In brief11
1Ashtray .................................. 65
Cupholders ........................... 56
Fuse box ............................. 129
2 Fixed air vents ....................... 91
3 Side air vents ........................ 90
4 Light switch .......................... 79
Rear fog light ......................... 82
Front fog lights .....................81
Exit lighting ............................ 83
Turn and lane-change
signals ................................... 81
Sidelights .............................. 79
Headlight flash, low beam
and high beam ......................80
5 Instruments .......................... 65
Driver Information Centre ..... 74
Transmission display ............68
6 Horn ...................................... 61
Driver airbag ......................... 45
7 Steering column controls ......618Windscreen wiper,
windscreen washer system ..61
Rear window wiper, rear
window washer system ........62
Trip computer ....................... 76
9 Centre air vents ..................... 90
10 Triple-Info-Display .................74
11 Tachograph ........................... 78
12 Front passenger airbag .........45
13 Storage tray ......................... 55
14 Coin tray ............................... 55
15 Storage tray ......................... 55
16 Glovebox .............................. 55
17 Utility hook ........................... 10
18 Climate control system .......... 84
19 Hazard warning flashers .......81
20 Central locking system ..........20
Heated exterior mirrors .........29
Heated rear window ..............31Manual transmission
automated,
Winter and Laden modes ......99
Cruise control and speed
limiter ................................. 104
21 Gear lever, Manual
transmission .......................... 96
Manual transmission
automated ............................. 97
22 Power outlet .......................... 64
Cigarette lighter ..................... 64
23 Ignition switch with
steering wheel lock ...............94
24 Steering wheel adjustment ...60
25 Remote control on
steering wheel ......................60
Cruise control .....................104
26 Ultrasonic parking assist ....108
Headlight range
adjustment ........................... 80
Electronic Stability
Program ............................. 103
Traction Control system ......102

In brief13
Headlight flash, high beam and
low beam
Pull lever.
High beam 3 80, Headlight flash
3 80.
Turn and lane-change signalslever up=right turn signallever down=left turn signal
Turn and lane-change signals
3 81.
Hazard warning flashers
Operated with the ¨ button.
Hazard warning flashers 3 81.

Keys, doors and windows21
■Press button c: Front doors and
sliding side doors are unlocked.
Press and hold button c: All doors
and the load compartment are
unlocked.
■ Press button c: Driver's door only is
unlocked. Press and hold c: All
doors and the load compartment
are unlocked.
If no door is opened within approx. 30 seconds after the vehicle has been unlocked, the vehicle is re-locked
automatically.
Locking the vehicle Close doors, load compartment and
fuel filler flap. If the doors are not
closed properly, the central locking
system will not work.
Locking with key
Turn key in driver's door lock towards
the rear of the vehicle.Locking with 2-button remote control
Depending on vehicle configuration:
■ Press button e briefly: All doors and
the load compartment are locked.
■ Press button e once to lock the front
doors, and press e twice to lock all
doors and the load compartment.
Locking with 3-button remote control
Press button e briefly: All doors and
the load compartment are locked.
Notice
Where fitted, alarm monitoring of the passenger compartment 3 26 is
switched off by pressing and holding
button e (which is confirmed by an
audible signal).
If this was done unintentionally,
unlock the doors again and press
button e briefly to lock the vehicle.

Keys, doors and windows23Automatic locking
Automatic locking after driving
off This security feature can be
configured to automatically lock the
doors, load compartment and fuel
filler flap as soon as the vehicle is
driven.
Activation
With the ignition switched on, press and hold e on the central locking
switch for approx. 5 seconds. An audible signal confirms activation.
Deactivation
With the ignition switched on, press and hold y on the central locking
switch for approx. 5 seconds. An audible signal confirms deactivation.Child locks9 Warning
Use the child locks whenever
children are occupying the rear
seats.
The child safety lock for the sliding
door is located on its rearward facing
edge.
Using a key or suitable screwdriver,
turn the child lock in the rear door to
the horizontal position. The door
cannot be opened from the inside. For
deactivation, turn the child lock to the vertical position.

Keys, doors and windows27
Press and hold button e; an audible
signal will sound as confirmation.
The status will remain until the doors
are unlocked.
Alarm
When triggered, the alarm sounds via a separate battery-backed power
sounder, and the hazard warning
lights flash simultaneously. The
number and duration of alarm signals
are stipulated by legislation.
If the vehicle battery is disconnected
or its power supply is interrupted, the
alarm siren will be triggered. First
deactivate the anti-theft alarm system if the vehicle battery must be
disconnected.
To silence the alarm siren (if
triggered) and therefore deactivate
the anti-theft alarm system, reconnect vehicle battery and unlock vehicle
with remote control button c (or
switch on the ignition).
Immobiliser
The system is part of the ignition
switch and checks whether the
vehicle is allowed to be started with
the key being used.
The immobiliser is activated
automatically after the key has been
removed from the ignition switch and
also if the key is left in the ignition
switch when the engine is turned off.
If the engine cannot be started, switch off the ignition and remove key, wait
approx. 2 seconds and then repeat
the start attempt. If start attempt is
unsuccessful, attempt to start the
engine using the spare key and seek
the assistance of a workshop.Notice
The immobiliser does not lock the doors. You should always lock the
vehicle after leaving it and switch on the anti-theft alarm system 3 20,
3 26.

70Instruments and controlsTurn signal
O flashes green.
Flashes if a turn signal or the hazard
warning flashers are activated.
Rapid flashing: failure of a turn signal light or associated fuse.
An audible warning can be heard
when the turn signals are on. When
towing a trailer, the pitch of the
audible warning changes.
Bulb replacement 3 124.
Fuses 3 128.
Turn signals 3 81.
Seat belt reminder
X illuminates in red.
If the seat belt is not fastened, X will
flash when vehicle speed exceeds
approx. 10 mph. An audible warning
also sounds for approx. 90 seconds.9 Warning
Fasten seat belt before each trip.
In the event of an accident, people
not wearing seat belts endanger their fellow occupants and
themselves.
Airbag and belt tensioners
v illuminates yellow.
When the ignition is switched on, the
control indicator illuminates briefly. If it does not illuminate or illuminates
whilst driving, there is a fault in the
belt tensioner or the airbag system.
The airbags and belt tensioners may
fail to trigger in the event of an
accident.
Deployment of the belt tensioners or
airbags is indicated by continuous
illumination of v.
9 Warning
Have the cause of the fault
remedied immediately by a
workshop.
Belt tensioners, airbag system 3 39,
3 42.
Airbag deactivation W illuminates yellow when the
ignition is switched on and remains
illuminated when the front passenger
airbag has been deactivated.
If control indicator W is illuminated in
conjunction with v or A, seek the
assistance of a workshop.

Instruments and controls75Vehicle messages
Messages are shown in the Driver
Information Centre, in combination
with illumination of control indicator
A or C in the instrument cluster.
Information messagesInformation messagesBATTERY MODE: ECONOMYESP OFFAUTO LIGHTS DEACTIVATEDOIL LEVEL CORRECT
Fault messages Will be displayed in combination with
control indicator A. Drive with
caution and seek the assistance of a
workshop.
To remove fault message, press the
button on the end of the wiper lever.
After a few seconds the message
may disappear automatically and A
remains illuminated. The fault will
then be stored in the on board
system.Fault messagesCHECK ESPCHECK FUEL FILTERCHECK GEARBOXCHECK AUTO LIGHTS
Warning messages
These appear with control indicator
C . Stop engine immediately and
seek the assistance of a workshop.
Warning messagesINJECTION FAULTENGINE OVERHEATINGGEARBOX OVERHEATINGWarning chimes
When starting the engine or
whilst driving: ■ During operation of the turn and lane-change signals.
■ If seat belt is not fastened.
■ If the parking assist detects an object.
■ If the vehicle has manual transmission automated and the
clutch temperature is too high.
■ In vehicles with manual transmission automated; when a
door is open while neutral is not
selected. A corresponding
message appears in the Driver
Information Centre.
■ If the vehicle speed briefly exceeds
a set limit.

80Lighting
3. Repeat step 2 within approx.5 seconds.
4. A double acoustic signal sounds for confirmation.
Repeat the operation to deactivate.
For reasons of safety, it is advisable
to have the automatic light control
function activated.
Daytime running lights Daytime running lights increase
visibility of the vehicle during daylight.
The lights operate automatically
when the ignition is switched on.
Automatic headlight activation
During poor lighting conditions the
headlights are switched on.High beam
To change between low and high
beam, pull lever until a click is felt.
Headlight flash To activate the headlight flash, pull
lever.
Headlight range
adjustment
Manual headlight range
adjustment
Adapt the headlight range to suit the
vehicle load to prevent dazzling of
oncoming traffic.
Turn knurled wheel to required position:
0=No load4=Loaded up to permissible
maximum weight
