2015 DODGE CHALLENGER SRT immobilizer

WARNING!(Continued)
•Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build-up may
cause serious injury or death.
CAUTION!
An unlocked car is an invitation to thieves. Always
remove the Key Fob from vehicle, place the ignition
in the OFF position and lock all doors when leaving
the vehicle unattended.
SENTRY KEY®
The Sentry Key® Immobilizer system prevents unauthor-
ized vehicle operation by disabling the engine. The
system does not need to be armed or activated. Operation
is automatic, regardless of whether the vehicle is locked
or unlocked. The system uses a Key Fob with a factory-mated Remote
Keyless Entry (RKE) transmitter, a Keyless Ignition Node
(KIN) and a RF receiver to prevent unauthorized vehicle
operation. Therefore, only Key Fobs that are pro-
grammed to the vehicle can be used to start and operate
the vehicle. The system will not allow the engine to crank
if an invalid Key Fob is used to start and operate the
vehicle. The system will shut the engine off in two
seconds if an invalid Key Fob is used to start the engine.
After placing the ignition to the ON/RUN position, the
Vehicle Security Light will turn on for three seconds for a
bulb check. If the light remains on after the bulb check, it
indicates that there is a problem with the electronics. In
addition, if the light begins to flash after the bulb check,
it indicates that someone used an invalid Key Fob to start
the engine. Either of these conditions will result in the
engine being shut off after two seconds.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

If the Vehicle Security Light turns on during normal
vehicle operation (vehicle running for longer than 10
seconds), it indicates that there is a fault in the electron-
ics. Should this occur, have the vehicle serviced as soon
as possible by an authorized dealer.
CAUTION!
The Sentry Key Immobilizer system is not compat-
ible with some aftermarket remote starting systems.
Use of these systems may result in vehicle starting
problems and loss of security protection.
All of the Key Fobs provided with your new vehicle have
been programmed to the vehicle electronics.
Replacement Keys
NOTE: Only Key Fobs that are programmed to the
vehicle electronics can be used to start and operate the
vehicle. Once a Key Fob is programmed to a vehicle, it
cannot be programmed to any other vehicle.
CAUTION!
• Always remove the Key Fobs from the vehicle and
lock all doors when leaving the vehicle unat-
tended.
• For vehicles equipped with Keyless Enter-N-Go,
always remember to place the ignition in the OFF
position.
Duplication of Key Fobs may be performed at an autho-
rized dealer. This procedure consists of programming a
blank Key Fob to the vehicle electronics. A blank Key Fob
is one that has never been programmed.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17

NOTE:When having the Sentry Key® Immobilizer Sys-
tem serviced, bring all vehicle Key Fobs with you to the
authorized dealer.
Customer Key Programming
Programming Key Fobs or RKE transmitters may be
performed at an authorized dealer.
General Information
The Sentry Key system complies with FCC rules part 15
and with RSS-210 of Industry Canada. Operation is
subject to the following conditions:
• This device may not cause harmful interference.
• This device must accept any interference that may be
received, including interference that may cause unde-
sired operation. NOTE:
Changes or modifications not expressly approved
by the party responsible for compliance could void the
user’s authority to operate the equipment.
VEHICLE SECURITY ALARM
The Vehicle Security Alarm monitors the vehicle doors
and trunk for unauthorized entry and the ignition switch
for unauthorized operation. While the Vehicle Security
Alarm is armed, interior switches for door locks and
decklid release are disabled. If something triggers the
alarm, the Vehicle Security Alarm will provide the fol-
lowing audible and visible signals: the horn will pulse,
the headlights will turn on, park lamps and/or turn
signals will flash, and the Vehicle Security Light in the
instrument cluster will flash.
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Hood Release........................... .132
Ignition Key..................................12
Illuminated Entry ..........................21
Immobilizer (Sentry Key) ....................16
Information Center, Vehicle ..................230
Inside Rearview Mirror .....................103
Instrument Cluster ..................219, 220, 221
Instrument Panel and Controls ................218
Instrument Panel Lens Cleaning ...............501
Interior Appearance Care ....................500
Interior Lights .......................... .142
Intermittent Wipers (Delay Wipers) .............144
Introduction ..............................4
iPod® Control .......................... .305
iPod®/USB/MP3 Control ...................305
Bluetooth® Streaming Audio ...............305Jump Starting
........................... .451
Key Fob Arm The Alarm .........................19
Lock The Doors .........................23
Panic Alarm ............................24
Programming Additional Key Fobs .........18, 24
Programming Additional Transmitters .......18, 24
Remote Keyless Entry (RKE) ................21
Unlatch The Trunk .......................23
Unlock The Doors .......................22
Key-In Reminder ..........................15
Keyless Enter-N-Go .....................33, 343
Enter The Trunk .........................23
Lock The Vehicle’s Doors ...............23, 263
Passive Entry Programming ................263
Unlock From The Driver’s Side ..............22
Unlock From The Passenger Side .............22
Keyless Entry System .......................21
560 INDEX

Keyless Go...............................12
Key, Replacement ..........................17
Keys ...................................12
Key, Sentry (Immobilizer) ....................16
Lane Change and Turn Signals ................139
Lane Change Assist ....................... .140
Lap/Shoulder Belts .........................44
Latches .................................95
Hood ............................... .132
Lead Free Gasoline ....................... .426
Leaks, Fluid ..............................95
Life of Tires ............................ .415
Light Bulbs .......................... .95, 516
Lights .............................. .95, 134
Airbag ...................... .64, 66, 93, 221
Alarm .............................. .221
Anti-Lock ........................ .221, 388
Automatic Headlights ....................135 Brake Assist Warning
....................395
Brake Warning ..................... .221, 385
Bulb Replacement ...................... .519
Center Mounted Stop ....................521
Courtesy/Reading ...................141, 195
Daytime Running ...................... .138
Dimmer Switch, Headlight .............139, 140
Exterior ...............................95
Fog ................................ .221
Hazard Warning Flasher ..................438
Headlights ........................ .134, 520
Headlights On Reminder ..................138
Headlights On With Wipers .............136, 146
Headlight Switch ...................... .134
High Beam ....................... .140, 221
High Beam Indicator .....................221
High Beam/Low Beam Select ...............140
Illuminated Entry ........................21
Instrument Cluster ...................134, 221
10
INDEX 561

Tilting.............................. .122
Security Alarm ............................18
Arm The System ........................19
Disarm The System .......................19
Selection of Coolant (Antifreeze) ...............523
Selection of Oil .......................... .472
SENTRY KEY FCC General Information ..................18
Key Programming .......................18
Sentry Key (Immobilizer) ....................16
Sentry Key Replacement .....................17
Service Assistance ........................ .543
Service Contract ......................... .545
Service Engine Soon Light (Malfunction Indicator) . .221
Service Manuals ......................... .548
Shift Indicator Light ...................... .352
Shifting ............................... .353
Automatic Transmission ..................353
Shift Speeds ............................ .351Shift Speeds, Manual Transmission
.............351
Shoulder Belts ............................44
Side View Mirror Adjustment .................109
Signals, Turn ...................... .95, 139, 221
Snow Chains (Tire Chains) ...................417
Snow Tires ............................. .413
Spark Plugs ............................ .523
Specifications Fuel (Gasoline) ........................ .523
Oil................................. .523
Speed Control (Cruise Control) ............151, 155
Speedometer ............................ .221
SRT Performance Features ...................274
Starting ............................. .26, 341
Automatic Transmission ..................342
Cold Weather ......................... .346
Engine Fails to Start .....................346
Remote ...............................26
Starting and Operating .....................341
10
INDEX 567
