2015 CADILLAC ELR ECO mode

Black plate (62,1)Cadillac ELR Owner Manual (GMNA-Localizing-U.S./Canada-7695154) -
2015 - CRC - 4/25/14
10-62 Vehicle Care
Tire Sealant and
Compressor Kit
{Warning
Running the engine in Extended
Range Mode in an enclosed area
with poor ventilation is dangerous.
Engine exhaust may enter the
vehicle. Engine exhaust contains
carbon monoxide (CO) which
cannot be seen or smelled. It can
cause unconsciousness and even
death. Never run the engine in
Extended Range Mode in an
enclosed area that has no fresh
air ventilation. For more
information, seeEngine Exhaust
on page 9-27.
{Warning
Overinflating a tire could cause
the tire to rupture and you or
others could be injured. Be sure
to read and follow the tire sealant
and compressor kit instructions
and inflate the tire to its
recommended pressure. Do not
exceed the recommended
pressure.
{Warning
Storing the tire sealant and
compressor kit or other
equipment in the passenger
compartment of the vehicle could
cause injury. In a sudden stop or
collision, loose equipment could
strike someone. Store the tire
sealant and compressor kit in its
original location. If this vehicle has a tire sealant and
compressor kit, there may not be a
spare tire, tire changing equipment,
and on some vehicles there may not
be a place to store a tire.
The tire sealant and compressor
can be used to temporarily seal
punctures up to 6 mm (0.25 in) in
the tread area of the tire. It can also
be used to inflate an
underinflated tire.
If the tire has been separated from
the wheel, has damaged sidewalls,
or has a large puncture, the tire is
too severely damaged for the tire
sealant and compressor kit to be
effective. See
Roadside Service on
page 13-5.
Read and follow all of the tire
sealant and compressor kit
instructions.
ProCarManuals.com

Black plate (5,1)Cadillac ELR Owner Manual (GMNA-Localizing-U.S./Canada-7695154) -
2015 - CRC - 4/25/14
Customer Information 13-5
and lock/unlock the vehicle.
Requires an Android™or iPhone®
and an active OnStar subscription.
See my.cadillac.com to register the
vehicle.
Cadillac Owner Centre
(Canada) cadillacowner.ca
Take a trip to the Cadillac Owner
Centre:
.Chat live with online help
representatives.
.Locate owner resources such as
lease-end, financing, and
warranty information.
.Retrieve favorite articles,
quizzes, tips, and multimedia
galleries organized into the
Features and Auto Care
Sections.
.Download owner manuals.
.Find Cadillac-recommended
maintenance services.
Roadside Service
U.S.: 1-888–811-1926.
Canada: 1-800-882-1112.
Text Telephone (TTY) Users (U.S.
Only): 1-888-889-2438.
Service is available 24 hours a day,
365 days a year.
Calling for Service
When calling Roadside Service,
have the following information
ready:
.Your name, home address, and
home telephone number.
.Telephone number of your
location.
.Location of the vehicle.
.Model, year, color, and license
plate number of the vehicle.
.Odometer reading, Vehicle
Identification Number (VIN), and
delivery date of the vehicle.
.Description of the problem.
Coverage
Services are provided up to 6 years/
110 000 km (70,000 mi), whichever
comes first.
In the U.S., anyone driving the
vehicle is covered. In Canada, a
person driving the vehicle without
permission from the owner is not
covered.
Roadside Service is not a part of the
New Vehicle Limited Warranty.
General Motors North America and
Cadillac reserve the right to make
any changes or discontinue the
Roadside Service program at any
time without notification.
General Motors North America and
Cadillac reserve the right to limit
services or payment to an owner or
driver if they decide the claims are
made too often, or the same type of
claim is made many times.
ProCarManuals.com

Black plate (10,1)Cadillac ELR Owner Manual (GMNA-Localizing-U.S./Canada-7695154) -
2015 - CRC - 4/25/14
13-10 Customer Information
center that has GM-trained
technicians and comparable
equipment.
Insuring the Vehicle
Protect your investment in the GM
vehicle with comprehensive and
collision insurance coverage. There
are significant differences in the
quality of coverage afforded by
various insurance policy terms.
Many insurance policies provide
reduced protection to the GM
vehicle by limiting compensation for
damage repairs by using
aftermarket collision parts. Some
insurance companies will not
specify aftermarket collision parts.
When purchasing insurance, we
recommend that you ensure that the
vehicle will be repaired with GM
original equipment collision parts.
If such insurance coverage is not
available from your current
insurance carrier, consider switching
to another insurance carrier.If the vehicle is leased, the leasing
company may require you to have
insurance that ensures repairs with
Genuine GM Original Equipment
Manufacturer (OEM) parts or
Genuine Manufacturer replacement
parts. Read the lease carefully, as
you may be charged at the end of
the lease for poor quality repairs.
If a Crash Occurs
If there has been an injury, call
emergency services for help. Do not
leave the scene of a crash until all
matters have been taken care of.
Move the vehicle only if its position
puts you in danger, or you are
instructed to move it by a police
officer.
Give only the necessary information
to police and other parties involved
in the crash.
For emergency towing see
Roadside Service on page 13-5.
Gather the following information:
.Driver name, address, and
telephone number.
.Driver license number.
.Owner name, address, and
telephone number.
.Vehicle license plate number.
.Vehicle make, model, and
model year.
.Vehicle Identification
Number (VIN).
.Insurance company and policy
number.
.General description of the
damage to the other vehicle.
Choose a reputable repair facility
that uses quality replacement parts.
See “Collision Parts” earlier in this
section.
In a crash, the sensing system may
shut down the high voltage system.
See Battery on page 10-23 for
important safety information. If an
airbag has inflated, see What Will
You See after an Airbag Inflates? on
page 3-24.
ProCarManuals.com

Black plate (11,1)Cadillac ELR Owner Manual (GMNA-Localizing-U.S./Canada-7695154) -
2015 - CRC - 4/25/14
Customer Information 13-11
If the vehicle is damaged from a
crash, flood, fire, or other event it
may be necessary to have the
vehicle inspected. SeeBattery on
page 10-23 andHigh Voltage Safety
Information on page 1-20 for
important safety information.
Managing the Vehicle Damage
Repair Process
In the event that the vehicle requires
damage repairs, GM recommends
that you take an active role in its
repair. If you have a pre-determined
repair facility of choice, take the
vehicle there, or have it towed there.
Specify to the facility that any
required replacement collision parts
be original equipment parts, either
new Genuine GM parts or recycled
original GM parts. Remember,
recycled parts will not be covered by
the GM vehicle warranty.
Insurance pays the bill for the repair,
but you must live with the repair.
Depending on your policy limits,
your insurance company may
initially value the repair using aftermarket parts. Discuss this with
the repair professional, and insist on
Genuine GM parts. Remember,
if the vehicle is leased, you may be
obligated to have the vehicle
repaired with Genuine GM parts,
even if your insurance coverage
does not pay the full cost.
If another party's insurance
company is paying for the repairs,
you are not obligated to accept a
repair valuation based on that
insurance company's collision policy
repair limits, as you have no
contractual limits with that company.
In such cases, you can have control
of the repair and parts choices as
long as the cost stays within
reasonable limits.
Service Publications
Ordering Information
Service Manuals
Service Manuals have the diagnosis
and repair information on the
engine, electric drive unit, axle,
suspension, brakes, electrical,
steering, body, etc.
Service Bulletins
Service Bulletins give additional
technical service information
needed to knowledgeably service
General Motors cars and trucks.
Each bulletin contains instructions
to assist in the diagnosis and
service of the vehicle.
Owner Information
Owner publications are written
specifically for owners and intended
to provide basic operational
information about the vehicle. The
Owner Manual includes the
Maintenance Schedule for all
models.
ProCarManuals.com

Black plate (12,1)Cadillac ELR Owner Manual (GMNA-Localizing-U.S./Canada-7695154) -
2015 - CRC - 4/25/14
13-12 Customer Information
In-Portfolio: Includes a Portfolio,
Owner Manual, and Warranty
Booklet.
RETAIL SELL PRICE: $35.00 to
$40.00 (U.S.) plus handling and
shipping fees.
Without Pouch: Owner Manual only.
RETAIL SELL PRICE:
$25.00 (U.S.) plus handling and
shipping fees.
Current and Past Models
Technical Service Bulletins and
Manuals are available for current
and past model GM vehicles.
ORDER TOLL FREE:
1-800-551-4123 Monday - Friday
8:00 AM - 6:00 PM Eastern Time
For Credit Card Orders Only
(VISA-MasterCard-Discover), visit
Helm, Inc. at: www.helminc.comOr write to:
Helm, Incorporated
Attention: Customer Service
47911 Halyard Drive
Plymouth, MI 48170
Prices are subject to change without
notice and without incurring
obligation. Allow ample time for
delivery.
All listed prices are quoted in U.S.
funds. Make checks payable in U.S.
funds.
Radio Frequency
Identification (RFID)
RFID technology is used in some
vehicles for functions such as tire
pressure monitoring and ignition
system security, as well as in
connection with conveniences such
as Remote Keyless Entry (RKE)
transmitters for remote door locking/
unlocking and starting, and
in-vehicle transmitters for garage
door openers. RFID technology in
GM vehicles does not use or recordpersonal information or link with any
other GM system containing
personal information.
Radio Frequency
Statement
This vehicle has systems that
operate on a radio frequency that
complies with Part 15/Part 18 of the
Federal Communications
Commission (FCC) rules and with
Industry Canada Standards
RSS-GEN/210/220/310.
Operation is subject to the following
two conditions:
1. The device may not cause
harmful interference.
2. The device must accept any interference received, including
interference that may cause
undesired operation of the
device.
Changes or modifications to any of
these systems by other than an
authorized service facility could void
authorization to use this equipment.
ProCarManuals.com

Black plate (3,1)Cadillac ELR Owner Manual (GMNA-Localizing-U.S./Canada-7695154) -
2015 - CRC - 4/25/14
INDEX i-3
Convex Mirrors . . . . . . . . . . . . . . . . 2-17
CoolantEngine . . . . . . . . . . . . . . . . . . . . . . 10-16
Engine TemperatureWarning Light . . . . . . . . . . . . . . . 5-23
Cooling System . . . . . . . . 10-14–10-16 Engine Messages . . . . . . . . . . . . 5-44
Courtesy Lamps . . . . . . . . . . . . . . . . 6-6
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . 13-8
Cruise Control . . . . . . . . . . . . . . . . . 9-37
Light . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26
Messages . . . . . . . . . . . . . . . . . . . . 5-42
Cruise Control, Active . . . . . . . . . 9-39
Cupholders . . . . . . . . . . . . . . . . . . . . . 4-2
Customer Assistance . . . . . . . . . . 13-4 Offices . . . . . . . . . . . . . . . . . . . . . . . . 13-3
Text Telephone (TTY)Users . . . . . . . . . . . . . . . . . . . . . . . 13-4
Customer Information Service Publications
Ordering Information . . . . . . .13-11
Customer Satisfaction Procedure . . . . . . . . . . . . . . . . . . . . 13-1D
Damage Repair, Collision . . . . . . 13-9
Danger, Warnings, andCautions . . . . . . . . . . . . . . . . . . . . . . . . iv
Data Recorders, Event . . . . . . . 13-14
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 6-4
Defensive Driving . . . . . . . . . . . . . . . 9-5
Delayed Charging Override . . . . 9-60
Delayed Locking . . . . . . . . . . . . . . . 2-12
Display Center Stack . . . . . . . . . . . . . . . . . 5-27
Distracted Driving . . . . . . . . . . . . . . . 9-4
Dome Lamps . . . . . . . . . . . . . . . . . . . 6-6
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . 5-27
Ajar Messages . . . . . . . . . . . . . . . 5-43
Delayed Locking . . . . . . . . . . . . . . 2-12
Locks . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Power Locks . . . . . . . . . . . . . . . . . . 2-11
Drive Belt Routing, Engine . . . . . 12-4
Drive Mode Messages . . . . . . . . . 5-44
Drive Unit Electric . . . . . . . . . . . . . . . . . . . . . . . 9-28 Driver Assistance Systems . . . . 9-47
Driver Efficiency Gauge . . . . . . . 5-13
Driver Information
Center (DIC) . . . . . . . . . . . . . . . . . 5-38
Driver Mode Control . . . . . . . . . . . 9-35
Driver Selected Operating Modes . . . . . . . . . . . . . . . . . . . . . . . 9-22
Driving Assistance Systems . . . . . . . . . . 9-50
Defensive . . . . . . . . . . . . . . . . . . . . . . 9-5
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5
Hill and Mountain Roads . . . . . . . 9-9
If the Vehicle is Stuck . . . . . . . . . 9-12
Loss of Control . . . . . . . . . . . . . . . . 9-8
Off-Road Recovery . . . . . . . . . . . . 9-7
Vehicle Load Limits . . . . . . . . . . . 9-12
Wet Roads . . . . . . . . . . . . . . . . . . . . 9-8
Winter . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Driving for Better Energy Efficiency . . . . . . . 1-26, 9-2
Driving Mode
Competitive . . . . . . . . . . . . . . . . . . . 9-36
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . 8-1
ProCarManuals.com

Black plate (4,1)Cadillac ELR Owner Manual (GMNA-Localizing-U.S./Canada-7695154) -
2015 - CRC - 4/25/14
i-4 INDEX
E
Easy Entry Seat . . . . . . . . . . . . . . . . 3-3
Electric Drive Unit . . . . . . . . . . . . . 9-28
Electric Drive UnitMessages . . . . . . . . . . . . . . . . . . . . 5-44
Electric Drive Unit Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 10-25
Electric Mode . . . . . . . . . . . . . . . . . . 9-21
Electric Parking Brake . . . . . . . . . 9-30
Electric Parking Brake Light . . . 5-21
Electrical Equipment, Add-On . . . . . . . . . . . . . . . . . . . . . . 9-71
Electrical Requirements for Battery Charging . . . . . . . . . . . . . 9-66
Electrical System
Engine CompartmentFuse Block . . . . . . . . . . . . . . . . 10-29
Instrument Panel Fuse Block . . . . . . . . . 10-33, 10-35
Overload . . . . . . . . . . . . . . . . . . . 10-29
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . 10-38
Emergency OnStar
®. . . . . . . . . . . . . . . . . . . . . . 14-2 Energy Efficiency
Driving . . . . . . . . . . . . . . . . . . . 1-26, 9-2
Energy Information . . . . . . . . . . . . 5-38
Engine Air Cleaner/Filter . . . . . . . . . . . 10-13
Check and Service EngineSoon Light . . . . . . . . . . . . . . . . . . 5-17
Compartment Overview . . . . . . . 10-8
Coolant . . . . . . . . . . . . . . . . . . . . . 10-16
Coolant Temperature Warning Light . . . . . . . . . . . . . . . 5-23
Cooling System . . . . . . 10-14–10-16
Cooling System Messages . . . 5-44
Drive Belt Routing . . . . . . . . . . . . 12-4
Exhaust . . . . . . . . . . . . . . . . . . . . . . 9-27
Oil Life System . . . . . . . . . . . . . 10-12
Oil Messages . . . . . . . . . . . . . . . . . 5-44
Overheating . . . . . . . . . . . . . . . . 10-19
Pressure Light . . . . . . . . . . . . . . . . 5-24
Running While Parked . . . . . . . . 9-27
Engine Unavailable
Out of Fuel . . . . . . . . . . . . . . . . . . . 9-24
Entry Lighting . . . . . . . . . . . . . . . . . . . 6-8
Event Data Recorders . . . . . . . . 13-14
Exit Lighting . . . . . . . . . . . . . . . . . . . . 6-8 Extended Range Mode . . . . . . . . 9-22
Extender, Safety Belt . . . . . . . . . . 3-17
Exterior Lamp Controls . . . . . . . . . 6-1
Exterior Lamps Off Reminder . . . 6-3
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
F
FeaturesMemory . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Filter, Engine Air Cleaner . . . . . . . . . 10-13
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 6-4
Flashers, Hazard Warning . . . . . . 6-5
Flat Tire . . . . . . . . . . . . . . . . . . . . . . 10-61
Floor Mats . . . . . . . . . . . . . . . . . . . . 10-87
Fluid Brakes . . . . . . . . . . . . . . . . . . . . . . 10-21
Washer . . . . . . . . . . . . . . . . . . . . . 10-19
Folding Mirrors . . . . . . . . . . . . . . . . 2-18
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . 9-50
Frequency Statement
Radio . . . . . . . . . . . . . . . . . . . . . . . 13-12
ProCarManuals.com

Black plate (7,1)Cadillac ELR Owner Manual (GMNA-Localizing-U.S./Canada-7695154) -
2015 - CRC - 4/25/14
INDEX i-7
Lights (cont'd)Low Fuel Warning . . . . . . . . . . . . 5-25
Safety Belt Reminders . . . . . . . . 5-14
Security . . . . . . . . . . . . . . . . . . . . . . 5-25
Service Electric Parking
Brake . . . . . . . . . . . . . . . . . . . . . . . 5-21
StabiliTrak
®OFF . . . . . . . . . . . . . 5-23
Tire Pressure . . . . . . . . . . . . . . . . . 5-24
Traction Control System (TCS)/StabiliTrak
®. . . . . . . . . . 5-23
Traction Off . . . . . . . . . . . . . . . . . . . 5-22
Locks Automatic Door . . . . . . . . . . . . . . . 2-13
Delayed Locking . . . . . . . . . . . . . . 2-12
Door . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Lockout Protection . . . . . . . . . . . . 2-13
Power Door . . . . . . . . . . . . . . . . . . . 2-11
Loss of Control . . . . . . . . . . . . . . . . . 9-8
Low Fuel Warning Light . . . . . . . . 5-25
Lower Anchors and Tethers
for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . 3-40
Lumbar Adjustment . . . . . . . . . . . . . 3-4
Front Seats . . . . . . . . . . . . . . . . . . . . 3-4
M
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . .11-14
Maintenance and Care Additional . . . . . . . . . . . . . . . . . . . . . 11-9
Maintenance Modes . . . . . . . . . . . 9-25
Maintenance Schedule . . . . . . . . 11-2 Recommended Fluidsand Lubricants . . . . . . . . . . . . .11-12
Malfunction Indicator Lamp . . . . 5-17
Memory Features . . . . . . . . . . . . . . . 1-9
Memory Seats . . . . . . . . . . . . . . . . . . 3-6
Messages Airbag System . . . . . . . . . . . . . . . . 5-49
Brake System . . . . . . . . . . . . . . . . 5-42
Compass . . . . . . . . . . . . . . . . . . . . . 5-42
Door Ajar . . . . . . . . . . . . . . . . . . . . . 5-43
Drive Mode . . . . . . . . . . . . . . . . . . . 5-44
Electric Drive Unit . . . . . . . . . . . . 5-44
Engine Cooling System . . . . . . . 5-44
Engine Oil . . . . . . . . . . . . . . . . . . . . 5-44
Fuel System . . . . . . . . . . . . . . . . . . 5-45
Key and Lock . . . . . . . . . . . . . . . . . 5-45
Lamp . . . . . . . . . . . . . . . . . . . . . . . . . 5-46
Object Detection System . . . . . 5-46
Propulsion Power . . . . . . . . . . . . . 5-48 Messages (cont'd)
Ride Control System . . . . . . . . . . 5-49
Security . . . . . . . . . . . . . . . . . . . . . . 5-49
Service Vehicle . . . . . . . . . . . . . . . 5-50
Starting the Vehicle . . . . . . . . . . . 5-50
Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-50
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 5-41
Vehicle Reminder . . . . . . . . . . . . . 5-51
Vehicle Speed . . . . . . . . . . . . . . . . 5-51
Washer Fluid . . . . . . . . . . . . . . . . . 5-51
Window . . . . . . . . . . . . . . . . . . . . . . . 5-51
Mirrors Automatic DimmingRearview . . . . . . . . . . . . . . . . . . . . 2-18
Convex . . . . . . . . . . . . . . . . . . . . . . . 2-17
Folding . . . . . . . . . . . . . . . . . . . . . . . 2-18
Heated . . . . . . . . . . . . . . . . . . . . . . . 2-18
Power . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Tilt in Reverse . . . . . . . . . . . . . . . . 2-18
Mirrors, Interior Rearview . . . . . . 2-18
Mode Driver Control . . . . . . . . . . . . . . . . . 9-35
Electric . . . . . . . . . . . . . . . . . . . . . . . 9-21
Extended Range . . . . . . . . . . . . . . 9-22
Modes Driver Selected . . . . . . . . . . . . . . . 9-22
Maintenance . . . . . . . . . . . . . . . . . . 9-25
ProCarManuals.com
