2015 DODGE CHALLENGER SRT cruise control

•The vehicle parking brake is applied.
• The braking temperature exceeds normal range (over-
heated).
• The shift lever/gear selector is removed from the
Drive position.
To Resume Speed
To resume a previously set speed, push the RES button
and release. Resume can be used at any speed above
20 mph (32 km/h).
To Turn Off
The system will turn off and erase the set speed in
memory if:
• The Normal (Fixed Speed) Electronic Speed Control
ON/OFF button is pushed.
• The ignition is turned off.
• The Adaptive Cruise Control (ACC) On/Off button is
pushed.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ..........218
 INSTRUMENT CLUSTER — SRT ...........219
 INSTRUMENT CLUSTER — SRT ...........220
 INSTRUMENT CLUSTER DESCRIPTIONS .....221
 DRIVER INFORMATION DISPLAY (DID) .....230
▫ Engine Oil Life Reset ..................233
▫ Cruise Control ....................... .235
▫ DID Yellow Telltales ....................235
▫ DID Red Telltales .....................236
▫ DID Selectable Menu Items ..............239
Uconnect® SETTINGS ...................249
▫ Buttons On The Faceplate ................250
▫ Buttons On The Touchscreen ..............251
▫ Customer Programmable Features — Uconnect®
8.4 Settings ......................... .251
▫ Guidelines For Race Track Use Of Your SRT . . .271
▫ SRT Performance Pages .................274
▫ SRT Drive Modes .....................286
▫ Race Options ........................ .298
▫ Valet Mode ......................... .3024

5. Push and release theDOWNarrow button to select “
Ye s ,” then push and release the OKbutton to select
reset of the Oil Life.
6. Push and release the UParrow button to exit the
submenu screen.
NOTE: If the indicator message illuminates when you
start the vehicle, the oil change indicator system did not
reset. If necessary, repeat this procedure.
Cruise Control
This area will show reconfigurable white caution tell-
tales. These telltales include:
• Cruise Ready
This telltale will illuminate white to indicate
that the Adaptive Cruise Control system is
activated. •
Electronic Speed Control SET
This telltale will illuminate green when the
electronic speed control is SET. Refer to “Elec-
tronic Speed Control” in “Understanding The
Features Of Your Vehicle” for further
information.
DID Yellow Telltales
This area will show reconfigurable amber caution tell-
tales. These telltales include:
• Service Forward Collision Warming — If Equipped
This light warns the driver of a potential colli-
sion with the vehicle in front and prompts the
driver to take action in order to avoid the
collision. Refer to “Adaptive Cruise Control
(ACC)” in “Understanding The Features Of Your Ve-
hicle” for further information.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 235

•Windshield Washer Fluid Low Indicator
This telltale will turn on to indicate the wind-
shield washer fluid is low.
• Service Adaptive Cruise Control — If Equipped
This light will turn on when a ACC is not
operating and needs service. Refer to “Adap-
tive Cruise Control (ACC)” in “Understanding
The Features Of Your Vehicle” for further
information.
• LaneSense Failure Telltale
This telltale will turn on to indicate that the
LaneSense Departure has detected a failure. •
Service AWD Indicator
This telltale will turn on to indicate the All
Wheel Drive (AWD) system is not functioning
properly and that service is required.
DID Red Telltales
This area will show reconfigurable red caution telltales.
These telltales include:
•Power Steering System Over Temperature — If
Equipped
If the “SERVICE POWER STEERING” message
and a steering wheel icon are displayed on the
DID screen, it indicates that the vehicle needs
to be taken to the dealer for service. It is likely
the vehicle has lost power steering assistance. Refer to
“Power Steering” in “Starting And Operating” for further
information.
236 UNDERSTANDING YOUR INSTRUMENT PANEL

Driver Assist — If Equipped
Adaptive Cruise Control (ACC) Menu
The DID displays the current ACC system settings. The
information displayed depends on ACC system status.
Push the ADAPTIVE CRUISE CONTROL (ACC) ON/
OFF button (located on the steering wheel) until one of
the following displays in the DID:
Adaptive Cruise Control Off
When ACC is deactivated, the display will read “Adap-
tive Cruise Control Off.”
Adaptive Cruise Control Ready
When ACC is activated but the vehicle speed setting has
not been selected, the display will read “Adaptive Cruise
Control Ready.”Push the SET + or the SET- button (located on the steering
wheel) and the following will display in the DID:
ACC SET
When ACC is set, the set speed will display in the
instrument cluster.
The ACC screen may display once again if any ACC
activity occurs, which may include any of the following:
•
Distance Setting Change
• System Cancel
• Driver Override
• System Off
• ACC Proximity Warning
• ACC Unavailable Warning
246 UNDERSTANDING YOUR INSTRUMENT PANEL

CavityCartridge Fuse Mini-Fuse Description
36 –10 Amp Red Anti-Lock Brake Module
37 –10 Amp Red Engine Controller/Rad Fan Relays – If
Equipped
38 –10 Amp Red Airbag Module
39 –10 Amp Red Power Steering Module/AC Clutch Relay
48 –10 Amp Red AWD Module/Front Axle Disconnect (LX)
/ Adaptive Cruise (LA) – If Equipped
49 –– Fuse – Spare
50 –– Fuse – Spare
51 –20 Amp Yellow Vacuum Pump
52 –5 Amp Tan Adaptive Cruise (LD/LX) – If Equipped
53 –– Fuse – Spare
7
MAINTAINING YOUR VEHICLE 507

About Your Brakes.....................382, 385
ABS (Anti-Lock Brake System) ................386
Adaptive Cruise Control (ACC) (Cruise Control) . . .155
Adding Engine Coolant (Antifreeze) ............487
Adding Fuel ............................ .430
Adding Washer Fluid ..................... .482
Additives, Fuel .......................... .428
Airbag.............................. .53, 54
Air Bag Advance Front Air Bag ....................54
Air Bag Components .....................53
Air Bag Operation .......................56
Air Bag Warning Light ..................64, 66
Enhanced Accident Response ................64
Event Data Recorder (EDR) .................67
FrontAirBag ........................53, 54
If A Deployment Occurs ...................62
Knee Impact Bolsters .....................57
Maintaining Your Air Bag System ............66Side Air Bags
...........................57
Transporting Pets ........................89
Air bag Deployment ........................53
Air bag Light .....................64, 66, 93, 221
Air bag Maintenance ........................66
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . .475
Air Conditioner Maintenance .................477
Air Conditioning Filter ..................320, 479
Air Conditioning, Operating Tips ...........319, 321
Air Conditioning Refrigerant ..........477, 478, 479
Air Conditioning System .................318, 477
Air Pressure, Tires ........................ .409
Alarm Arm The System ........................19
Disarm The System .......................19
Alarm Light ............................ .221
Alarm, Panic .............................24
Alarm (Security Alarm) ......................18
Alarm System (Security Alarm) ................18
552 INDEX

Lower Anchors And Tethers For Children.......75
Older Children And Child Restraints ..........71
Seating Positions ........................74
Using The Top Tether Anchorage .............87
Clean Air Gasoline ....................... .426
Cleaning Wheels .............................. .498
Climate Control ......................... .310
Automatic ........................... .310
Cold Weather Operation ....................346
Console, Overhead ....................... .194
Contract, Service ......................... .545
Coolant Pressure Cap (Radiator Cap) ...........489
Cooling System .......................... .485
Adding Coolant (Antifreeze) ...............487
Coolant Capacity ...................... .522
Coolant Level ..................... .485, 490
Disposal of Used Coolant .................489
Drain, Flush, and Refill ...................486 Inspection
........................... .490
Points to Remember .....................490
Pressure Cap ......................... .489
Radiator Cap ......................... .489
Selection of Coolant (Antifreeze) ......486, 522, 523
Corrosion Protection ...................... .496
Cruise Control (Speed Control) ................155
Cupholders ......................... .210, 502
Customer Assistance ...................... .543
Customer Programmable Features .............249
Data Recorder, Event .......................67
Daytime Brightness, Interior Lights .............143
Daytime Running Lights ....................138
Dealer Service ........................... .469
Deck Lid, Emergency Release .................40
Deck Lid, Power Release .....................39
Defroster, Rear Window .....................213
Defroster, Windshield .......................93
10
INDEX 555
