Page 77 of 380
Removing the front head restraints
x Sit in the back seat behind the head restraint you want to remove. Pull the head restraint all the
way up ⇒ in Adjusting the front and rear head restraints. Recline the backrest with the head re-straint so that there is enough overhead clearance to remove it.
x Slide a flat object, such as a plastic credit card, underneath the right side of the cap on the right-
hand seat guide rod ⇒ fig. 38 (1) to unlock the head restraint.
x Push the flat object (plastic card) in against the guide rod to depress a release button located under the cap (not visible).
x Use one hand to hold the release button in with the flat object. With your other hand, lift the same guide rod slightly to expose a notch in the rod at the bottom (can be seen and felt with fingers). The right-hand guide rod is now released.
x To release the left-hand guide rod, press button (2) in (towards guide rod) and hold.
x Pull the head restraint out completely while holding button (2).
Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Adjust the head restraint according to the occupant's size, Adjusting the front and rear head re-straints.
Removing the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward, Luggage compartment.
x Pull the head restraint all the way up ⇒ .
x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap ⇒ fig. 39 (1) in the direction of the arrow and hold it in this position.
x At the same time press button (2) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear seat bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward ⇒ page 135, Luggage compartment.
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size, Adjusting the front and rear head re-straints.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in a crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are proper-ly protected.
Page 87 of 380
WARNING
Damage to safety belts reduces their overall effectiveness and increases the risk of serious personal injury and death whenever the vehicle is being used.
x Never let safety belts become damaged by being caught in the door or seat hardware.
x Torn or frayed safety belts can tear, and damaged safety belt hardware can break in an accident.
x Inspect belts regularly for damage. If webbing, bindings, buckles, or retractors are dam-aged, have the belts replaced immediately with the correct replacement belts approved by Volkswagen for your vehicle, model, and model year.
x Safety belts that were subject to stress in an accident and stretched must be replaced with a correct, new safety belt, preferably by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Replacement after a crash may be necessary even if a safety belt shows no visible dam-age. Anchorages that have been loaded must also be inspected.
x Damaged safety belts must be replaced; they cannot be repaired.
x Never try to repair a damaged safety belt yourself. Never remove or modify the safety belts in any way.
x Have safety belts, bindings, retractors and buckles replaced by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Always keep the belts clean. Dirty belts may not work correctly and can impair the func-tion of the inertia reel.
Warning light
Fig. 45 Warning light in the instrument cluster.
Page 88 of 380
The safety belt warning light ª comes on for 6 seconds when the ignition is switched on. A warning chime also sounds for up to 6 seconds if the driver's safety belt is not buckled. The chime stops soon-er if the driver buckles his or her safety belt. The warning light and the chime go out when both driver and front passenger have bucked their safety belts.
If the driver and front seat passenger do not both fasten their safety belts within about 24 seconds after the chime stops and the vehicle is moving at a speed of more than about 15 mph (25 km/h), the chime will again sound for about 6 seconds, then go off for about 24 seconds, then sound again for about another 6 seconds. The same thing happens if one of the safety belts is fastened and then unfastened while the vehicle is moving. The safety belt warning light ª also flashes. The warning chime continues to sound at 24 second intervals for up to 2 minutes. No chime sounds at speeds of less than about 5 mph (8 km/h).
If the ignition is switched on, the safety belt warning light ª stays on until the driver and front passen-ger have both buckled their safety belts.
WARNING
Not wearing a safety belt or wearing an improperly positioned safety belt increases the risk of severe personal injury or death. Safety belts offer optimum protection only when used cor-rectly.
Frontal collisions and laws of physics
Fig. 46 A vehicle with passengers not wearing safety belts approaches a wall.
Fig. 47 A vehicle with passengers not wearing safety belts hits a wall.
Page 98 of 380
WARNING
Improper use or positioning of a safety belt extender increases the risk of serious personal injury and death.
x A driver or passenger who is not properly restrained can be seriously injured by striking the interior of the passenger compartment or by the safety belt itself, which can be displaced from stronger parts of the body into sensitive areas like the abdomen.
x Safety belt extenders offer optimum protection only when they are properly used.
x Only use the extender when the belt is not long enough to be worn low and snug and the person is in the correct seating position. Remove and stow extender safely when not needed.
x Always make sure the safety belt tongue of the safety belt extender is securely inserted into the buckle for the seating position that belongs to the seat where the safety belt extender is being used. Attaching the safety belt to the wrong buckle will reduce safety belt effective-ness and can cause serious personal injury.
x Never use the safety belt extender if you can properly attach the safety belt without it. Using a safety belt extender when not needed can increase the risk of injury, especially in a collision.
x Never use a safety belt extender if the distance (B) between the front edge of the safety belt extender buckle (A) and the centerline of the person using the safety belt extender
⇒ fig. 56 (C) is less than 6 inches (15 cm).
x Never leave a safety belt extender attached to the vehicle safety belt buckle when the extender is not needed and being used with the safety belt. Otherwise, the airbag control module will receive an incorrect signal from the safety belt buckle and this will prevent the airbag from working properly for a person who is not using the safety belt.
x Never use more than 1 extender with a safety belt. Using more than 1 extender can change the way the safety belt passes over the body and can cause serious injury.
x Never use the safety belt extender to secure a child restraint.
x Never use a safety belt extender on your Volkswagen that you got from another automo-bile manufacturer or from an automotive parts store.
x Never use the safety belt extender you got for your vehicle for any other vehicle, regard-less of make, model, or model year.
NOTICE
x Leaving the extender attached to the safety belt buckle when the front seat is occupied and the safety belt is not being used will signal to the airbag control unit that the front passenger seat is occu-pied and that the safety belt is being used. The electronic control unit for the airbag system will then receive incorrect information that will
– cause the safety belt pretensioner to deploy unnecessarily in collisions.
– cause the front passenger airbag to deploy later in collisions in which the front airbag would otherwise be triggered earlier to help protect an unrestrained front seat passenger.
x A pretensioner that has deployed cannot be repaired. The entire safety belt must be re-placed.
NOTICE
If the safety belt extender is left attached to the safety belt buckle, the safety belt warning system will sense that the safety belt for that seat is being used. The warning light will not come on and the warning chime will not sound even though the seat is occupied and the safety belt is not being used.
Page 101 of 380
Page 102 of 380
Lights up Possible cause Proper response
Cornering light malfunction. If all light bulbs are OK, see an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Fog lights switched on (indicator light on the headlight switch).
Z
Page 104 of 380
Switching lights on and off
Fig. 71 Headlight switch next to the steering wheel.
Fig. 72 Headlight switch next to the steering wheel (with fog lights and automatic headlight control).
Page 105 of 380
Acoustic warning when lights are not switched off
In the following situation, a warning chime will sound if you take the key out of the ignition and open the driver door. This is to remind you that lights are still on.
x Light switch in position , if the vehicle has no orientation lighting, Coming home and Leaving home feature (orientation lighting).
WARNING
Daytime running lights are not bright enough to let you see ahead or be seen by others when it is dark.
x Always switch on the low-beam headlights at dusk or when it is dark and whenever the weather is bad or visibility is poor.
x Never use the daytime running lights to see where you are going. They are not bright enough and will not let you see far enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-beam headlights at dusk or when it is dark.
x The taillights do not come on with the daytime running lights. Unless the taillights are on, a vehicle cannot be seen by others in bad weather, at dusk, or when it is dark.
x Even if automatic headlight control (AUTO) is switched on, the low-beam headlights may still not come on by themselves in fog or heavy rain. You have to switch on the low-beam headlights manually.
In cool or humid weather, the insides of the headlights, the rear lights, and turn signals can temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in the United States
Lights and vision features
