Operating fault
Have it checked by a CITROËN dealer or a
qualified workshop.
In the event of a fault in STOP mode, the
vehicle may stall.
All of the instrument panel warning lamps
come on.
It is then necessary to switch off the ignition
and start the engine again using the "START/
STOP" button.Before doing any work under the
bonnet, deactivate the Stop & Start
system to avoid the risk of injury related
to an automatic change to START
mode.
This system requires the use of a 12 V battery
of specific technology and characteristics
(reference numbers available from a CITROËN
dealer or a qualified workshop).
Fitting a battery not listed by CITROËN would
introduces the risk of faults with the system.
Maintenance
The Stop & Start system makes use of
an advanced technology. All work on
this type of battery must only be carried
out by a CITROËN dealer or a qualified
workshop.With the Touch screen tablet system
A fault with the system is signalled in the
"dr iving" menu page.
With the control switch on the
dashboard
In the event of a fault with the system, the
indicator lamp in the "EcO O
FF" control switch
flashes, then comes on continuously.
The symbol in the "E
cO

OFF!"
button changes to alert mode and
the indicator lamp flashes for a few
moments then remains on fixed. If you press this button to reactivate
the system, the indicator lamp flashes
again for a few moments then returns to
fixed illumination.

DS5_en_Chap04_conduite_ed01-2015
F With the engine running, press button 1. The
activated/deactivated status when the engine was
switched off is retained when the engine is switched
on again.
The blade retracts automatically 3 seconds after switching
off the engine except in STOP mode of Stop & Start.
Activation / de activation
F With the engine running, adjust the
brightness of the information using
button
3:
-

t
owards the rear to increase the
brightness,
-

t
owards the front to decrease the
brightness.
Brightness adjustment
We recommend that adjustments are
only made using these buttons when
the vehicle is stationary.
When stationary or while driving, no
objects should be placed around the
transparent blade (or on its cover) to
avoid blocking deployment of the blade
and preventing its correct operation.
In certain extreme weather conditions
(rain and/or snow, bright sunshine, ...)
the head-up display may not be legible
or may suffer temporary inter ference.
Some sunglasses may hamper reading
of the information.
To clean the transparent blade, use a
clean, soft cloth (such as a spectacles
cloth or microfibre cloth). Do not use
a dry or abrasive cloth or detergent or
solvent products as these could scratch
the blade or damage the anti-reflection
coating.
Height adjustment
F With the engine running, adjust the display to the required height using button 2 :
-

t
owards the rear to move the display up,
-

t
owards the front to move the display
down.

241
DS5_en_Chap09_verifications_ed01-2015
Fuel tankcapacity of the tank: approximately 60 litres.Additions of fuel must be of at least 5 litres to
be registered by the fuel gauge.
Opening the filler cap may result in an inrush of
air. This vacuum is entirely normal and results
from the sealing of the fuel system.
F

T
ake care to select the pump that delivers
the correct fuel type for your vehicle's
engine (reminder on a label on the inside of
the filler flap).
F

O
pen the filler cap by turning it a 1/4 turn to
the left.
F

R
emove the filler cap and hang it on its
carrier (on the filler flap).
Opening
If you have put in the wrong fuel for
your vehicle, you must have have
the tank drained and refilled with
the correct fuel before you star t the
engine.
With Stop & Start, never refuel with the
system in STOP mode; you must switch
off the ignition with the START/STOP
button.
Refuelling
F Introduce the nozzle and push it in fully
(pushing open the non-return valve A on
petrol vehicles).
F

F
ill the tank (don't continue past the third
cut-off of the nozzle, as this may cause
malfunctions).
F

R
efit the filler cap turning it a 1/4 turn to the
right.
F

P
ush the filler flap to close it.
Your vehicle is fitted with a catalytic converter
which reduces harmful emissions in the
exhaust gas.
The filler neck is narrower and allows only
petrol nozzles to be used.
For a petrol engine, the use of unleaded fuel
is compulsory.
F

P

ress the switch
This switch remains active for a few minutes
after switching off the ignition. If necessary,
switch the ignition on again to reactivate it.
checks

261
DS5_en_Chap09_verifications_ed01-2015
Never store bottles of AdBlue® in your
vehicle. Before topping-up, ensure that the vehicle is
parked on a flat and level sur face.
In wintry conditions, ensure that the
temperature of the vehicle is above -11°C.
Other wise, by freezing, the AdBlue
® cannot
be poured into its tank. Park your vehicle in a
warmer area for a few hours to allow the top-up
to be carried out.
Procedure
F Press the START/STOP button to switch off the engine. F

R
aise the boot floor for access to the
AdBlue
® tank. Use an object, such as a
bag, to keep the left part up.
Recommendations on storage
AdBlue® freezes at about -11°C and
deteriorates above 25°C. It is recommended
that bottles be stored in a cool area and
protected from direct sunlight.
Under these conditions, the additive can be
kept for at least a year.
If the additive has frozen, it can be used once it
has completely thawed out.
checks

15Hybrid4 system
DS5Hy4_en_Chap00c_hybride_ed01-2015
Starting the Hybrid4
system
Activation of the Hybrid4 system
On activation of the Hybrid4 system, the instrument panel lights up, the power indicator needle is placed at position " 0 ". The steering column automatically unlocks (perceptible noise and movement of the steering column). Depending on certain parameters, such as the state of charge of the high voltage battery or the ambient temperature, the Hybrid4 system itself determines whether it is necessary to start the HDi Diesel engine. The mode selector is at the AUTO p o s i t i o n .
In wintry conditions with the engine cold, the Diesel pre-heating warning lamp can stay on for a few seconds; wait until it goes off before releasing the brake pedal.
Starting - switching off the Hybrid4 system
Never leave children alone inside the vehicle when the Hybrid4 system is a c t i v e .
 Place the gear selector at position N .  Insert the electronic key in the reader. or  With Keyless Entry and Starting, simply having the electronic key inside the vehicle is sufficient.
 Press the brake pedal firmly.  Make a single short press (about one second) on the " START/STOP " button.  Maintain pressure on the brake pedal until the RE ADY lamp comes on, signalling RE ADY lamp comes on, signalling RE ADYactivation of the Hybrid4 system, confirmed by an audible signal.
If the Hybrid4 system does not start up:  If N is flashing in the instrument panel, move the gear selector to position A then to position N .  If the " Foot on the brake " is displayed, press the brake pedal
f i r m l y .

17Hybrid4 system
DS5Hy4_en_Chap00c_hybride_ed01-2015
Switching off the Hybrid4
system
 Immobilise the vehicle.  Place the gear selector in position N .  Make a short press (about one second) on the " START/STOP " button. The Hybrid4 stops: - the RE ADY lamp goes off, RE ADY lamp goes off, RE ADY
- the steering column locks, - the electric parking brake is applied automatically, unless its automatic mode is deactivated.  Check that the parking brake warning lamps are on.  Remove the electronic key from the reader.
Before doing anything under the bonnet, the Hybrid4 must be switched off ( RE ADY lamp off) and the electric RE ADY lamp off) and the electric RE ADYparking brake must be applied.
Check that the RE ADY lamp is off RE ADY lamp is off RE ADYbefore leaving the vehicle. Never leave the electronic key in the vehicle in your absence.
For reasons of safety and theft protection,
do not leave your electronic key in the vehicle, even when you are close to it. It is recommended that you keep it on your person.
Switching the ignition on
With the electronic key in the reader or the Keyless Entry and Starting key inside the vehicle, pressing the " START/STOP " button, with no action on the brake pedal , allows the ignition to be switched on.
 Press the " START/STOP " button, the instrument panel comes on but the Hybrid4 system does not start up.
With the ignition on, the system goes into energy economy mode when necessary to maintain the state of charge of the battery.
 Press this button again to switch off the ignition and so allow the vehicle to be l o c k e d .

DS5Hy4_en_Chap00c_hybride_ed01-2015
Back-up starting /
emergency switching off
Back-up starting with the Keyless Entry and Starting system
When the electronic key is in the recognition zone and after pressing the " START/STOP " button, the Hybrid4 system does not start up:
 Insert the electronic key in the reader.  Place the gear selector at position N .  Press the brake pedal firmly.  Press the " START/STOP " button. The Hybrid4 starts up; the RE ADY lamp is on. RE ADY lamp is on. RE ADY
Electronic key not recognised with Keyless Entry and Starting
If the electronic key is no longer in the recognition zone when driving or when you (later) request switching off of the hybrid system, a message appears in the instrument panel.
 Press and hold the " START/STOP " button for about 3 seconds if you want to force the hybrid system to switch off.
In the event of an emergency only, the engine can be switched of without any conditions.  To do this, press and hold the " S TA R T/STOP " button for about 3 seconds. In this case the steering column locks as soon as the vehicle stops.
The electronic key must always remain inside the vehicle when in use.
Emergency switching off
Note that restarting will not be possible without the presence of the electronic key in the recognition zone.

DS5Hy4_en_Chap08_info-pratiques_ed01-2015
Car washing machine or tunnel
Some car washing machines or tunnels (where the vehicle is moved for wards on a travelling track) require that the parking brake be "released" during the wash.
With the hybrid system active, RE ADY lamp on, parking brake RE ADY lamp on, parking brake RE ADYreleased: - Place the gear selector at position N . - Switch off the engine (press the START/STOP button). The parking brake is applied automatically and the RE ADYlamp goes off in the instrument panel. - Switch on the ignition again (press the START/STOP button) without your foot on the brake pedal. The RE ADY lamp RE ADY lamp RE ADYremains off. - Release the parking brake using the manual control on the centre console, while keeping your foot on the brake pedal. - Switch off the ignition (press the START/STOP button without
your foot on the brake pedal) checking that the parking brake r e m a i n s r e l e a s e d .
If the HDi Diesel engine was on standby, it then restarts. If the HDi Diesel engine is running, its operation is maintained without time limit.
With the hybrid system active, RE ADY lamp on, parking brake RE ADY lamp on, parking brake RE ADYreleased: - Place the gear selector at position N ( AUTO mode). - Press the brake pedal then the " ECO OFF " b u t t o n .
Car washing machines or tunnels in which the HDi Diesel engine must be switched off. Car washing machines or tunnels in which the HDi Diesel engine must not be switched off.
If possible on your vehicle, deactivate the automatic operation of the electric parking brake in the vehicle systems configuration menu.
