2015 CITROEN DS3 CABRIO DAG headlamp

DS3_en_Chap00b_vue-ensemble_ed01-2014
Exterior
customising kits
These expressive stickers form part   of   a   range   of   kits,   very
d

ifferent   one   from   another,   which
a

llow you to create a unique
and
  attractive   exterior   for   your
v

ehicle.
Guide-me-home lighting
After switching off the ignition, under low lighting conditions the headlamps remain   on   for   a   few   seconds   to   help   you   leave   the   vehicle.
Active city Brake
The purpose of this system is to avoid a frontal collision   or   reduce   the   speed   of   impact   if   the
d

river   fails   to   take   action   or   does   not   take
s

ufficient   action.
2 41
13 5 157
Stop & Start
This system puts the engine t
emporarily   on   standby   during
s

tops   in   the   traffic   (red   lights,   traffic
j

ams,   etc...).   The   engine   restarts
a

utomatically   as   soon   as   you   want
t

o   move   off.   The   Stop   &   Start   system
r

educes   fuel   consumption,   exhaust
e

missions   and   the   noise   level   when
s

tationary. 118

DS3_en_Chap00c_eco-conduite_ed01-2014
Before moving off, if the passenger compartment is too warm, ventilate it by   opening   the   windows   and   air   vents   before   using   the   air   conditioning.
Above
  30   mph   (50   km/h),   close   the   windows   and   leave   the   air   vents
 ope

n.
Remember
  to   make   use   of   equipment   that   can   help   keep   the
 t

emperature   in   the   passenger   compartment   down   (sunroof   and   window
 b

linds...).
Switch
  off   the   air   conditioning,   unless   it   has   automatic   regulation,   as
 s

oon   as   the   desired   temperature   is   attained.
Switch
  off   the   demisting   and   defrosting   controls,   if   not   automatic.
Switch
  off   the   heated   seat   as   soon   as   possible.
Switch
  off   the   headlamps   and   front   foglamps   when   the   level   of   light
d

oes   not   require   their   use.
Avoid
  running   the   engine   before   moving   off,   particularly   in   winter;   your
v

ehicle   will   warm   up   much   faster   while   driving.
Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.
Optimise the use of your gearbox
With a manual gearbox, move off gently and change up without waiting. During   acceleration   change   up   early.
With
  an   automatic   or   electronic   gearbox,   give   preference   to   automatic
m

ode   and   avoid   pressing   the   accelerator   pedal   heavily   or   suddenly.
The
  gear   shift   indicator   invites   you   engage   the   most   suitable   gear:   as
s

oon   as   the   indication   is   displayed   in   the   instrument   panel,   follow   it
s

traight   away.
For
  vehicles   fitted   with   an   electronic   or   automatic   gearbox,   this
i

ndicator   appears   only   in   manual   mode.
drive smoothly
Maintain a safe distance between vehicles, use engine braking rather than   the   brake   pedal,   and   press   the   accelerator   progressively.   These
p

ractices   contribute   towards   a   reduction   in   fuel   consumption   and   CO
2
emissions

and

also

helps

reduce

the

background

traffic

noise.
control the use of your electrical
equipment
If your vehicle has cruise control, make use of the system at speeds a bove   25   mph   (40   km/h)   when   the   traffic   is   flowing   well.As
  a   passenger,   if   you   avoid   connecting   your   multimedia   devices
(

film,   music,   video   game...),   you   will   contribute   towards   limiting   the  c
onsumption   of   electrical   energy,   and   so   of   fuel.
Disconnect   your   portable   devices   before   leaving   the   vehicle.

23
DS3_en_Chap01_controle-de-marche_ed01-2014
Operation indicator lamps
If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.
W arning /indicator lampis on
cau

seAction / Observations
Left-hand
direction indicatorflashing with buzzer.The   lighting   stalk   is   pushed   down.
Right-hand
direction indicatorflashing with buzzer.The   lighting   stalk   is   pushed   up.
Sidelamps fixed. The
  lighting   stalk   is   in   the   "Sidelamps"
p

osition.
di

pped beam
headlamps fixed.
The
  lighting   stalk   is   in   the   "Dipped
b

eam   headlamps"   position.
Main beam
headlamps fixed.
The
  lighting   stalk   is   pulled   towards
yo

u. Pull
  the   stalk   to   return   to   dipped   beam   headlamps.
Front foglamps fixed. The
  front   foglamps   are   switched   on
u

sing   the   ring   on   the   lighting   control
st

alk. Turn
  the   ring   on   the   lighting   control   stalk   rear wards
t

wice   to   switch   off   the   front   foglamps.
Rear foglamps fixed. The
  rear   foglamps   are   on.Turn
  the   ring   on   the   stalk   rear ward   to   turn   off   the   rear
fo

glamps.
Hazard warning
lamps
flashing
  with   audible
s

ignal. The
  hazard   warning   lamps   switch,
l

ocated on the dashboard, has been
operated. The
  left-hand   and   right-hand   direction   indicators   and
t

heir   associated   indicator   lamps   flash   simultaneously.
Monitoring

DS3_en_Chap04_confort_ed01-2014
Rear view mirror
Manual day/night model
Adjustment
F Adjust  the   mirror   so   that   the   glass   is  d
irected   correctly   in   the   "day"   position.
day / night position
F Pull  the   lever   to   change   to   the   "night"   anti-
dazzle   position.
F

P
ush   the   lever   to   change   to   the   normal
"

day"   position. By
  means   of   a   sensor,   which   measures   the
l

ight   from   the   rear   of   the   vehicle,   this   system
a

utomatically   and   progressively   changes
b

etween   the   day   and   night   uses.
Automatic day/night model
In order to ensure optimum visibility d
uring   your   manoeuvres,   the   mirror
l

ightens   automatically   when   reverse
g

ear
 i
s
 enga
ged.
As

a

safety

measure,

the

mirrors

s

hould

be

adjusted

to

reduce

the

"blind

s

p ot ".
Adjustable

mirror

providing

a

central

rear ward

v

iew.
Equipped

with

an

anti-dazzle

system,

which

d

arkens

the

mirror

glass:

this

reduces

t

he nuisance to the driver caused by the
headlamps

from

following

vehicles,

low

sun...

DS3_en_Chap07_visibilite_ed01-2014
Visibility
This section describes all of the lighting and wiper controls, headlamp adjustment,   the   various   interior   lamps   including   the   interior   mood   lighting
a

nd   in   particular,   the   LED   lamps,   a   true   signature   of   your   vehicle.

DS3_en_Chap07_visibilite_ed01-2014
Lighting controlsSystem for selection and control of the various front and rear lamps providing the vehicle's lighting.
T he   various   front   and   rear   lamps   of   the   vehicle
a

re   designed   to   adapt   the   driver's   visibility
p

rogressively   according   to   climatic   conditions:
-

s
idelamps,   to   be   seen,
-

d
ipped   beam   headlamps   to   see   without
d

azzling
 o
ther
 d
rivers,
-

m
ain   beam   headlamps   to   see   clearly   when
t

he   road   is   clear.
Main lighting
Other lamps are installed to fulfil the requirements   of   particular   conditions   of
v

isibility:
-

a
  rear   foglamp   to   be   seen   from   afar,
-

f
ront   foglamps   for   improved   vision,
-

L
ED   lamps   to   be   seen   during   the   daytime.
Additional lighting
Various automatic lighting control modes are   also   available   according   to   the   following
op

tions:
-

g
uide-me-home   lighting,
-

a
utomatic   illumination   of   headlamps.
Programming
In some weather conditions (e.g. low temperature   or   humidity),   the   presence
o

f   misting   on   the   internal   sur face   of   the
g

lass   of   the   headlamps   and   rear   lamps
i

s   normal;   it   disappears   after   the   lamps
h

ave   been   on   for   a   few   minutes.

133
DS3_en_Chap07_visibilite_ed01-2014
Model without AUTO lighting
Model with AUTO lighting
Manual controls
The lighting is controlled directly by the driver by   means   of   the   ring   A   and   the   stalk   B.
Automatic
  illumination   of   headlamps.
B.
 S

talk   for   switching   the   headlamp   beam:
p

ull   the   stalk   to   switch   between   dipped   and
m

ain   beam   headlamps.
In
  the   lamps   off   and   sidelamps   modes,
t

he   driver   can   switch   on   the   main   beam
h

eadlamps   temporarily   ("headlamp   flash")   by
m

aintaining   a   pull   on   the   stalk.
A.
 M

ain   lighting   mode   selection   ring:   turn   it
t

o   position   the   symbol   required   facing   the
ma

rk.Lighting
  off   /   daytime   running   lamps.
Sidelamps
 o

nly.
Dipped headlamps or main beam headlamps.
displays
Lighting of the corresponding indicator lamp on the   instrument   panel   confirms   the   switching   on
o

f   the   lighting   selected.
The
  instrument   panel   has   permanent   back-
lighting.
  Illumination   of   the   instrument   panel   is
t

herefore   not   linked   to   the   exterior   lighting.
Visibility

135
DS3_en_Chap07_visibilite_ed01-2014
The temporary illumination of the dipped beam headlamps   after   the   vehicle's   ignition   has   been
s

witched   off   makes   the   driver's   exit   easier
w

hen   the   light   is   poor.
Switching on
F With  the   ignition   off,   "flash"   the   headlamps  u
sing   the   lighting   stalk.
F

A
  further   "headlamp   flash"   switches   the
f

unction   off.
Switching off
The manual guide-me-home lighting switches off   automatically   after   a   set   time.
Manual guide-me-home
lighting
Visibility
