PERIODIC MAINTENANCE AND ADJUSTMENT
6-9
62. Remove the spark plug cap.
3. Remove the spark plug as shown,
with the spark plug wrench includ-
ed in the additional tool kit, which
was handed out separately at the
purchase of the vehicle. To check the spark plu
gs
1. Check that the porcelain insulator around the center electrode on
each spark plug is a medium-to-
light tan (the ideal color when the
vehicle is ridden normally).
2. Check that all spark plugs in- stalled in the engine have the
same color.
TIPIf any spark plug shows a distinctly dif-
ferent color, the engine could be oper-
ating improperly. Do not attempt to
diagnose such problems yourself. In-
stead, have a Yamaha dealer check
the vehicle.
3. Check each spark plug for elec-trode erosion and excessive car-
bon or other deposits, and replace
it if necessary.
4. Measure the spark plug gap with a wire thickness gauge and, if nec-
essary, adjust the gap to specifi-
cation.
1. Spark plug cover
2. Bolt
1. Spark plug cap
2
1
1
1. Spark plug wrench
1
Specifie d spark plu g:
NGK/CPR7EA-91. Spark plug gapSpark plu g g ap:
0.8–0.9 mm (0.031–0.035 in)
U2DEE0E0.book Page 9 Friday, June 14, 2013 1:29 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-10
6
To install a spark plu
g
1. Clean the surface of the spark plug gasket and its mating sur-
face, and then wipe off any grime
from the spark plug threads.
2. Install the spark plug with the spark plug wrench, and then tight-
en it to the specified torque.
TIPIf a torque wrench is not available
when installing a spark plug, a good
estimate of the correct torque is 1/4–
1/2 turn past finger tight. However, the
spark plug should be tightened to the
specified torque as soon as possible.3. Install the spark plug cap.
4. Install the spark plug cover by in-stalling the bolts.
EAU47113
Engine oil an d oil filter car-
tri dgeThe engine oil level should be checked
before each ride. In addition, the oil
must be changed and the oil filter car-
tridge replaced at the intervals speci-
fied in the periodic maintenance and
lubrication chart.
To check the en gine oil level
1. Place the vehicle on a level sur- face and hold it in an upright posi-
tion. A slight tilt to the side can
result in a false reading.
2. Start the engine, warm it up for several minutes, and then turn it
off.
3. Wait a few minutes until the oil set- tles.
4. Remove the engine oil filler cap, wipe the engine oil dipstick clean,
insert it back into the oil filler hole
(without screwing it in), and then
remove it again to check the oil
level.
TIPThe engine oil should be between the
minimum and maximum level marks.
Tightenin g torque:
Spark plug: 13 Nm (1.3 m·kgf, 9.4 ft·lbf)
1. Engine oil filler cap
1. Engine oil dipstick
2. Maximum level mark
3. Minimum level mark
1
1
32
U2DEE0E0.book Page 10 Friday, June 14, 2013 1:29 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-12
6
7. Install the engine oil drain bolt and
its new gasket, and then tighten
the bolt to the specified torque.
8. Refill with the specified amount of the recommended engine oil, and
then install and tighten the oil filler
cap.
TIPBe sure to wipe off spilled oil on any
parts after the engine and exhaust sys-
tem have cooled down.NOTICE
ECA11621
In or der to prevent clutch slip-
pa ge (since the en gine oil also
lu bricates the clutch), do not
mix any chemical add itives. Do
not use oils with a diesel speci-
fication of “CD” or oils of a hi gh-
er quality than specified . In
a dd ition, do not use oils lab eled
“ENERGY CONSERVING II” or
hi gher.
 Make sure that no forei gn mate-
rial enters the crankcase.
9. Start the engine, and then let it idle for several minutes while checking
it for oil leakage. If oil is leaking,
immediately turn the engine off
and check for the cause.TIPAfter the engine is started, the engine
oil level warning light should go off if
the oil level is sufficient.NOTICE
ECA10402
If the oil level warnin g li ght flickers
or remains on even if the oil level is
correct, imme diately turn the en gine
off an d have a Yamaha dealer check
the vehicle.10. Turn the engine off, wait a few minutes until the oil settles, and
then check the oil level and cor-
rect it if necessary.
1. Torque wrench
2. Oil filter cartridgeTightenin g torque:
Oil filter cartridge: 17 Nm (1.7 m·kgf, 12 ft·lbf)
Ti ghtenin g torque:
Engine oil drain bolt: 43 Nm (4.3 m·kgf, 31 ft·lbf)
1
2
Recommen ded en gine oil:
See page 8-1.
Oil quantity: Without oil filter cartridge replace-
ment:3.70 L (3.91 US qt, 3.26 Imp.qt)
With oil filter cartridge replacement:
4.00 L (4.23 US qt, 3.52 Imp.qt)
U2DEE0E0.book Page 12 Friday, June 14, 2013 1:29 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-32
6
EAU45226
Replacing the auxiliary li ght
b ul b If the auxiliary light bulb burns out, re-
place it as follows.
1. Remove the headlight unit. (See page 6-29.)
2. Remove the auxiliary light bulb socket (together with the bulb) by
pulling it out.
3. Remove the burnt-out bulb by pulling it out. 4. Insert a new bulb into the socket.
5. Install the socket (together with
the bulb) by pushing it in.
6. Install the headlight unit.
EAU24351
Supportin g the motorcycleSince this model is not equipped with a
centerstand, follow these precautions
when removing the front and rear
wheel or performing other mainte-
nance requiring the motorcycle to
stand upright. Check that the motorcy-
cle is in a stable and level position be-
fore starting any maintenance. A
strong wooden box can be placed un-
der the engine for added stability.
To service the front wheel
1. Stabilize the rear of the motorcy- cle by using a motorcycle stand
or, if an additional motorcycle
stand is not available, by placing a
jack under the frame in front of the
rear wheel.
2. Raise the front wheel off the ground by using a motorcycle
stand.
To service the rear wheel
Raise the rear wheel off the ground by
using a motorcycle stand or, if a motor-
cycle stand is not available, by placing
1. Auxiliary light bulb socket
1
1. Auxiliary light bulb
1
U2DEE0E0.book Page 32 Friday, June 14, 2013 1:29 PM

INDEXAABS (for ABS models) ........................... 3-11
ABS warning light (for ABS models) ....... 3-4
Air filter element, replacing ................... 6-13
Auxiliary light bulb, replacing ................ 6-32BBattery .................................................. 6-26
Brake and clutch levers, checking and lubricating ........................................... 6-23
Brake and shift pedals, checking and lubricating ........................................... 6-22
Brake fluid, changing ............................ 6-20
Brake fluid level, checking .................... 6-19
Brake lever ............................................ 3-10
Brake lever free play, checking............. 6-17
Brake light switches.............................. 6-18
Brake pedal........................................... 3-11CCables, checking and lubricating ......... 6-21
Care ........................................................ 7-1
Catalytic converter ................................ 3-14
Clutch lever ........................................... 3-10
Clutch lever free play, adjusting ........... 6-16DDimmer switch ........................................ 3-8
Drive belt slack ..................................... 6-21EEngine break-in....................................... 5-3
Engine oil and oil filter cartridge ........... 6-10
Engine stop switch ................................. 3-9
Engine trouble warning light ................... 3-4FFront and rear brake pads, checking.... 6-18
Front fork, checking .............................. 6-24 Fuel ....................................................... 3-13
Fuel consumption, tips for reducing ...... 5-3
Fuel level warning light ........................... 3-4
Fuel tank breather/overflow hose ......... 3-14
Fuel tank cap ........................................ 3-12
Fuses, replacing ................................... 6-27
HHandlebar switches ................................ 3-8
Hazard switch......................................... 3-9
Headlight bulb, replacing ..................... 6-29
High beam indicator light ....................... 3-3
Horn switch ............................................ 3-9IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-18
Immobilizer system ................................ 3-1
Immobilizer system indicator light .......... 3-5
Indicator lights and warning lights ......... 3-3LLicense plate light ................................ 6-31MMain switch ............................................ 3-2
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control
system.................................................. 6-3
Matte color, caution ............................... 7-1
Model label ............................................. 9-1
Multi-function meter unit ........................ 3-5NNeutral indicator light ............................. 3-3OOil level warning light ............................. 3-3PPanel, removing and installing ............... 6-8 Parking ....................................................5-4
Part locations ..........................................2-1
Pass switch .............................................3-8
RRESET switch .........................................3-9
Rider seat ..............................................3-16SSafety information ...................................1-1
SELECT switch .......................................3-9
Shifting ....................................................5-2
Shift pedal .............................................3-10
Shock absorber assemblies,
adjusting .............................................3-17
Sidestand ..............................................3-17
Sidestand, checking and lubricating.....6-23
Spark plugs, checking ............................6-8
Specifications .........................................8-1
Starting the engine ..................................5-1
Start switch .............................................3-9
Steering, checking ................................6-25
Steering lock .........................................3-15
Storage ...................................................7-3
Supporting the motorcycle ...................6-32
Swingarm pivots, lubricating ................6-24TTail/brake light ......................................6-30
Throttle grip and cable, checking and lubricating ...........................................6-22
Throttle grip free play, checking ...........6-13
Tires ......................................................6-14
Tool kit ....................................................6-2
Troubleshooting ....................................6-33
Troubleshooting chart ...........................6-34
Turn signal indicator light........................3-3
