2015 Citroen DS5 ECO mode

275
DS5_en_Chap10_caracteristiques_ed01-2015
* The kerb weight is equal to the unladen weight + driver (75 kg).
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the maximum authorised speed is reduced (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
di
esel engine
e-H d i 110
e-H d i 115
BlueH d i 120
BlueH d i 135
Gearbox ETG6 6-speed
electronic ETG6 6-speed
electronic 6-speed manual 6-speed manual
Model code 9HR8/PS9H
d8
/PS
BHZM/S -M/1S -M/2S AH
v
AHSM/S - M/1S
-M/2S
-
U
nladen weight
1 5281 5281 5281 635
-
K
erb weight*
1 6031 6031 603 1 710
-
G
ross vehicle weight (GV W)
2 1502 1502 1502 255
-
G
ross train weight (GTW)
o

n a 12% gradient
3 150
3 1503 1503 305
-
B
raked trailer (within the GTW limit)
o

n a 10% or 12% gradient
1 000
1 0001 000 1 050
-
U
nbraked trailer
74 574 574 5750
-
R
ecommended nose weight
75757575
Diesel weights and towed loads (in kg) - Commercial versions
Technical data

DS5_en_Chap10_caracteristiques_ed01-2015
diesel engineBlueH d i 15 0 H d i 160BlueH d i 180
Gearbox 6-speed manual 6-speed manual6-speed automaticEAT6 6-speed
automatic
Model code AHX AHRM/S -M/1S
-M/2S RHH8 -8/1 -8/2
RHHA -A /1AHW T/S -T/1S -T/2S
-

U
nladen weight 1 6351 643 1 634 1 634
-

K
erb weight* 1 7101 7181 709 1 709
-

G
ross vehicle weight (GV W) 2 2552 265 2 2552 255
-

G
ross train weight (GTW)
o

n a 12% gradient 3 305
3 3153 305 3 305
-

B
raked trailer (within GTW limit)
o

n a 10% or 12% gradient 1 050
1 0501 0501 050
-

U
nbraked trailer 750750750750
-

R
ecommended nose weight 75757575
Diesel weights and towed loads (in kg) - Commercial versions
* The kerb weight is equal to the unladen weight + driver (75 kg).
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
When towing, the maximum authorised speed is reduced (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

285
DS5_en_Chap11c_SMEGplus_ed01-2015
7-inch touch screen tablet
GPS satellite navigation - Multimedia audio - Bluetooth® telephone
Contents
First steps
2 86
Steering mounted controls

2
88
Menus
28

9
Navigation
2

90
Navigation - Guidance

2
98
Tr a f fi c
3

0 2
Radio Media

3
04
Radio
31

0
DAB (Digital Audio Broadcasting) radio

3
12
Media
3

14
Settings
3

18
Internet
3

26
Internet browser

3
27
MirrorLink
® 330
Telephone
3
32
Frequently asked questions

3
40
The system is protected in such a way that it will only operate in
your vehicle. As a safety measure, the driver should only carry out operations
which require prolonged attention while the vehicle is stationary.
The display of the energy economy mode message signals
that the system is about to go into standby. Refer to the Energy
economy (mode) section.
Audio and Telematics

DS5_en_Chap11c_SMEGplus_ed01-2015
Steering mounted controls
Media: change the multimedia
source.
Telephone: call.
Call in progress: access to the
telephone menu (end call, secret
mode, hands-free mode).
Telephone, press and hold: reject an
incoming call, end a call; when there
is no call in progress, access to the
telephone menu.
MirrorLink
®, press and hold:
start voice recognition on your
smartphone via the system. Decrease volume.
Radio, rotate: automatic search for
the previous
/ next station.
Media, rotate: previous
/ next track.
Press: confirm a selection. Radio: display the list of stations.
Media: display the list of tracks.
Radio, press and hold: update the list
of stations received.
Increase volume.

291
DS5_en_Chap11c_SMEGplus_ed01-2015
Level 1Level 2 Level 3co mments
Navigation Settings
Navigation Enter destination
Display recent destinations
calc

ulatory criteriaFastest
Choose the navigation criteria.
The map displays the route chosen according to
these criteria.
Shortest
Time/distance
Ecological
To l l s
Ferries
Tr a f f i c
Strict-Close
Show route on map Display the map and start navigation.
Confirm
Save the options.
Save current location Save the current address.
Stop navigation Delete the navigation information.
voic

e synthesis Choose the volume for voice and announcement
of street names.
di

version Detour from your initial route by a determined
distance.
Navigation Display in text mode.
Zoom in.
Zoom out.
Display in full screen mode.
Use the arrows to move the map.
Switch to 2D map.
Audio and Telematics

15
5
12
8
16
6
13
9
17
7
14
10
11
18
1
1
1
307
DS5_en_Chap11c_SMEGplus_ed01-2015
Level 1Level 2 Level 3co mments
Radio Media
Secondary page Radio list Preset
Press a radio station to select it.
Update list Update the list of stations received.
Frequency Enter the desired radio frequency.
c

onfirm Save the settings.
Radio Media
Secondary page Photos Home screen
Display the selected photo in the home page.
Rotate Rotate the photo 90°.
Select all Select all the photos in the list.
Press again to deselect.
Slideshow Previous photo.
Display the photos in sequence, full screen.
The system supports the following image
formats: .gif, .jpg, .bmp, .png.
Pause
/ Play.
Next photo.
Full screen Display the selected photo full-screen.
Radio Media
Secondary page
Manage Jukebox Sor t by folder
Choose a selection mode.
Sor t by album
Select all
co

py Copy files to the Jukebox.
Magnifying glass Create folder
Choose the desired function.
Rename
Delete
Select all
Confirm
Save the settings.
Audio and Telematics

3
2
3
3
1
DS5_en_Chap11c_SMEGplus_ed01-2015
Press on Radio Media to display the
primary page.
Press Radio Media to display the
primary page. Select "
Preset".
If necessary, select change of
source. Press on Radio Media
to display the
primary page.
Select change source.
"
AM Radio ". By automatic frequency search
Select "FM Radio ".
" AM Radio ".
Press on the secondary page.
Select a preset radio station
in the list.
Select " FM Radio ".
Select a radio station from
the list offered.
Select " Update list " to refresh the
list. Select " List" in the primary page.
Or Press on Radio Media to display the
primary page.
Radio
changing a radio frequency
Selecting a station
OR THEN
Radio reception may be affected by
the use of electrical equipment not
approved by CITROËN, such as a USB
charger connected to the 12 V socket.
The exterior environment (hills,
buildings, tunnel, car park, below
ground...) may prevent reception,
even in RDS station tracking mode.
This phenomenon is normal in the
propagation of radio waves and is in no
way indicative of a fault with the audio
system.
Or
Select "
Radio list " in the secondary
page. Or
Press 3 or 4 to move the cursor for an
automatic search down or up for a radio
frequency.
Or

315
DS5_en_Chap11c_SMEGplus_ed01-2015
The audio equipment will only play audio
files with ".wma, .aac, .flac, .ogg and. mp3"
file extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of file (.mp4, ...) can be played.
"wma" files must be of the standard wma 9
type.
The sampling rates supported are 11, 22, 44
and 48 KHz. In order to be able to play a recorded CDR or
CDRW, when recording it is preferable to select
the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format it may
not be played correctly.
It is recommended that the same recording
standard is always used for an individual disc,
with as low a speed as possible (4x maximum)
for optimum sound quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.
It is advisable to restrict file names to
20
characters, without using of special
characters (e.g.: " "
? ; ù) to avoid any playing
and displaying problems.
Information and advice
Use only USB memory sticks formatted FAT 32
(28 -bit file allocation table).
The system supports USB mass
storage devices, BlackBerry
® devices
or Apple® players via USB ports. The
adaptor cable not supplied.
Control of the peripheral device is with
the audio system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied). It is recommended that the USB cable
for the portable device is used. The system does not support the
simultaneous connection of two
identical devices (two memory sticks,
two Apple
® players) but it is possible
t
o connect one memory stick and one
Apple
® player at the same time.
Audio and Telematics
