rear window defroster automatically
turns off after 10 minutes.
CAUTION!
Failure to follow these cautions can cause damage to
the heating elements:
•
Use care when washing the inside of the rear
window. Do not use abrasive window cleaners on
the interior surface of the window. Use a soft cloth
and a mild washing solution, wiping parallel to the
heating elements. Labels can be peeled off after
soaking with warm water.
(Continued)
312 UNDERSTANDING YOUR INSTRUMENT PANEL

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust the
inside and outside mirrors, fasten your seat belt, and if
present, instruct all other occupants to buckle their seat
belts.
WARNING!
•When leaving the vehicle, always make sure the
ignition is in the OFF position, remove the Key Fob
from the vehicle, and lock the vehicle.
• Never leave children alone in a vehicle, or with
access to an unlocked vehicle. Leaving children in
a vehicle unattended is dangerous for a number of
reasons. A child or others could be seriously or
fatally injured. Children should be warned not to
touch the parking brake, brake pedal or the trans-
mission gear selector.
(Continued)
WARNING! (Continued)
•Do not leave the Key Fob in or near the vehicle (or
in a location accessible to children), and do not
leave the ignition (of a vehicle equipped with
Keyless Enter-N-Go™) in the ACC or ON/RUN
mode. A child could operate power windows, other
controls, or move the vehicle.
Manual Transmission — If Equipped
Apply the parking brake, place the shift lever in NEU-
TRAL and press the clutch pedal before starting vehicle.
This vehicle is equipped with a clutch interlocking igni-
tion system. It will not start unless the clutch pedal is
pressed to the floor.
Normal Starting With Integrated Key — Manual
Transmission
Normal starting of either a cold or a warm engine does
not require pumping or pressing the accelerator pedal.
5
STARTING AND OPERATING 341

Hood Release........................... .132
Ignition Key..................................12
Illuminated Entry ..........................21
Immobilizer (Sentry Key) ....................16
Information Center, Vehicle ..................230
Inside Rearview Mirror .....................103
Instrument Cluster ..................219, 220, 221
Instrument Panel and Controls ................218
Instrument Panel Lens Cleaning ...............501
Interior Appearance Care ....................500
Interior Lights .......................... .142
Intermittent Wipers (Delay Wipers) .............144
Introduction ..............................4
iPod® Control .......................... .305
iPod®/USB/MP3 Control ...................305
Bluetooth® Streaming Audio ...............305Jump Starting
........................... .451
Key Fob Arm The Alarm .........................19
Lock The Doors .........................23
Panic Alarm ............................24
Programming Additional Key Fobs .........18, 24
Programming Additional Transmitters .......18, 24
Remote Keyless Entry (RKE) ................21
Unlatch The Trunk .......................23
Unlock The Doors .......................22
Key-In Reminder ..........................15
Keyless Enter-N-Go .....................33, 343
Enter The Trunk .........................23
Lock The Vehicle’s Doors ...............23, 263
Passive Entry Programming ................263
Unlock From The Driver’s Side ..............22
Unlock From The Passenger Side .............22
Keyless Entry System .......................21
560 INDEX

Overheating, Engine...................... .438
Owner’s Manual (Operator Manual) ..........4,548
Paint Care ............................. .496
Panic Alarm ..............................24
Parking Brake ........................... .382
ParkSense® System, Rear ....................183
Passing Light ........................... .140
Performance ......................... .240, 274
Pets ....................................89
Placard, Tire and Loading Information ..........404
Power Brakes .............................. .385
Deck Lid Release ........................39
Distribution Center (Fuses) ................508
Door Locks ............................31
Mirrors ..............................110
Outlet (Auxiliary Electrical Outlet) ...........207
Seats ............................... .122Sunroof
............................. .204
Tilt/Telescoping Steering Column ............149
Windows ..............................37
Power Steering Fluid ...................... .525
Pregnant Women and Seat Belts ................50
Pretensioners Seat Belts ..............................50
Programmable Features .....................249
Radial Ply Tires ...........................411
Radiator Cap (Coolant Pressure Cap) ...........489
Radio Operation ......................... .308
Radio Remote Controls .....................307
Radio (Sound Systems) .....................305
Rain Sensitive Wiper System .................146
Rear Camera ........................... .192
Rear Cupholder ..........................211
Rear ParkSense System .....................183
Rear Seat, Folding ........................ .131
564 INDEX
