2014 VOLKSWAGEN BEETLE warning

clock symbol is also displayed and the number of days until the required service is shown. The display switches off after a few seconds.
For vehicles with text messages (Premium instrument cluster), Oil change and Inspection are shown in the instrument cluster display with the number of miles (km) and days remaining until service is due.
Service event
For vehicles without text messages, a warning , a warning chime sounds when the ignition is switched on, and a flashing wrench symbol > is displayed for several seconds when service is due. For vehicles with text messages, Oil change now! or Inspection now! is shown in the instrument cluster display.
Viewing service message
The current service message can be accessed when the ignition is switched on, the engine is switched off, and the vehicle is stopped:
x For vehicles without text messages: Push the

▪ Consumption --.- mpg (l/100 km) (current fuel consumption)
▪ Av. consumption --.- mpg (l/100 km) (average fuel consumption)
▪ Range -- mi (km)
▪ Route -- mi (km)
▪ Odometer -- mi (km)
▪ Average speed --- mph (km/h)
▪ --- mph (km/h) (digital speed display)
▪ Oil temperature -- °F (°C)
▪ Coolant temperature -- °F (°C)
▪ Speed warning at --- mph (km/h)
Audio ⇒ booklet Radio or ⇒ booklet Navigation system
Navigation ⇒ booklet Navigation system
Vehicle status
Settings
▪ Language
▪ MFI data
– Travel time
– Curr. consump. (current fuel consumption)
– Avg. consump. (average fuel consumption)
– Route
– Odometer
– Average speed
– Digital speed (digital speed display)
– Oil temp.
– Coolant temp.
– Speed warning
– Back
▪ Lights & Vision
– Coming Home
– Leaving Home
– Back
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
▪ Units
– Temperature
– Consump./distance
– Back
▪ Service
– Info
– Back
▪ Factory setting

Display Function
Coolant temperature Coolant temperature (digital display).
Speed warning --- mph When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an acoustic warning sounds and a visual message may also appear in the instrument cluster display. Speed warning --- km/h
Switching between the displays
x Vehicles without a multifunction steering wheel: Press the rocker switch TRI P in the windshield
wiper lever ⇒ fig. 16 (2).
x Vehicles with a multifunction steering wheel: Press the * or the + button ⇒ fig. 17.
Storing speed for the speed warning
x Select the Speed warning at -- mph or Speed warning at -- km/h display.
x Press the /+

Driving checklists and warnings

¥ Properly fasten your safety belt before driving the vehicle and wear your safety belt properly at all times while driving. Make sure that all passengers do the same, Safety belts.
¥ Only transport as many passengers as there are seats and safety belts available.
¥ Never drive if your driving ability has been impaired, for example by medication, alcohol or illegal drugs.
¥ Never let passengers or phone calls distract you while driving, and never take your attention off the road while using vehicle software or adjusting vehicle equipment or accessories.
¥ Always adapt your speed and driving style to visibility, weather, road, and traffic conditions.
¥ Always obey traffic laws and speed limits.
¥ On long trips make frequent rest stops – at least once every 2 hours.
¥ Secure animals in the vehicle with a system that corresponds to weight and size.
WARNING
Always observe traffic rules and posted speed limits and use common sense. Your good judgment can mean the difference between arriving safely at your destination and being seri-ously injured in a crash or other kind of accident.
Regular service and maintenance of your vehicle is important both for operational and driving safety and to help prolong your vehicle's service life. Always follow the scheduled maintenance inter-
vals in the ⇒ booklet Warranty and Maintenance, especially for changing the brake fluid. Hard use, frequent stop-and-go driving, driving in very dusty areas, and other factors may make it necessary to have the vehicle serviced more frequently. Ask an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for more information.
Driving in other countries

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
If a door is not closed properly, the vehicle icon appears in the instrument cluster display showing an
open door ⇒ fig. 13, ⇒ fig. 14, ⇒ fig. 15.
Depending on your vehicle's equipment and options, the icon may still be displayed even after the ignition is switched off as long as the key has not been taken out of the ignition. The icon in the in-strument cluster display goes out about 15 seconds after the vehicle has been locked.

x Switch on the ignition.
x Close all windows and doors.
x Pull the switch for the respective window up and hold it for at least 2 seconds in this position.
x Release the switch, pull up and hold again. The one-touch feature is now reactivated.
The one-touch feature can be reactivated for one or more windows at the same time.
Convenience closing
The convenience closing feature lets you close the windows and the power sunroof from as follows:
From inside the vehicle: When the driver door is open, pull up and hold the switch for the driver win-dow until all windows and the sunroof are closed.
x Manual locking from outside the vehicle: Lock the vehicle with the vehicle key bit in the driver door and keep the key turned in the locking position to close all windows and the power sunroof, Manually unlocking and locking the driver door.
x Vehicles with Keyless Access: Hold your finger on the lock sensor surface on the outside of the door handle for a few seconds until the windows and power sunroof close, Unlocking or locking the vehicle with Keyless Access.
WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children, remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power win-dows for several minutes after the ignition is switched off as long as the driver or passenger door has not been opened.
NOTICE
The windows must go down slightly when you unlock the vehicle. Otherwise the windows and seals could be damaged when opening the doors.
If the power windows malfunction, the one-touch feature, as well as pinch protection may not work properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right away.
If convenience closing of the power windows from the outside requires removing the cover cap of the lock cylinder on the driver door, the cover cap must be reinstalled after the vehicle is locked
⇒ page 345, Manually unlocking and locking the driver door.
Power window pinch protection

x Try one-touch window closing again.
x If the window meets resistance a second time, so that it stops and goes back down, one-touch closing is deactivated for about 10 seconds.
x If you pull the power window button up all the way and hold it during this 10 second interval, the
window will close without pinch protection ⇒ .
Closing the window without pinch protection
x Try to close the window again within 10 seconds by holding the switch. Pinch protection is turned off for a short distance in the window track!
x If closing takes longer than about 10 seconds, pinch protection is turned on again. The window stops again if there is resistance.
x If the window still will not close, please see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
WARNING
Without pinch protection, power windows will close with enough force to cause serious per-sonal injury.
x Always be careful when closing power windows.
x Always make sure that no one is in the way when overriding pinch protection to close power windows!
x Pinch protection cannot prevent fingers or other parts of the body from being pressed against the window frame; injuries may result.
Pinch protection is also active during convenience closing of the windows and the power sunroof, Power sunroof – convenience closing feature.
