2014 TOYOTA PRIUS C tire size

512 6-1. Specifications
Tire size■ Typical tire size information
The illustration indicates typical tire size.
Tire use
(P = Passenger car,
T = Temporary use)
Section width (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code
(R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol
(alphabet with one letter)
■ Tire dimensions
Section width
Tire height
Wheel diameter

517
6-1. Specifications
6
Vehicle specifications
Production options
weight
The combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy duty
battery, and special trim
Rim A metal support for a tire or a tire and tube
assembly upon which the tire beads are seated
Rim diameter
(Wheel diameter) Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designation The industry manufacturer's designation for a
rim by style or code
Rim width Nominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity) The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicl
e's designated seating
capacity
Vehicle maximum load
on the tire The load on an individual tire that is determined
by distributing to each axle its share of the
maximum loaded vehicle weight, and dividing
by two
Vehicle normal load
on the tire The load on an individual tire that is determined
by distributing to each axle its share of curb
weight, accessory weight, and normal occu-
pant weight (distributed in accordance with
Table 1* below), and dividing by two
Weather side The surface area of the rim not covered by the
inflated tire
Bead The part of the tire that is made of steel wires,
wrapped or reinforced by ply cords and that is
shaped to fit the rim
Tire related termMeaning

528
6-2. Customization
Items to initialize
ItemWhen to initializeReference
Maintenance data
(except Canada)After the maintenance is performedP. 353
Tire pressure warning
system
• When rotating the tires on vehicles with differing front and rear tire
inflation pressures
• When changing tire pressure (such as when changing traveling speed,
load weight, etc.)
• When changing the tire size
P. 3 8 5
The following items must be initia lized for normal system operation
after such cases as the 12-volt batt ery being reconnected, or mainte-
nance being performed on the vehicle:

555
Alphabetical index
Switch
Cruise control ....................... 217
“ECO MODE” switch ............ 176
Emergency flasher switch .... 428
EV drive mode switch ........... 172
Engine switch ............... 160, 164
Fog light switch..................... 208
Hazard light switch ............... 428
Headlight switch ................... 204
Ignition switch ............... 160, 164
Light switches ....................... 204
Power door lock switch........... 65
“POWER” switch .................. 164
Power window switch ............. 98
Rear window wiper and
washer switch .................... 214
Steering wheel audio
switches ............................. 288
Window lock switch ................ 98
Wiper and washer ........ 210, 214
Tail lights Replacing light bulbs ............ 415
Switch ................................... 204
Wattage ................................ 505
Theft deterrent system Immobilizer system............... 110
Theft prevention labels ......... 113
Theft prevention labels ........... 113
Tire inflation pressure ............ 392
Tire information Glossary ............................... 516
Size ...................................... 512
Tire identification number ..... 511
Uniform tire quality grading ............................... 513 Tires
Chains ...................................231
Checking ...............................384
If you have a flat tire ..............463
Inflation pressure...................392
Inflation pressure sensor .......385
Information ............................509
Replacing ..............................463
Rotating tires .........................384
Size .......................................504
Snow tires .............................231
Spare tire...............................463
Tire pressure warning system ........................384, 439
Tools .........................................463
Total load capacity...................230
Towing Dinghy towing........................236
Emergency towing.................431
Trailer towing.........................235
TRAC .........................................221
Traction control........................221
Transmission Hybrid transmission...............175
If the shift lever cannot be shifted from P................. 477
Trip information .......................187
Trip meter .................................181
Turn signal lights Replacing light bulbs .............415
Switch....................................178
Wattage .................................505
USB memory ....................268, 276
