2014 VOLKSWAGEN PASSAT SEL PREMIUM length

Check all wiper blades regularly. Wiper blades that grab and squeak must be replaced if worn or
damaged and cleaned if dirty ⇒ .
Replace worn or damaged wiper blades immediately. Replacement blades may be purchased from any authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Lifting and tilting windshield wiper arms
Move the wiper arms to the service position before lifting them away from the windshield Windshield wiper and washer.
It is not possible to lift the wiper arms away from the windshield when they are not in the service position.
When lifting or replacing a wiper blade on a window, grip it only by its mounting and not by the blade itself.
Cleaning the wiper blades
x Lift the wiper arm(s) away from the windshield.
x Using a soft cloth, carefully remove dust and dirt from the wiper blades.
x If the blades are very dirty, carefully clean them with a sponge or cloth ⇒ .
x Carefully fold the wiper arm back down onto the windshield.
Changing wiper blades
x Lift the wiper arm away from the windshield.
x Press and hold the release button ⇒ fig. 187 (1).
x While lifting the wiper blade in the direction of the wiper arm, pull off the wiper blade in the direction of the arrow. This may require moderate force.
x Install a new wiper blade of same length and type onto the wiper arm by pushing in the opposite direction of the arrow until it latches.
x Carefully fold the wiper arm back down onto the windshield.
WARNING
Worn or dirty wiper blades reduce visibility and increase the risk of accidents and severe injuries.
x Always change wiper blades if they are damaged or worn, and if they cannot clean the windows sufficiently.
NOTICE
x Damaged or dirty wiper blades can scratch the windshield.
x Solvents, abrasive sponges and sharp-edged objects will damage the graphite coating on the wiper blades.
x Do not clean the windows with gasoline, nail polish remover, paint thinner or similar fluids.
x To help prevent damage to the engine hood and the windshield wiper arms, lift the wiper arms away from the windshield only when they are in the service position.
Waxing and polishing vehicle paint

363
Loosening the wheel bolts
x Push the lug wrench over the wheel bolt all the way ⇒ fig. 208.
x Holding the lug wrench at the end, loosen the wheel bolt by turning it counterclockwise about 1
complete turn (360°) ⇒ .
Loosening the anti-theft wheel bolt (where applicable)
x Take the adapter for the anti-theft wheel bolt out of the vehicle tool kit.
x Push the adapter all the way over the anti-theft wheel bolt.
x Slide the lug wrench onto the adapter until it stops.
x Holding the lug wrench at the end, loosen the wheel bolt by turning it counterclockwise about 1
complete turn (360°) ⇒ .
Important information regarding wheel bolts
The design of rims and wheel bolts is matched to the factory-installed wheels. If different wheels are installed, wheel bolts with the right length and bolt head shape must be used. The attachment of the wheels and function of the brake system depend on this.
It may not be possible to use wheel bolts from different vehicles of the same model.
Where applicable: On a wheel with a wheel cover, the anti-theft wheel bolt must be installed at points
⇒ fig. 209 (2) or (3) in relation to the position of the tire valve (1). Otherwise, the wheel cover cannot be installed.
Wheel bolt tightening torque
Correctly tightened bolts for steel and alloy wheel rims should have a torque of 103 ft-lbs. (140 Nm). After changing a wheel, have the wheel bolt tightening torque checked right away with an accurate torque wrench.
Before you check the tightening torque, replace corroded and difficult-to-turn wheel bolts and clean the threads in the wheel hub.
Never grease or oil the wheel bolts and the threads in the wheel hubs. The bolts can come loose while driving if greased or oiled, even if tightened to the required torque.
WARNING
Improperly tightened wheel bolts can come loose while driving and cause you to lose control over the vehicle, resulting in accidents and serious injuries.
x Only use wheel bolts that belong your vehicle and to the wheel being installed.
x Never use different wheel bolts.
x Wheel bolts and wheel hub threads must always be clean, easy-to-turn and free of oil and grease.
x Only use the lug wrench that is supplied with the vehicle to loosen the wheel bolts.
x Loosen the wheel bolts only about 1 turn before lifting the vehicle with the jack.
x Never grease or oil the wheel bolts and the threads in the wheel hubs. The bolts can come loose while driving if greased or oiled, even if tightened to the required torque.
x Never loosen bolted connections on wheel rims with bolted rim rings.
x If the wheel bolts are not tightened to the proper torque, the wheel can come off the vehicle when it is moving. Extremely high torque can damage the wheel bolts and/or their threads.

Abbreviations
Abbreviation Meaning
5S manual 5-speed manual transmission
6S automatic 6-speed automatic transmission
6S manual 6-speed manual transmission
ABS Anti-lock Brake System
AFS Adaptive Front Lighting System
AKI Anti-Knock Index
ANSI American National Standards Institute
ASR Anti-Slip Regulation
ATA Anti-Theft Alarm system
BAS Brake Assist System
ccm Cubic centimeters - unit of measure for engine displacement
CCS Cruise Control System
CID Cubic inches - unit of measure for engine displacement
cm Centimeter - metric unit of measure for length
CO2 Carbon dioxide
DIN Deutsches Institut für Normung (German Institute for Standardization)
DPF Diesel Particulate Filter
DRL Daytime running lights
DSG® DSG® Direct Shift Gearbox automatic transmission
EDL Electronic Differential Lock
EN European Norm
EPC Engine control (Electronic Power Control)
ESC Electronic Stability Control
FSI Fuel Stratified Injection
g/km Generated carbon monoxide amount in grams per kilometer driven
GAWR Gross Axle Weight Rating
GVWR Gross Vehicle Weight Rating
HID High Intensity Discharge headlights (Xenon)
hp Horsepower - unit to measure engine power
kg Kilogram - metric unit for weight
kN Kilonewton - a measure of force
kp Kilopond - a measure of force
kPa Kilopascal - unit of measure for tire pressure
kW Kilowatt - engine rating

LED Light Emitting Diode
m Meter, metric unit of measure for length
MFI Multi-Function Indicator
Nm Newton meter - engine torque unit
RON Research Octane Number, measurement of anti-knock resistance of gasoline
rpm Engine revolutions per minute (engine speed)
SAE Society of Automotive Engineers
SRE Manifold injection
TDI® Turbocharged Direct Injection (Turbocharged diesel engine with direct fuel injection)
XDL Extensions of the Electronic Differential Lock system.
