2014 TOYOTA YARIS Speed

347
6-1. Specifications
6
Vehicle specifications
Oil viscosity (5W-30 is explained here as an example):
●
The 5W in 5W-30 indicates the characteristic of the oil which allows
cold startability. Oils with a lower value before the W allow for easier
starting of the engine in cold weather.
● The 30 in 5W-30 indicates the viscosity characteristic of the oil when
the oil is at high temperature. An oil with a higher viscosity (one with a
higher value) may be better suited if the vehicle is operated at high
speeds, or under extreme load conditions.
How to read oil container label:
The ILSAC (International Lubric ant Standardization and Approval
Committee) Certification Mark is added to some oil containers to help
you select the oil you should use.
Cooling system
Capacity
(Reference) Vehicles with an automatic transmission:
4.9 qt. (4.6 L, 4.0 Imp.qt.)
Vehicles with a manual transmission:
5.0 qt. (4.7 L, 4.1 Imp.qt.)
Coolant typeUse either of the following:
• “Toyota Super Long Life Coolant”
• A similar high-quality ethylene glycol-based non-silicate, non-amine, non-nitrite,
and non-borate coolant with long-life
hybrid organic acid technology
Do not use plain water alone.

359
6-1. Specifications
6
Vehicle specifications
Tire size
■ Typical tire size information
The illustration indicates typical tire size.
Tire use
(P = Passenger car,
T = Temporary use)
Section width (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code
(R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol
(alphabet with one letter)
■ Tire dimensions
Section width
Tire height
Wheel diameter

362 6-1. Specifications
Warning: The temperature grades of a tire assume that it is properly
inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either sepa-
rately or in combination, can cause heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure
Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

369
6-2. Customization
6
Vehicle specifications
Illumination
(
P. 202)
(vehicles
with alarm
system or
daytime run-
ning light
system) Time elapsed before
lights turn off
15 seconds7.5 seconds
30 seconds
Operation after the
engine switch is turned
to the “LOCK” position On Off
Operation when the
doors are unlocked On Off
Seat belt
reminder
buzzer
( P. 307) Vehicle speed linked
seat belt reminder
buzzer
On Off
ItemFunctionDefault settingCustomized
setting

393
Alphabetical index
Shift lever
Automatic transmission ........ 127
If the shift lever cannot be
shifted from P ..................... 328
Manual transmission ............ 129
Shift lock system..................... 328
Side airbags ............................... 80
Side marker lights Replacing light bulbs ............ 287
Switch ................................... 145
Wattage ................................ 352
Side mirror Adjusting................................. 64
Defogger............................... 199
Folding.................................... 65
Spare tire Identification number ............ 358
Inflation pressure .......... 262, 351
Information ........................... 356
Replacing ............................. 315
Size ...................................... 351
Storage location ................... 315
Spark plug................................ 348
Specifications .......................... 342
Speedometer ........................... 133
Steering wheel
Adjustment ............................. 62
Column lock release ............. 125
Electric power steering ......... 163
EPS ...................................... 163
Specification ......................... 350
Warning light ........................ 306
Stop lights Replacing light bulbs ............ 287
Wattage ................................ 352
Storage features Bottle holders ............... 204, 207
Cup holders .................. 204, 205
Glove box ..................... 204, 205
Storage precautions ............... 170
Stuck If the vehicle becomes stuck................................... 337 Sun visors.................................208
Switch
Cruise control ........................159
Emergency flashers switch ..................................296
Engine switch ........................124
Fog lights switch.................... 149
Hazard lights switch ..............296
Headlights switch ..................145
Ignition switch........................124
Light switch ...........................145
Power door lock switch ...........35
Power window switch ..............67
Steering wheel audio switches ..............................201
Turn signal lights ...................130
VSC OFF switch....................164
Window lock switch .................67
Wiper and washer .........151, 154
Tachometer...............................133
Tail lights Replacing light bulbs .............287
Switch....................................145
Wattage .................................352
Theft deterrent system Alarm .......................................74
Engine immobilizer system .....72
Theft prevention labels ............77
Theft prevention labels..............77
Tire inflation pressure .....262, 351
Tire information Glossary ................................362
Size .......................................359
Tire identification number ......358
Uniform tire quality grading ................................360
