2014 VOLKSWAGEN PASSAT CC Engine

Tire inflation pressure label
A tire inflation pressure label is on the driver door jamb, Tires and wheels.
Fuel grade sticker
An information sticker listing the correct fuel grade for your vehicle, Refueling.
Engine data

x Always be careful when you enter a driveway or drive up or down steep ramps or over curbs or other obstacles. Parts of the vehicle close to the ground may be damaged (such as bumper covers, spoilers, and parts of the engine, suspension, and exhaust systems).

Unlocking and locking the luggage compartment lid
If the vehicle is locked and a valid remote control vehicle key is within range ⇒ fig. 23 A of the luggage compartment lid, it unlocks automatically when opened.
Open and close the luggage compartment lid as you would a standard luggage compartment lid, Luggage compartment lid
The luggage compartment lid locks automatically when it is closed except in the following situations:
x The vehicle is completely unlocked.
x When an authorized remote control vehicle key is inside the vehicle.
Sensor-controlled luggage compartment lid opener (Easy Open)
If your vehicle has Keyless Access, it may also be equipped with the Easy Open feature.
When a valid vehicle key is within the opening range of the luggage compartment lid A, the luggage compartment lid can be unlocked and opened by moving your foot within the sensor’s range B below the rear bumper.
x Switch off the ignition.
x Stand in front of the middle of the rear bumper.
x Quickly move your foot and shin as close to the bumper as possible. Your shin must be in the upper part of the sensor’s range and your foot in the lower part B (1).
x Quickly move your shin out of range B (2). The luggage compartment lid opens automatically.
If the luggage compartment lid does not open, wait a few seconds and try again.
The high-mounted brake light flashes once to show that the Easy Open feature is opening the luggage compartment lid.
The luggage compartment lid locks automatically after closing if the vehicle was locked before and a valid vehicle key is not inside the vehicle.
Easy Open may not work properly or at all in the following situations (examples):
x If the rear bumper is very dirty.
x If the rear bumper has salty water on it after driving on salted roads.
x If a trailer hitch has been retrofit on the vehicle.
Easy Open may be automatically deactivated in heavy rain to help prevent unintentional deployment caused by water running down the vehicle, for example.
The Easy Open feature may be turned on and off in the Settings – Convenience menu, Volkswagen Information System.
Locking with a second vehicle key
If a remote control vehicle key is inside the passenger compartment, the vehicle can be locked from the outside only if a second valid remote control vehicle key is within range.
When the vehicle is locked from the outside, the keyless go (starting) function of any keys left in the passenger compartment will be deactivated, Starting and stopping the engine. A key that was inside the vehicle when it was locked from the outside is reactivated by pressing the 0 button on the
deactivated key ⇒ fig. 21.
Automatic deactivation of sensors
If the vehicle has not been unlocked or locked for a longer period of time, the proximity sensors in the passenger door are automatically deactivated.
If a sensor on the door handle of a locked vehicle is activated too often, for instance by a bush or hedge that rubs against the vehicle, the sensors in the door handle on that side of the vehicle are switched off for a short time.
The door handle sensors become active again if one of the following events occurs:

The power locks and the closing system work like the standard unlocking and locking system. Only the way that the systems are operated is different.
All turn signals flash twice to confirm that the vehicle has been unlocked and once to confirm that it has been locked.
If the vehicle was unlocked and within the next few seconds neither a door nor the luggage compartment lid has been opened, the vehicle is automatically locked again.
Unlocking and opening doors (Keyless Entry)
x Grasp the door handle of the driver or front passenger door so that you touch the unlocking sensor surface (A).
x Open the door.
Closing and locking doors (Keyless Exit)
x Switch the ignition off.
x Close the driver door.
x Touch the sensor surface in the door handle on the driver or front passenger door (B). The vehicle is locked. The door being locked must be closed.
Unlocking and locking the luggage compartment lid
If the vehicle is locked and a valid remote control vehicle key is within range ⇒ fig. 25 of the luggage compartment lid, it unlocks automatically when opened.
Open and close the luggage compartment lid as you would a standard luggage compartment lid, Luggage compartment lid
The luggage compartment lid locks automatically when it is closed except in the following situations:
x The vehicle is completely unlocked.
x When an authorized remote control vehicle key is inside the vehicle.
Locking with a second vehicle key
If a remote control vehicle key is inside the passenger compartment, the vehicle can be locked from the outside only if a second valid remote control vehicle key is within range.
When the vehicle is locked from the outside, the keyless go (starting) function of any keys left in the passenger compartment will be deactivated , Starting and stopping the engine. A key that was inside the vehicle when it was locked from the outside is reactivated by pressing the 0 button on the
deactivated key ⇒ fig. 21.
Automatic deactivation of sensors
If the vehicle has not been unlocked or locked for a longer period of time, the proximity sensors in the passenger door are automatically deactivated.
If a sensor on the door handle of a locked vehicle is activated too often, for instance by a bush or hedge that rubs against the vehicle, the sensors in the door handle on that side of the vehicle are switched off for a short time.
The door handle sensors become active again if one of the following events occurs:
x A short time has passed.
x OR: The vehicle is unlocked using the 0 button in the remote control vehicle key.
x OR: The luggage compartment lid is opened.
x OR: The vehicle is mechanically unlocked with the emergency key.
Convenience features
The settings in the Settings – Convenience menu, Volkswagen Information System determine which doors open when the door handle unlocking surface is grasped.

WARNING
Careless or unsupervised use of the sunroof can cause serious injuries.
x Always make sure that no one is in the way of the power sunroof when it is closing.
x Always take all vehicle keys with you when leaving the vehicle.
x Never leave children or persons requiring assistance unattended in the vehicle, especially if they have access to the vehicle key. Unsupervised use of the remote control vehicle key can lock the vehicle, start the engine, switch on the ignition and operate the sunroof.
x The sunroof can still be opened or closed for a short period after the ignition has been switched off, as long as the driver or passenger door is not opened.
WARNING
Without pinch protection, the power sunroof will close with enough force to cause serious personal injury.
x Always be careful when closing the power sunroof.
x Always make sure that no one is in the way when overriding the pinch protection to close the power sunroof!
x Pinch protection cannot prevent fingers or other parts of the body from being pressed against the edge of the roof; injuries may result.
If the power sunroof malfunctions, pinch protection may not function properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.

Starting the engine may stop seat adjustment.
When entering and exiting the vehicle, be careful not to come into contact with any switches that could change the seat adjustment.
Adjusting the front and rear head restraints

Fig. 43 Adjusting the front head restraints.

Fig. 44 Adjusting the rear head restraints.

Lights up Possible cause Proper response

One or more driving lights not working or cornering light malfunction. Replace burned out bulb
Cornering light malfunction. If all light bulbs are OK, see an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Adaptive Front Lighting System (AFS) malfunction.
Fog lights switched on (indicator light on the headlight switch). Refer to 2014 owners manual



Left or right turn signal. The indicator light blinks twice as fast if a turn signal is not working on the vehicle or the trailer.
Check the turn signals on the vehicle and the trailer.
 Daytime running lights (DRL) on. Refer to 2014 owners manual
$2,
 High beams switched on or headlight flashers in use. Refer to 2014 owners manual

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, stop the engine, turn on the emergency flashers, and use other warning devices to warn approaching traffic.
x Never park the vehicle in areas where the hot catalytic converter and exhaust system can come into contact with dry grass, brush, spilled fuel, oil, or other material that can catch fire.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
High Intensity Discharge (HID) headlights provide bright, uniform lighting to help you see and be seen. The light comes from an electric arc between two electrodes in the gas-filled bulb. Over time, the electrodes can wear down and the gap between them will get wider. The HID lamp’s control unit then increases the voltage to keep the arc’s brightness constant. However, the commonly called “Xenon” bulbs will also ultimately burn out. Before they burn out, HID lamps can flicker. A message will then appear in the MFI. This is your reminder to see an authorized Volkswagen dealer or an authorized Volkswagen Service facility to check the headlights.

NOTICE
To help prevent damage to the wiper blades and the wiper motor when it is cold outside, always make sure that blades are not frozen to the windshield before operating the wipers. Using the service position can be helpful in cold weather so the wipers do not freeze to the windshield, Windshield wiper service position.
x If the ignition is switched off while the wipers are running, the wipers will continue at the same wiping speed when the ignition is switched on again. Frost, ice, snow, leaves, and other objects on the windshield can damage the wipers and the wiper motor.
x Remove snow and ice from the wipers before you begin driving.
x If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends using a deicing spray.
NOTICE
Never switch on the windshield wipers when the windshield is dry because the windshield can be scratched.
The windshield wipers work only if the ignition is switched on and the engine hood is closed. The windshield wipers turn off automatically when the engine hood is opened.
The intermittent wiping for the front windshield depends on the driving speed. The higher the speed, the faster the wipers move.
If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends using a deicing spray.
Windshield wiper functions
