2014 VOLKSWAGEN JETTA HYBRID mirror

Side view

Fig. 1 Vehicle side overview.
Key to fig. 1:
(1) Fuel filler flap
(2) Roof antenna
(3) Outside door handles
(4) Outside mirror
– Additional turn signal light
(5) Lift points for the jack

Front view

Fig. 2 Vehicle front overview.
Key to fig. 2:
(1) Inside mirror
(2) Windshield wipers
(3) Engine hood release
(4) Headlights (on both left and right)
(5) Fog lights (on both left and right, if equipped)
(6) Threaded hole for the front towing eye (behind cover)
(7) Side marker lights (on both left and right)

Driver door overview

Fig. 4 Overview of controls in the driver door.
Key to fig. 4:
(1) Door handle
(2) Power locking button for locking and unlocking the vehicle 0 – 1
(3) Knob for adjusting the outside mirror
– Adjusting outside mirrors , – / – 2
– Outside mirror heating ?
(4) Buttons for operating the power windows
– Power windows
– Safety switch for rear power windows _
(5) Indicator light for the power locking system
(6) Lever for releasing the engine hood
(7) Storage compartment
(8) Bottle holder
(9) Reflector
(10) Luggage compartment release switch q
(11) Fuel filler flap release switch

– Mirror adjust
Individually
Both mirrors
Back
– Factory setting
– Back
▪ Lights & Vision
– Conv. turn sig. (convenience turn signal)
– Factory setting
– Back
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
▪ Snow tires (winter tires)
– On
– + 5 mph
– - 5 mph
– Back
▪ Units
– Temperature
– Consump./dist.
– Back
▪ Service
– Info
– Back
▪ Factory setting
Using the instrument cluster menus

Fig. 13 Right side of the multi-function steering wheel: Controls for menus in the instrument cluster.

Convenience menu Function
Unlock doors
Doors are unlocked as follows depending on the option selected: – All doors: Pushing the unlock button 0 on the remote control vehicle key unlocks all doors and the luggage compartment lid. – Single door: Pushing the unlock button 0 on the remote control vehicle key unlocks only the driver door. To unlock all doors and the luggage compartment, push the unlock button 0 on the key a second time within about 5 seconds. On vehicles with Keyless Access, touching the sensor surface of the door handle on the side where the valid vehicle key is located unlocks the respective door – Vehicle side: Pushing the unlock button 0 on the remote control vehicle key unlocks the doors on the driver side of the vehicle. On vehicles with Keyless Access, touching the sensor surface of a door handle on the side where the valid vehi-cle key is located unlocks the doors on that side of the vehicle.
Window op.
Off
Manual unlocking/locking: No windows open or close when the key is held in the unlocking or locking position Keyless Access: No windows close when the locking sensor on the door handle is pressed and held (conven-ience closing)
All
Manual unlocking/locking: All windows open or close when the key is held in the unlocking or locking position. Keyless Access: All windows and the sunroof close when the locking sensor on the door handle is pressed and held.
Driver
Manual unlocking: The driver window opens when the key is held in the unlocking position. Manual locking: All windows close when the key is held in the locking position. Keyless Access: All windows and the sunroof close when the locking sensor on the door handle is pressed and held.
Back The display switches back to the Convenience menu.
Mirror adjust
IndividuallyBoth outside mirrors are adjusted separately.
Both mirrors The front passenger outside mirror is adjusted at the same time as the driver outside mirror.
Back The display returns to the Convenience menu.
Factory setting Resets the features in the Convenience submenu back to the factory settings.
Back The display returns to the Settings menu.
Lights & Vision submenu

Mirrors

Inside mirror

Fig. 81 Manually adjustable inside mirror.

Fig. 83 Auto-dimming inside mirror (if equipped): Version A and Version B.
