2015 DODGE CHALLENGER SRT fuse

CavityCartridge Fuse Mini-Fuse Description
21 30 Amp Pink –Headlamp Washers – If Equipped / Police
Feed
22 40 Amp Green / 20
Amp Blue – Police –
Engine Cooling Pump (6.2L Supercharged)
/ Police Bat Feed#3–IfEquipped
23 20 Amp Blue –Police Bat Feed#1–IfEquipped
24 20 Amp Blue –Police Bat Feed#3–IfEquipped
28 –– Fuse – Spare
29 –15 Amp Blue Transmission Control Module
(LA/LD Police)
30 –– Fuse – Spare
31 –25 Amp Clear Engine Module
32 –– Fuse – Spare
33 –– Fuse – Spare
34 –25 Amp Clear Powertrain #1
35 –20 Amp Yellow Powertrain #2
506 MAINTAINING YOUR VEHICLE

CavityCartridge Fuse Mini-Fuse Description
36 –10 Amp Red Anti-Lock Brake Module
37 –10 Amp Red Engine Controller/Rad Fan Relays – If
Equipped
38 –10 Amp Red Airbag Module
39 –10 Amp Red Power Steering Module/AC Clutch Relay
48 –10 Amp Red AWD Module/Front Axle Disconnect (LX)
/ Adaptive Cruise (LA) – If Equipped
49 –– Fuse – Spare
50 –– Fuse – Spare
51 –20 Amp Yellow Vacuum Pump
52 –5 Amp Tan Adaptive Cruise (LD/LX) – If Equipped
53 –– Fuse – Spare
7
MAINTAINING YOUR VEHICLE 507

Rear Power Distribution Center (Fuses)
There is also a power distribution center located in the
trunk under the spare tire access panel. This center
contains fuses and relays.
CAUTION!
•When installing the power distribution center
cover, it is important to ensure the cover is properly
positioned and fully latched. Failure to do so may
allow water to get into the power distribution
center and possibly result in an electrical system
failure.
• When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If
a properly rated fuse continues to blow, it indicates
a problem in the circuit that must be corrected.
Rear Power Distribution Center
508 MAINTAINING YOUR VEHICLE

CavityCartridge Fuse Mini-FuseDescription
2 60 Amp Yellow —Front PDC Feed #1
3 — —Fuse – Spare
4 60 Amp Yellow —Front PDC Feed #2
5 30 Amp Pink —Sunroof / Dome Lamp –
Police
6 40 Amp Green —Exterior Lighting #1
7 40 Amp Green —Exterior Lighting #2
8 30 Amp Pink —Interior Lighting
9 40 Amp Green —Power Locks
10 30 Amp Pink —Driver Door Control
Module
11 30 Amp Pink —Passenger Door Control
Module
7
MAINTAINING YOUR VEHICLE 509

CavityCartridge Fuse Mini-FuseDescription
12 —20 Amp Yellow Dual USB Center Console
Rear/Cigar Lighter IP – If
Equipped
15 40 Amp Green —HVAC Blower
16 20 Amp Blue —Left Spot Lamp – Police
17 ——Fuse – Spare
18 30 Amp Pink —Mod Network Interface –
Police
19 ——Fuse — Spare
20 ——Fuse — Spare
21 30 Amp Pink (6.2L Super-
charged)
25 Amp Clear (LD STD) —
Fuel Pump (6.2L Super-
charged)
Fuel Pump (LD STD)
22 —20 Amp Yellow – Police
10 Amp Red – LA Right Spot Lamp – Police
Integrated Center Stack –
LA
510 MAINTAINING YOUR VEHICLE

CavityCartridge Fuse Mini-FuseDescription
23 —10 Amp Red Fuel Door/Diagnostic
Port
24 —15 Amp Blue Integrated Center Stack –
LD/LX
25 —10 Amp Red Tire Pressure Monitor
26 —15 Amp Blue – LD/LX
25 Amp Clear – LA
30 Amp Green – LA 6.2L Supercharged Transmission / Electronic
Shift Module (LD/LX)
Fuel Pump (LA)
Fuel Pump (LA 6.2L Su-
percharged)
27 —25 Amp Clear Amplifier – If Equipped
31 —25 Amp Breaker Power Seats
32 —15 Amp Blue HVAC Module/Cluster
33 —15 Amp Blue Ignition Switch/RF hub
Module/Steering Column
Lock-LX If Equipped
7
MAINTAINING YOUR VEHICLE 511

CavityCartridge Fuse Mini-FuseDescription
34 —10 Amp Red Steering Column
Module/Clock/Spare –
Police
35 —5 Amp Tan Battery Sensor
36 —15 Amp Blue Electronic Exhaust Valve
– If Equipped
37 —20 Amp Yellow Radio
38 —15 Amp Blue – LD/LX
20 Amp Yellow – LA Console Power Outlet/
Console Media Hub (LD/
LX)
Power Outlet Inside Arm
Rest/Console Media Hub
(LA)
40 ——Fuse — Spare
41 ——Fuse — Spare
42 30 Amp Pink —Rear Defrost
512 MAINTAINING YOUR VEHICLE

CavityCartridge Fuse Mini-FuseDescription
43 —20 Amp Yellow Rear Heated Seats/
Steering Wheel Module
44 —10 Amp Red Park Assist / Blind Spot
/ Rear View Camera
45 —15 Amp Blue Cluster / Rearview Mir-
ror / Compass(LDLX)/
Humidity Sensor
46 ——Fuse — Spare
47 —10 Amp Red Adaptive Front Lighting
/ Auto High BEAM /
Day Time Running
Lamps- If Equipped
48 —20 Amp Yellow Active Suspension – SRT
49 ——Fuse — Spare
50 ——Fuse — Spare
7
MAINTAINING YOUR VEHICLE 513
