2015 Citroen C1 Under inflation detection

.
.
Direction indicators 101
Horn 10 1
Hazard warning lamps

1
02
Under-inflation detection
1

02
ESC system

1
05
Active City Brake

1
08
Seat belts

1
13
Airbags
1

16
Safety
Child seats 121
Deactivating the passenger's
front airbag

1
24
ISOFIX child seats

1
30
Child lock

1
35
Child safety Checks
Fuel tank 1
36
Temporary puncture
repair kit

1
38
Changing a wheel

1
43
Snow chains

1
48
Changing a bulb

1
49
Changing a fuse

1
54
12 V battery

1
63
Electrical energy economy mode

1
66
Changing a wiper blade

1
66
Towing the vehicle

1
67
Fitting roof bars

1
68
Accessories
1

69
Practical information Technical data
7-inch touch screen tablet 183
Audio system 2 23
Audio and telematics
Visual search
Alphabetical index
B o n n et 17 2
Petrol engines 1 73
Checking levels

1
74
C h e c ks
17

7Engines
1

79
Weights
18
0
Dimensions
1
81
Identification markings
1
82
Contents

4
C1_en_Chap00b_vue-ensemble_ed01-2015
Exterior
102
81 91
33
Electronic key: Keyless
Entry and Starting
This system allows the locking, unlocking and
starting the vehicle by keeping the key on your
person and in the recognition zone.
Stop & Start
This system puts the engine temporarily
into standby during stops in the traffic (red
lights, traffic jams, etc...). The engine restarts
automatically as soon as you want to move
off. The Stop & Start system reduces fuel
consumption, exhaust emissions and the noise
level when stationary.
Under-inflation detection
This system automatically checks the tyre
pressures when driving and alerts you in the
event of an under-inflated tyre.
Active City Brake
The aim of this system is to avoid a frontal
collision or reduce the speed of impact if the
driver fails to react or reacts too late.
Lane departure warning
system
This system gives a warning if you inadvertently
cross a longitudinal road marking. 108
Over view

7
C1_en_Chap00b_vue-ensemble_ed01-2015
Instruments and controls
1. Lighting and direction indicator stalk
2. Steering mounted controls for the audio
system or the touch screen tablet
A

ctivation / deactivation of the lane
departure warning system
3.
S

teering mounted controls for the ETG
electronic gearbox
4.
S

peed limiter control
5.
S

creen wash/wipe control stalk
6.
E

lectric window controls
7.
B

onnet release
8.
F

uel filler flap release
9.
D

eactivation of Stop & Start
o

r Activation / deactivation of Active City
Brake
H

eadlamp height adjustment 10. D
oor mirror adjustment controls
11. D eactivation of VSC / TRC systems
12 .
S

teering wheel adjustment control
13.
D

river's front airbag


Horn
14 .
S

ide air vents
15.
I

nstrument panel
16.
C

ourtesy lamp
E

lectric fabric roof control
17.
P

assenger's front airbag
18.
G

love box /
D

eactivation of the passenger's front
airbag /
R

einitialisation of the tyre under-inflation
detection system
19.
A

udio system, touch screen tablet or open
storage 20. S
TART/STOP button
21. H azard warning lamps
22.
M

anual or automatic air conditioning
controls
23.
A

uxiliary sockets for portable devices
24.
G

ear lever
25.
C

up holder and storage
26.
P

arking brake
2 7.
C

up holder
.
Over view

18
Stop & Star t
(VTi 68 S&S
engine)flashing.
The Stop & Start system has a fault. Have the system checked by a CITROËN dealer or a
qualified workshop.
Speed limiter fixed. The speed limiter has a fault. Have it checked by a CITROËN dealer or a qualified
workshop.
Door(s) open
/
Boot open fixed, accompanied by
an audible signal. A door or the boot is still open. Close the door or boot.
Warning


/ indicator lamp
State Cause Action

/ Observations
Under-inflation fixed. The pressure in one or more wheels
is too low. Check the tyre pressures as soon as possible.
This check should preferably be carried out when the
tyres are cold.
You must reinitialise the system after the adjustment
of one or more tyre pressures and after changing one
or more wheels.
For more information, refer to the "Under-inflation
detection" section.
Monitoring

62
C1_en_Chap04_amenagements_ed01-2015
Glove box
Sun visor
The sun visors are fitted with a vanity mirror,
with a concealing flap and a map holder
(or ticket holder). It can be used to hold the vehicle's handbook
pack...
F

T
o open the glove box, raise the handle.
It houses the front passenger airbag
deactivation switch A and the reinitialisation
button ( B) for the tyre under-inflation detection
system (depending on equipment).
On one side there is a location C
intended to
hold a water bottle (1 litre maximum). F
T o connect a 12 V accessory (maximum
power: 120 Watts), lift the cover and
connect a suitable adaptor.
12 V accessory socket
Do not exceed the maximum power
rating of the socket (risk of damage to
your device).
Fittings

102
C1_en_Chap07_securite_ed01-2015
Under-inflation detection
The system monitors the pressures in the four
tyres, once the vehicle is moving.
It compares the information given by the four
wheel speed sensors with reference values,
which must be reinitialised ever y time the
tyre pressures are adjusted or a wheel
changed.
The system triggers an alert as soon as it
detects a drop in the inflation pressure of one
or more tyres. The under-inflation detection system
does not replace the need for vigilance
on the part of the driver.
This system does not avoid the need to
check the tyre pressures (including the
spare wheel) every month as well as
before a long journey.
Driving with under-inflated tyres impairs
road holding, extends braking distances
and causes premature tyre wear,
particularly under arduous condition
(high loading, high speed, long journey).
System which automatically checks the pressures of the tyres while driving.
Hazard warning
lamps
Visual warning by means of the direction
indicators to alert other road users to a vehicle
breakdown, towing or accident.
F

P
ress this button, the direction indicators
flash.
They can operate with the ignition off.
Safety

103
C1_en_Chap07_securite_ed01-2015
Under-inflation alert
This is given by fixed illumination of
this warning lamp, accompanied by
an audible signal.
F

R

educe speed immediately, avoid
excessive steering movements and sudden
braking.
F

S

top the vehicle as soon as it is safe to do
so.
The loss of pressure detected does not
always cause visible bulging of the tyre.
Do not satisfy yourself with just a visual
check.
F

I

f you have a compressor (such as the one
in the temporary puncture repair kit) check
the pressures of the four tyres when cold.
I

f it is not possible to carry out this check
straight away, drive carefully at reduced
speed.
or
F

I

n the event of a puncture, use the
temporary puncture repair kit or the spare
wheel (depending on equipment).
The alert is maintained until the system
is reinitialised.
Reinitialisation
Before reinitialising the system, ensure
that the pressures of the four tyres are
correct for the use of the vehicle and in
line with the recommendations on the
tyre pressure label.
The under-inflation detection system
does not give a warning if a pressure is
incorrect at the time of reinitialisation.
It is necessary to reinitialise the system every
time one or more tyre pressure is adjusted, and
after changing one or more wheels.
A label attached to the middle pillar, driver's
side, gives a reminder of this.
The inflation pressures defined for
your vehicle can be found on the tyre
pressure label.
See the "Identification markings"
section.
Tyre pressures should be checked
when the tyres are "cold" (vehicle
stopped for 1 hour or after a journey of
less than 6 miles (10 km) at moderate
speeds).
Other wise (when hot), add 0.3 bar to
the pressures shown on the label. Driving with under-inflated tyres
increases fuel consumption.
7
Safety

142
C1_en_Chap09_info-pratiques_ed01-2015
Should the pressure of one or more
tyres be adjusted, it is necessary to
reinitialise the under-inflation detection
system.
Refer to the "Under-inflation detection"
section.
Tyre under-inflation
detection
After repair of the tyre, the warning
lamp will remain on until the system is
reinitialised.
For more information, refer to the
"Under-inflation detection" section.
F

S

tart the compressor by placing the switch
at the " I" position and adjust the pressure
to the value shown on the vehicle's tyre
pressure label.
T

o deflate: press the black button on the
compressor pipe, at the valve connector.
F

O

nce the correct pressure is reached, put
the switch to the " O" position.
F

R

emove the kit then stow it.
Practical information
