1. Jumper cable negative lead5. Start the engine. (Refer to “Starting theengine” on page 6-2.)
6. After the engine starts, disconnect the negative lead of the jumper cable from
the frame and charged battery, and then
disconnect the positive lead of the jumper
cable from the charged battery and the
battery in the vehicle.
7. Install the hood.
5B410023Fuse replacementThe main fuse, the fuel injection system fuse,
the EPS fuse, and the fuse box are located
under the hood.1. Fuse box 2. Main fuse
3. EPS fuse
4. Fuel injection system fuse
5. Fuel injection system spare fuse
1
1 3
2
4
5
