PERIODIC MAINTENANCE AND ADJUSTMENT
6-23
6
EAU25862
TroubleshootingAlthough Yamaha scooters receive a
thorough inspection before shipment
from the factory, trouble may occur
during operation. Any problem in the
fuel, compression, or ignition systems,
for example, can cause poor starting
and loss of power.
The following troubleshooting chart
represents a quick and easy procedure
for checking these vital systems your-
self. However, should your scooter re-
quire any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the scooter prop-
erly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look
like Yamaha parts, but they are often
inferior, have a shorter service life and
can lead to expensive repair bills.
WARNING
EWA15142
When checking the fuel system, do
not smoke, and make sure there are
no open flames or sparks in the ar-
ea, including pilot lights from waterheaters or furnaces. Gasoline or
gasoline vapors can ignite or ex-
plode, causing severe injury or prop-
erty damage.
U1S0E2E0.book Page 23 Thursday, July 25, 2013 6:53 PM

SCOOTER CARE AND STORAGE
7-3
7 windshield which does not affect your
visibility and which cannot be easily
recognized.
After cleaning
1. Dry the scooter with a chamois or
an absorbing cloth.
2. Use a chrome polish to shine
chrome, aluminum and stainless-
steel parts, including the exhaust
system. (Even the thermally in-
duced discoloring of stainless-
steel exhaust systems can be re-
moved through polishing.)
3. To prevent corrosion, it is recom-
mended to apply a corrosion pro-
tection spray on all metal,
including chrome- and nickel-plat-
ed, surfaces.
4. Use spray oil as a universal clean-
er to remove any remaining dirt.
5. Touch up minor paint damage
caused by stones, etc.
6. Wax all painted surfaces.
7. Let the scooter dry completely be-
fore storing or covering it.
WARNING
EWA10943
Contaminants on the brakes or tires
can cause loss of control.
Make sure that there is no oil or
wax on the brakes or tires. If
necessary, clean the brake
discs and brake linings with a
regular brake disc cleaner or
acetone, and wash the tires with
warm water and a mild deter-
gent.
Before operating the scooter
test its braking performance
and cornering behavior.NOTICE
ECA10801
Apply spray oil and wax spar-
ingly and make sure to wipe off
any excess.
Never apply oil or wax to any
rubber and plastic parts, but
treat them with a suitable care
product.
Avoid using abrasive polishing
compounds as they will wear
away the paint.
TIPConsult a Yamaha dealer for ad-
vice on what products to use.
Washing, rainy weather or humid
climates can cause the headlight
lens to fog. Turning the headlight
on for a short period of time will
help remove the moisture from the
lens.
U1S0E2E0.book Page 3 Thursday, July 25, 2013 6:53 PM

SPECIFICATIONS
8-2
8
(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measured on cold
tires):Loading condition:
0–90 kg (0–198 lb)
Front:
150 kPa (1.50 kgf/cm², 22 psi)
Rear:
160 kPa (1.60 kgf/cm², 23 psi)
Loading condition:
90–184 kg (198–406 lb)
Front:
150 kPa (1.50 kgf/cm², 22 psi)
Rear:
160 kPa (1.60 kgf/cm², 23 psi)Front wheel:Wheel type:
Cast wheel
Rim size:
12xMT3.50Rear wheel:Wheel type:
Cast wheel
Rim size:
12xMT3.50Front brake:Type:
Single disc brake
Operation:
Right hand operation
Specified brake fluid:
DOT 3 or 4
Rear brake:Type:
Drum brake
Operation:
Left hand operationFront suspension:Type:
Telescopic fork
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
120.0 mm (4.72 in)Rear suspension:Type:
Unit swing
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
100.0 mm (3.94 in)Electrical system:Ignition system:
DC CDI
Charging system:
AC magnetoBattery:Model:
CB4L-B (GS), YB4L-B (YUASA)
Voltage, capacity:
12 V, 4.0 AhHeadlight:Bulb type:
Incandescence
Bulb voltage, wattage × quantity:Headlight:
12 V, 35.0 W/35.0 W × 1
Tail/brake light:
12 V, 5.0 W/21.0 W × 1
Front turn signal light:
12 V, 10.0 W × 2
Rear turn signal light:
12 V, 10.0 W × 2
Meter lighting:
LED
High beam indicator light:
LED
Oil level warning light:
LED
Turn signal indicator light:
LED
Fuel level warning light:
LEDFuses:Main fuse:
7.5 A
U1S0E2E0.book Page 2 Thursday, July 25, 2013 6:53 PM

10-1
10
INDEX
22-stroke engine oil .................................. 3-7AAcceleration and deceleration ................ 5-3
Air filter element, cleaning ...................... 6-9
Anti-theft device housing ....................... 3-8BBattery .................................................. 6-19
Brake fluid, changing............................ 6-15
Brake fluid level, checking.................... 6-14
Brake lever, front .................................... 3-4
Brake lever, rear ..................................... 3-4
Brake levers, lubricating ....................... 6-16
Brake pads and shoes, checking ......... 6-14
Braking ................................................... 5-3CCables, checking and lubricating ......... 6-16
Carburetor,adjusting............................. 6-10
Care ........................................................ 7-1
Catalytic converter ................................. 3-6
Centerstand, checking and
lubricating........................................... 6-17
Cowling and panel, removing and
installing ............................................... 6-6DDimmer switch........................................ 3-4EEngine break-in ...................................... 5-4
Engine, starting a warm.......................... 5-2FFinal transmission oil .............................. 6-8
Front brake lever free play, checking ... 6-13
Front fork, checking ............................. 6-18
Fuel ......................................................... 3-5Fuel and 2-stroke engine oil tank
caps ..................................................... 3-5
Fuel consumption, tips for reducing ...... 5-4
Fuel level warning light........................... 3-2
Fuse, replacing..................................... 6-21
HHandlebar switches ............................... 3-3
Headlight bulb, replacing ..................... 6-21
High beam indicator light ....................... 3-2
Horn switch ............................................ 3-4IIdentification numbers ........................... 9-1
Indicator lights and warning lights ......... 3-2KKickstarter .............................................. 3-8LLuggage hook ........................................ 3-9MMain switch/steering lock ...................... 3-1
Maintenance and lubrication, periodic... 6-3
Maintenance, emission control
system ................................................. 6-2
Matte color, caution ............................... 7-1
Model label............................................. 9-1OOil level warning light ............................. 3-2PParking ................................................... 5-5
Part locations ......................................... 2-1RRear brake lever free play, adjusting.... 6-13SSafe-riding points................................... 1-5
Safety information .................................. 1-1Seat......................................................... 3-8
Spark plug, checking .............................. 6-7
Specifications ......................................... 8-1
Speedometer unit ................................... 3-3
Starter (choke) lever................................ 3-7
Starting a cold engine............................. 5-1
Starting off .............................................. 5-2
Start switch ............................................. 3-4
Steering, checking ................................ 6-18
Storage ................................................... 7-4
TTail/brake light bulb, replacing ............. 6-22
Throttle grip and cable, checking and
lubricating ........................................... 6-16
Throttle grip free play, checking ........... 6-10
Tires ...................................................... 6-10
Troubleshooting .................................... 6-23
Troubleshooting chart........................... 6-24
Turn signal indicator light ....................... 3-2
Turn signal light bulb, replacing............ 6-22
Turn signal switch ................................... 3-4VVehicle identification number ................. 9-1WWheel bearings, checking .................... 6-19
Wheels .................................................. 6-12
