2014 YAMAHA VX display

Table of contents
General and important labels ........... 1
Identification numbers .................... 1
Primary Identification (PRI-ID)
number............................................ 1
Craft Identification Number (CIN) ....... 1
Engine serial number.......................... 1
Manufactured date label .................... 2
Model information ........................... 2
Builder’s plate .................................... 2
Important labels .............................. 4
Warning labels.................................... 5
Other labels ........................................ 8
Safety information ........................... 10
Limitations on who may operate
the watercraft ............................. 10
Cruising limitations ........................ 11
Operation requirements ................ 12
Recommended equipment ........... 14
Hazard information........................ 15
Watercraft characteristics ............. 15
Water-skiing .................................. 17
Safe boating rules ......................... 18
Enjoy your watercraft
responsibly ................................. 19
Description....................................... 20
Watercraft glossary ....................... 20
Location of main components ...... 21
Control function operation ............. 25
Watercraft control functions ......... 25
Remote control transmitter
(VX Deluxe / VX Cruiser)................ 25
Yamaha Security System
(VX Deluxe / VX Cruiser)................ 26
Engine stop switch .......................... 27
Engine shut-off switch .................... 27
Start switch ..................................... 27
Throttle lever .................................... 28
Steering system ............................... 28
Cooling water pilot outlet ................. 29
Water separator................................ 29
Watercraft operation ...................... 30
Watercraft operation functions ..... 30
Reverse system (VX Deluxe /
VX Cruiser) .................................... 30
Watercraft operation modes ......... 31
Low RPM Mode (VX Deluxe /
VX Cruiser) .................................... 31
Instrument operation ...................... 33
Multifunction information
center ......................................... 33
Information display ........................... 33
Equipment operation ...................... 38
Equipment..................................... 38
Seat .................................................. 38
Handgrip........................................... 39
Reboarding step (VX Deluxe /
VX Cruiser) .................................... 39
Bow eye............................................ 40
Stern eyes ........................................ 40
Cleat ................................................. 40
Storage compartments .................... 40
Fire extinguisher holder and cover ... 42
Operation and handling
requirements ................................... 44
Fuel requirements ......................... 44
Fuel................................................... 44
Engine oil requirements ................ 45
Engine oil .......................................... 45
Draining the bilge water ................ 47
Draining the bilge water on land....... 47
Draining the bilge water on water .... 47
Transporting on a trailer................ 48
First-time operation ........................ 49
Engine break-in............................. 49
Pre-operation checks ..................... 50
Pre-operation checklist .................... 50
Pre-operation check points .......... 52
Pre-launch checks ........................... 52
UF2P71E0.book Page 1 Wednesday, July 10, 2013 5:37 PM

Watercraft operation
31
EJU40001
Watercraft operation modes
EJU31418Low RPM Mode (VX Deluxe /
VX Cruiser)
The Low RPM Mode is a function that limits
the maximum engine speed to approximately
90% of the maximum engine speed in the
normal mode.
The Low RPM Mode can only be activated
and deactivated by operating the remote
control transmitter that is included with this
watercraft. (See page 25 for information on
the remote control transmitter.)
TIP:
The Low RPM Mode can only be activated
when the engine is stopped in the unlock
mode of the Yamaha Security System.
Activating and deactivating the Low RPM
Mode
Activation of the Low RPM Mode will be con-
firmed by the number of beeps when the re-
mote control transmitter is operated, and by
the “L-MODE” indicator light of the multifunc-
tion information center. (See page 33 for in-
formation on the multifunction information
center.)
TIP:
If the remote control transmitter is operated
while the multifunction information center is
in the standby state, the center performs the
initial operation, and then the setting is se-
lected.
To activate the Low RPM Mode:
Push the “L-Mode” (unlock) button on the re-
mote control transmitter for more than 4 sec-
onds. Once the beeper sounds three times
and the “SECURITY” indicator light blinks
three times, then comes on, the “L-MODE”
indicator light comes on and the Low RPM
Mode is activated.
TIP:
If the Low RPM Mode is activated immediate-
ly after the information display turns off, the
“L-MODE” indicator light will not come on.
1Remote control transmitter
Number of
beepsLow RPM Mode
operation“L-
MODE”
indicator
light
ActivatedComes
on
Deactivated Goes off
UF2P71E0.book Page 31 Wednesday, July 10, 2013 5:37 PM

Instrument operation
33
EJU31459
Multifunction information
center
The multifunction information center displays
various watercraft information.
Multifunction information center initial op-
eration
When the multifunction information center is
activated, all of the display segments come
on. After 2 seconds, the warning indicators in
the information display go off, and then the
center starts to operate normally.
If only the multifunction information center is
activated, the “WARNING” indicator light
blinks once.
TIP:
VX Deluxe / VX Cruiser: The “SECURITY” in-
dicator light also comes on as part of the ini-
tial operation.
The “SECURITY” indicator light will go off
when the engine is started.
Multifunction information center standby
state
If the multifunction information center does
not receive any operation input within 25 sec-onds after the engine stops, the center will
turn off and enter a standby state. When the
engine is started again, the displays return to
their state before the center turned off, and
then the center starts to operate normally.
EJU35025Information display
The information display shows watercraft op-
erating conditions.
EJU31504Speedometer
The speedometer shows the watercraft
speed against water.
By switching the display units, the speed can
be shown in kilometers per hour “km/h” or
miles per hour “mph”.
1“SECURITY” indicator light (VX Deluxe /
VX Cruiser)
2Select button
3Information display
4“L-MODE” indicator light (VX Deluxe /
VX Cruiser)
5“WARNING” indicator light
21345
1Tachometer
2Speedometer
3Hour meter/voltmeter
4Fuel level meter
5Check engine warning indicator
6Engine overheat warning indicator
7Oil pressure warning indicator
8Fuel level warning indicator
1234
8765
UF2P71E0.book Page 33 Wednesday, July 10, 2013 5:37 PM

Instrument operation
34
TIP:
“mph” is selected as the display unit at the
Yamaha factory.
To switch the speedometer display units:
Push the select button for at least 1 second,
within 10 seconds after the multifunction in-
formation center is activated. The speedom-
eter display changes.
EJU31464Tachometer
The tachometer shows the engine speed.The outer numbers × 1000 r/min and display
segments on the meter show the engine
speed.
EJU31556Hour meter/voltmeter
The hour meter/voltmeter has both an hour
meter function and a voltmeter function. By
switching the meter, it can be used as either
an hour meter or a voltmeter.
TIP:
The hour meter is selected at the Yamaha
factory.
Hour meter
The hour meter shows the total number of
hours that the engine has been running since
the watercraft was new.
TIP:
The elapsed time will be kept even if the bat-
tery terminals have been disconnected.
1Speedometer
1Speedometer
2Select button
1
1
2
1Tachometer
1Hour meter/voltmeter
1
1
UF2P71E0.book Page 34 Wednesday, July 10, 2013 5:37 PM

Instrument operation
35
To switch to the hour meter from the voltme-
ter:
Push the select button for at least 1 second
after the multifunction information center is
activated for more than 10 seconds. The dis-
play switches to the hour meter from the volt-
meter.
Voltmeter
The voltmeter shows the battery voltage.
When the battery voltage is normal, the volt-
meter displays approximately 12 volts.
If the battery voltage has dropped significant-
ly, “LO” is displayed on the voltmeter. If the
battery voltage has risen significantly, “HI” is
displayed. If “LO” or “HI” is displayed, imme-
diately return to shore and have a Yamaha
dealer service the watercraft.
To switch to the voltmeter from the hour me-
ter:
Push the select button for at least 1 second
after the multifunction information center is
activated for more than 10 seconds. The dis-play switches to the voltmeter from the hour
meter.
EJU31515Fuel level meter
The fuel level meter shows the amount of fuel
remaining in the fuel tank. The amount of re-
maining fuel is shown using eight display
segments, which disappear two at a time as
the fuel level decreases.
TIP:
The accuracy of the fuel level meter varies
depending on the operating conditions. Use
this function as a reference only.
EJU41972Fuel level warning
If the fuel remaining in the fuel tank drops to
about 11 L (2.9 US gal, 2.4 Imp.gal), the low-
est two fuel level segments, the fuel level
warning indicator, and the “WARNING” indi-
1Hour meter
2Select button
1
2
1Vo l t m et e r
2Select button
1Fuel level meter
1
2
1
UF2P71E0.book Page 35 Wednesday, July 10, 2013 5:37 PM

Index
A
After removing the watercraft from the
water ..................................................... 71
B
Battery care.............................................. 73
Battery checks ......................................... 53
Battery, jumping ....................................... 86
Beaching and docking the watercraft ...... 70
Beverage holder ....................................... 42
Bilge water check..................................... 53
Bilge water, draining ................................ 47
Bilge water, draining on land ................... 47
Bilge water, draining on water ................. 47
Boarding alone ......................................... 65
Boarding and starting off from a dock ..... 69
Boarding the watercraft ........................... 65
Boarding with passenger(s) ..................... 66
Bow eye ................................................... 40
Bow storage compartment ...................... 40
Builder’s plate ............................................ 2
C
Capsized watercraft ................................. 69
Check engine warning ............................. 37
Cleaning ................................................... 76
Cleaning the watercraft ............................ 73
Cleat ......................................................... 40
Cooling water pilot outlet ......................... 29
Cooling water pilot outlet check .............. 58
Craft Identification Number (CIN)............... 1
Cruising limitations................................... 11
E
Emergency procedures ............................ 85
Engine break-in ........................................ 49
Engine compartment check ..................... 52
Engine idling speed check ....................... 58
Engine oil ................................................. 45
Engine oil and oil filter .............................. 80
Engine oil level check............................... 52
Engine oil requirements ........................... 45
Engine overheat warning ......................... 36
Engine serial number ................................. 1
Engine shut-off cord (lanyard) check ....... 55
Engine shut-off switch ............................. 27
Engine stop switch................................... 27
Engine unit check..................................... 52Enjoy your watercraft responsibly ............ 19
Equipment ................................................ 38
F
Fire extinguisher check ............................ 57
Fire extinguisher holder and cover........... 42
Fire extinguisher holder, cover, and
band checks ......................................... 56
Flushing the cooling water passages....... 72
Fuel .......................................................... 44
Fuel level check........................................ 52
Fuel level meter ........................................ 35
Fuel level warning..................................... 35
Fuel requirements .................................... 44
Fuel system checks ................................. 52
Fuses, replacing ....................................... 86
G
Getting to know your watercraft .............. 59
Glossary, watercraft ................................. 20
Glove compartment ................................. 41
H
Handgrip .................................................. 39
Hazard information................................... 15
Hood check .............................................. 58
Hour meter/voltmeter ............................... 34
Hull and deck check ................................ 57
I
Identification numbers ............................... 1
Information display................................... 33
J
Jet intake and impeller, cleaning.............. 85
Jet intake checks ..................................... 57
Jumper cables, connecting ...................... 86
L
Labels, important ....................................... 4
Labels, other .............................................. 8
Labels, warning .......................................... 5
Launching the watercraft ......................... 60
Learning to operate your watercraft......... 59
Leaving the watercraft.............................. 61
Limitations on who may operate the
watercraft .............................................. 10
Long-term storage ................................... 76
Low RPM Mode (VX Deluxe /
VX Cruiser) ............................................ 31
Lubrication ............................................... 76
UF2P71E0.book Page 1 Wednesday, July 10, 2013 5:37 PM
