2014 VAUXHALL COMBO indicator

78Instruments and controls
The warning will be repeated every
time the engine is started, until the
engine oil is changed and the service display is reset. Seek the assistance
of a workshop.
Service display 3 70.
Low engine oil level
y illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
If the control indicator does not
extinguish after a few seconds, or if it illuminates while driving, the engine
oil level is insufficient.
Check oil level before seeking the
assistance of a workshop 3 127.
Low fuel
$ illuminates or flashes yellow.
Illuminates for a few seconds after the ignition is switched on.Illuminates
Level in fuel tank is too low. Refuel
immediately 3 120.
Never run the tank dry.
Catalytic converter 3 107.
Flashes Fault in fuel system.
Have the cause of the fault remedied by a workshop.
Fuel gauge 3 68.
Drain fuel filter
z illuminates yellow.
Illuminates when the ignition is
switched on and goes out shortly after
the engine starts.
Illuminates when the engine is
running
Indicates the presence of water in the
diesel. Seek the assistance of a
workshop immediately.Immobiliser
d illuminates yellow.
Fault in the immobiliser system. The
engine cannot be started.
Stop-start system
Æ illuminates yellow.
A fault is present in the system.
Have the cause of the fault remedied
by a workshop.
Depending on version, 9 will
illuminate as an alternative if control
indicator Æ is not present. A warning
message may also be displayed in
the Driver Information Centre 3 79.
Generic warning 9 3 73.
Stop-start system 3 103.
Exterior light 8 illuminates green.
The exterior lights are on 3 88.
Exterior light failure µ illuminates yellow.

Instruments and controls79
One or more of the exterior lights is
faulty 3 132.
Depending on version, 9 will
illuminate as an alternative if control
indicator µ is not present. A warning
message may also be displayed in
the Driver Information Centre 3 79.
Generic warning 9 3 73.
High beam
C illuminates blue.
Illuminated when high beam is on and during headlight flash 3 88.
Fog light > illuminates green.
The front fog lights are on 3 90.
Rear fog light
r illuminates yellow.
The rear fog light is on 3 91.
Cruise control m illuminates green.The system is on.
Cruise control 3 115.
Door open
\ illuminates red.
A door or the tailgate is open.Information displays
Driver Information Centre
The Driver Information Centre is
located in the instrument cluster
between the speedometer and
tachometer. Two versions are
available; a Standard version

80Instruments and controls
and a Multifunction version with
further adjustable settings.
Some of the displayed functions differ
when the vehicle is being driven or at a standstill. Some options are onlyavailable when the vehicle is being
driven.
Depending on variant, the following
items appear in the display:
■ Odometer, trip odometer 3 67
■ Clock 3 63
■ Outside temperature 3 63
■ Headlight range adjustment 3 89
■ Transmission display 3 108
■ Stop-start system indicator 3 103
■ Vehicle messages 3 85
■ Trip computer 3 86
Selecting menus and options
The menus and options can be
selected via the buttons on the
instrument panel.Press the SETq button:
■ once to access the settings menu
■ press again to access a menu option and submenu options
■ after changes have been made, briefly press again to confirm a
value and automatically return to
the previous display screen
Alternatively, press and hold the
SET q button to return to the
previous display screen without
saving changes to the current menu
option.
Notice
The settings menu is exited
automatically after a delay. Only
changes already confirmed by
briefly pressing the SETq button
are stored.

88LightingLightingExterior lighting............................ 88
Interior lighting ............................. 91
Lighting features ..........................94Exterior lighting
Light switch
Turn light switch:
§=off / daytime running lights9=sidelights / headlights
Control indicator 8 3 78.
Tail lights
Tail lights are illuminated together
with headlights and sidelights.
High beam
To switch from low to high beam,
push lever.
To switch to low beam, pull lever.
Headlight flash
To activate the headlight flash, pull
lever.

90LightingHazard warning flashers
Operated with the ¨ button.
Turn and lane-change
signalsLever up=right turn signalLever down=left turn signal
If the lever is moved past the
resistance point, the turn signal is
switched on constantly. When the
steering wheel moves back, the turn
signal is automatically deactivated.
For five flashes, e.g. when changing
lanes, press the lever until resistance is felt and then release.
Move the lever to the resistance point
and hold for longer indication.
Switch the indicator off manually by
moving the lever to its original
position.
Front fog lights
Operated by pressing the > button.
Switching on front fog lights will
switch sidelights on automatically.
Press the button again to turn the
front fog lights off.

102Driving and operatingIgnition switch positionsSTOP=Steering wheel lock
released, ignition offMAR=Ignition on, for diesel
engine: preheatingAVV=StartingStarting the engine
Manual transmission: operate clutch
and brake.
Manual transmission automated: operate brake, the transmission
automatically shifts to N (neutral)
Do not operate the accelerator pedal. Diesel engine: turn the key to positionMAR for preheating until control
indicator ! extinguishes.
Turn the key briefly to position AVV
and release.
Before restarting or to switch off the
engine, turn the key back to position
STOP .
Autostop
During an Autostop, the engine is
restarted automatically by depressing the clutch pedal. Vehicles with
manual transmission automated
(MTA): shift to a forward gear, release
brake pedal or move lever to +, – or
R to enable an automatic restart.
Stop-start system 3 103.
Starting the vehicle at low
temperatures The start of the engine without
additional heaters is possible down to
-25 °С for diesel engines and -30 °C
for petrol engines. Required is an
engine oil with the correct viscosity,
the correct fuel, performed services
and a sufficiently charged battery.

104Driving and operating
ActivationThe stop-start system is available as
soon as the engine is started, the
vehicle starts-off and the conditions
as stated below in this section are
fulfilled.
Deactivation
Deactivate the stop-start system
manually by pressing the ^ button in
the centre console. LED in the button
illuminates to confirm deactivation.
Autostop
If the vehicle is at a low speed or at a
standstill, activate an Autostop as
follows:
■ Depress the clutch pedal
■ set the lever to neutral
■ release the clutch pedal
The engine will be switched off while the ignition stays on.
An Autostop is indicated when control indicator ^ flashes in the Driver
Information Centre 3 79.
During an Autostop, the heating and
brake performance will be
maintained.Caution
The steering assist can be
reduced during an Autostop.
Conditions for an Autostop
The stop-start system checks if each
of the following conditions is fulfilled.
Otherwise an Autostop will be
inhibited.
■ The stop-start system is not manually deactivated
■ the bonnet is fully closed
■ the driver's door is closed and the driver's seat belt is fastened
■ the battery is sufficiently charged and in good condition
■ the engine is warmed up
■ the engine coolant temperature is not too high
■ the engine exhaust temperature is not too high, e.g. after driving with
high engine load

106Driving and operating
Notice
In the event of an accident with
airbag deployment, the engine is
turned off automatically if the vehicle
comes to a standstill within a certain time.Engine exhaust9 Danger
Engine exhaust gases contain
poisonous carbon monoxide,
which is colourless and odourless and could be fatal if inhaled.
If exhaust gases enter the interior
of the vehicle, open the windows.
Have the cause of the fault
rectified by a workshop.
Avoid driving with an open load
compartment, otherwise exhaust
gases could enter the vehicle.
Diesel particle filter
The diesel particle filter system filters
harmful soot particles out of the
exhaust gases. The system includes
a self-cleaning function that runs
automatically during driving without
any notification. The filter is cleaned
by periodically burning off the soot
particles at high temperature. This
process takes place automatically
under set driving conditions and may
take up to 25 minutes. Typically it
needs 15 minutes. Autostop is not
available and fuel consumption may
be higher during this period. The
emission of smells and smoke during
this process is normal.
Under certain driving conditions, e.g.
short distances, the system cannot
clean itself automatically.
If the cleaning of the filter is required
and if previous driving conditions did
not enable automatic cleaning, it will
be indicated by control indicator
[ . Simultaneously a message
may appear in the Driver Information
Centre 3 79.
Control indicator [ illuminates
when diesel particle filter is full. Start
cleaning process as soon as possible to avoid damage to the engine.
Cleaning process To activate cleaning process,
continue driving, keep engine speed
above 2000 rpm. Shift down if
necessary. Diesel particle filter
cleaning is then started.
