2014 VOLKSWAGEN PASSAT CC window

Rear view

Fig. 3 Vehicle rear overview.
Key to ⇒ fig. 3:
(1) Rear window
– Rear window defroster
– Rear window antenna
(2) High-mounted brake light
(3) Taillights (on both left and right) ,
(4) Volkswagen emblem. Area for:
– Luggage compartment release
– Rear Assist camera (if equipped)
(5) Threaded hole for the rear towing eye (behind cover)
(6) Roof antenna
(7) Park Distance Control (PDC) sensors (on both left and right, if equipped)
(8) Area for attaching a trailer hitch

Lower center console

Fig. 7 Overview of the lower center console.
Key to ⇒ fig. 7:
(1) Lever for:
– Manual transmission
– Automatic transmission
(2) Storage compartment with cup holders in the center console
(3) Storage compartment in the center armrest
(4) Buttons for:
– Starter button (vehicles with Keyless Access locking and starting system)
– Electronic parking brake G
– Anti-slip regulation (ASR) m
– Rear window sunshade j
– Park Distance Control (ParkPilot) '
(5) Storage compartment
– with 12 Volt socket

Back
– Window op. (window operation)
Off
All
Driver
Back
– Mirror down (on/off)
– Mirror adjust
Individually
Both mirrors
Back
– Factory setting
– Back
▪ Lights & Vision
– Coming Home
– Leaving Home
– Footwell light
– Conv. turn sig. (convenience turn signal)
– Factory setting
– Back
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
▪ Snow tires (winter tires)
– On
– + 5 mph
– - 5 mph
– Back
▪ Compass (vehicles without navigation system)
– Zone
– Calibrate
– Back
▪ Units
– Temperature
– Consump./dist.
– Air pressure
– Back
▪ Service
– Info
– Back
▪ Factory setting

Convenience menu Function
Unlock doors
Doors are unlocked as follows depending on the option selected: – All doors: Pushing the unlock button 0 on the remote control vehicle key unlocks all doors and the luggage com-partment lid. – Single door: Pushing the unlock button 0 on the remote control vehicle key unlocks only the driver door. To unlock all doors and the luggage compartment, push the unlock button 0 on the key a second time within about 5 seconds. On vehicles with Keyless Access, touching the sensor sur-face of the door handle on the side where the valid vehicle key is located unlocks the respective door. – Vehicle side: Pushing the unlock button 0 on the remote control vehicle key unlocks the doors on the driver side of the vehicle. On vehicles with Keyless Access, touching the sensor sur-face of a door handle on the side where the valid vehicle key is located unlocks the doors on that side of the vehicle.
Window op.
Off Power window settings when unlocking/locking the driver door. All
Driver
Back The display switches back to the Convenience menu.
Mirror down Tilts passenger mirror down when backing up so you can see the curb. Feature only available on vehicles equipped with memory seats.
Mirror adjust IndividuallyBoth outside mirrors are adjusted separately.
Both mirrorsThe front passenger outside mirror is adjusted at the same time as the driver outside mirror.
Back The display returns to the Convenience menu.
Factory setting Resets the features in the Convenience submenu back to the factory set-tings.
Back The display returns to the Settings menu.
Applicable only in Canada
Convenience submenu

Convenience menu Function

Auto unlock
You can enable or disable Auto unlock. If Auto unlock is enabled (box checked), the doors automatically unlock when you switch off the ignition and open a door from inside the vehicle. On vehicles with automatic transmission, the doors will also unlock when the selector lever is in Park (P) and the ignition is switched off. Auto unlock works only if the vehicle has been automatically locked after reaching a speed of 10 mph (15 km/h). Auto unlock always unlocks all the doors.
Unlock doors
Doors are unlocked as follows depending on the option selected: – All doors: Pushing the unlock button 0 on the remote control vehicle key unlocks all doors and the luggage com-partment lid. – Single door: Pushing the unlock button 0 on the remote control vehicle key unlocks only the driver door. To unlock all doors and the luggage compartment, push the unlock button 0 on the key a second time within about 5 seconds. On vehicles with Keyless Access, touching the sensor sur-face of the door handle on the side where the valid vehicle key is located unlocks the respective door . – Vehicle side: Pushing the unlock button 0 on the re-mote control vehicle key unlocks the doors on the driver side of the vehicle. On vehicles with Keyless Access, touching the sensor sur-face of a door handle on the side where the valid vehicle key is located unlocks the doors on that side of the vehicle.
Window op.
Off Power window settings when unlocking/locking the driver door. All
Driver
Back The display switches back to the Convenience menu.
Mirror down Tilts passenger mirror down when backing up so you can see the curb. Feature only available on vehicles equipped with memory seats.
Mirror adjust IndividuallyBoth outside mirrors are adjusted separately.
Both mirrorsThe front passenger outside mirror is adjusted at the same time as the driver outside mirror.
Back The display returns to the Convenience menu.
Factory setting Resets the features in the Convenience submenu back to the factory set-tings.
Back The display returns to the Settings menu.
Lights & Vision submenu

Function Using the buttons on the remote control vehicle key
⇒ fig. 21
Unlock the vehicle. Press the 0 button.
Lock the vehicle. Press the 1 button.
Unlock the luggage compartment lid. Press and hold the q button. The luggage compartment lid
opens automatically ⇒ page 67.
Note: Depending on the settings for the power locking system in the Convenience submenu, it may be necessary to press the 0button on the remote control vehicle key twice to unlock all doors and the luggage compartment lid, Volkswagen Information System.
The vehicle key unlocks or locks the vehicle only when the battery in the remote control vehicle key has enough power, and the remote control vehicle key is within a few yards/meters of the vehicle.
x All turn signals flash once and the horn beeps once to confirm that the vehicle has been locked. The horn beep can be disabled by deactivating the ATA confirm feature in the Convenience submenu, Volkswagen Information System.
x All turn signals flash twice to confirm that the vehicle has been unlocked.
If the turn signals do not flash to confirm locking, one or more doors or the luggage compartment lid is not locked.
If the driver door is open, the vehicle cannot be locked with the remote control vehicle key.
If the vehicle was unlocked with the remote control vehicle key and the door or the luggage compartment lid has not been opened within a few seconds, the vehicle is automatically locked again. This feature helps prevent you from leaving the vehicle unlocked unintentionally.
NOTICE
Check to make sure that the windows go down slightly when you unlock the vehicle. Otherwise the windows and seals could be damaged when opening the door.
Unlocking or locking the vehicle from the inside

Fig. 22 In the vehicle doors: Power locking button.

Power windows

For one-touch opening: Press the switch for the window down briefly as far as it goes.
For one-touch closing: Pull the switch for the window up briefly as far as it goes.
Stopping automatic movement: Pull/press the switch again.
Reactivating the one-touch feature
If the vehicle battery is disconnected or dead and the windows are not completely closed, the one-touch feature will not work and must be reactivated:
x Switch on the ignition.
x Close all windows and doors.
x Pull up the switch for the respective window and hold it for at least 2 seconds in this position.
x Release the switch, pull up and hold again. The one-touch feature is now reactivated.
The one-touch feature can be reactivated for one or more windows at the same time.
WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children, remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power windows for several minutes after the ignition is switched off as long as the driver or front passenger door has not been opened.
x Always use the safety switch when children are in the back seat to disable the rear power windows and keep them from being opened and closed.
NOTICE
The windows must go down slightly when you unlock the vehicle. Otherwise the windows and seals could be damaged when opening the doors.
If the power windows malfunction, the one-touch feature, as well as pinch protection may not work properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right away.
Power window pinch protection
