500 6-1. Specifications
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allowscold startability. Oils with a lower value before the W allow for easier
starting of the engine in cold weather.
• The 20 in 0W-20 indicates the viscosity characteristic of the oil when the oil is at high temperature. An oil with a higher viscosity (one with a
higher value) may be better suited if the vehicle is operated at high
speeds, or under extreme load conditions.
How to read oil container label:
The International Lubricant Spec ification Advisory Committee
(ILSAC) Certification Mark is added to some oil containers to help
you select the oil you should use.
Cooling system
Capacity Gasoline engine
Power control unit 5.6 qt. (5.3 L, 4.7 Imp. qt.)
1.7 qt. (1.6 L, 1.4 Imp. qt.)
Coolant type Use either of the following:
• “Toyota Super Long Life Coolant”
• A similar high-quality ethylene glycol-based non-silicate, non-amine, non-nitrite,
and non-borate coolant with long-life
hybrid organic acid technology
Do not use plain water alone.

516 6-1. Specifications
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of hybrid
transmission, power steering, power brakes,
power windows, power seats, radio and heater,
to the extent that these items are available as
factory-installed equipment (whether installed
or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight 150 lb. (68 kg) times the number of occupants
specified in the second co
lumn of Table 1* that
follows
Occupant distribution Distribution of occupants in a vehicle as speci-
fied in the third column of Table 1* below

517
6-1. Specifications
6
Vehicle specifications
Production options
weight
The combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy duty
battery, and special trim
Rim A metal support for a tire or a tire and tube
assembly upon which the tire beads are seated
Rim diameter
(Wheel diameter) Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designation The industry manufacturer's designation for a
rim by style or code
Rim width Nominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity) The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicl
e's designated seating
capacity
Vehicle maximum load
on the tire The load on an individual tire that is determined
by distributing to each axle its share of the
maximum loaded vehicle weight, and dividing
by two
Vehicle normal load
on the tire The load on an individual tire that is determined
by distributing to each axle its share of curb
weight, accessory weight, and normal occu-
pant weight (distributed in accordance with
Table 1* below), and dividing by two
Weather side The surface area of the rim not covered by the
inflated tire
Bead The part of the tire that is made of steel wires,
wrapped or reinforced by ply cords and that is
shaped to fit the rim
Tire related termMeaning

521
6-1. Specifications
6
Vehicle specifications
*:Table 1
 Occupant loading and distri bution for vehicle normal load
for various designated seating capacities
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehi- cle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat
Tire related termMeaning

551
Alphabetical index
Heaters
Seat heaters ......................... 337
Side mirrors .......................... 247
Hill-start assist control ........... 221
Hood ......................................... 364
Horn .......................................... 180
Hybrid system Emergency shut off system .... 30
Energy monitor/
consumption screen ............. 35
High voltage components ....... 29
Hybrid system indicator ........ 197
“POWER” switch .................. 164
Vehicle Proximity
Notification System .............. 25
I/M test ...................................... 359
Identification Engine .................................. 498
Tire ....................................... 509
Vehicle.................................. 497
Ignition switch ................. 160, 164
Illuminated entry system ........ 323
Immobilizer system ................. 110
Indicator lights ........................ 184
Initialization
Items to initialize ................... 528
Inside rear view mirror.............. 94
Interior lights
Switch ................................... 322
Wattage ................................ 505
iPod .......................................... 268
Jack Positioning a floor jack ......... 366
Vehicle-equipped jack .......... 463
Jack handle.............................. 463 Keyless entry..............................61
Keys
Electronic key ..........................44
Engine switch ................160, 164
If the electronic key does not operate properly............ 479
If you lose your keys .............478
Ignition switch................160, 164
Key battery ............................401
Key number .............................44
Keyless entry...........................61
Keys ........................................44
Mechanical key .......................44
“POWER” switch ...................164
Wireless remote control key ........................................61
Knee airbag ..............................116
License plate lights
Replacing light bulbs .............415
Wattage .................................505
Light bulbs
Replacing ..............................415
Wattage .................................505
Lights
Emergency flasher switch .....428
Fog light switch .....................208
Hazard light switch ................428
Headlight switch ....................204
Instrument panel light switch ..................................204
Interior lights switch...............322
Parking light switch ...............204
Personal light switch .............322
Replacing light bulbs .............415
Side marker light switch ........204
Tail light switch ......................204
Turn signal lever....................178
Wattage .................................505
Load capacity ...........................230
Lock steering column ......162, 168
I
J
K
L

555
Alphabetical index
Switch
Cruise control ....................... 217
“ECO MODE” switch ............ 176
Emergency flasher switch .... 428
EV drive mode switch ........... 172
Engine switch ............... 160, 164
Fog light switch..................... 208
Hazard light switch ............... 428
Headlight switch ................... 204
Ignition switch ............... 160, 164
Light switches ....................... 204
Power door lock switch........... 65
“POWER” switch .................. 164
Power window switch ............. 98
Rear window wiper and
washer switch .................... 214
Steering wheel audio
switches ............................. 288
Window lock switch ................ 98
Wiper and washer ........ 210, 214
Tail lights Replacing light bulbs ............ 415
Switch ................................... 204
Wattage ................................ 505
Theft deterrent system Immobilizer system............... 110
Theft prevention labels ......... 113
Theft prevention labels ........... 113
Tire inflation pressure ............ 392
Tire information Glossary ............................... 516
Size ...................................... 512
Tire identification number ..... 511
Uniform tire quality grading ............................... 513 Tires
Chains ...................................231
Checking ...............................384
If you have a flat tire ..............463
Inflation pressure...................392
Inflation pressure sensor .......385
Information ............................509
Replacing ..............................463
Rotating tires .........................384
Size .......................................504
Snow tires .............................231
Spare tire...............................463
Tire pressure warning system ........................384, 439
Tools .........................................463
Total load capacity...................230
Towing Dinghy towing........................236
Emergency towing.................431
Trailer towing.........................235
TRAC .........................................221
Traction control........................221
Transmission Hybrid transmission...............175
If the shift lever cannot be shifted from P................. 477
Trip information .......................187
Trip meter .................................181
Turn signal lights Replacing light bulbs .............415
Switch....................................178
Wattage .................................505
USB memory ....................268, 276
T
U

556 Alphabetical index
Vanity mirrors........................... 333
Vehicle data recordings ............18
Vehicle identification number ................................... 497
Vehicle Proximity Notification
System ....................................25
Vehicle stability control........... 221
VSC............................................ 221
Warning buzzers Brake system ........................ 437
Electric power steering system ................................ 438
Key reminder ......................... 455
Master warning...................... 439
Seat belt reminder ................. 439
Warning lights Anti-lock brake system .......... 438
Brake assist system .............. 438
Brake system ........................ 437
Charging system .... ............... 438
Electric power steering
system ................................ 438
Front passenger occupant classification system ........... 438
Low brake fluid ...................... 437
Low fuel level ........................ 439
Low tire inflation pressure ..... 439
Malfunction indicator lamp .... 438
Master warning light .............. 439 Pretensioners ........................ 438
Seat belt reminder light ......... 439
Slip indicator light .................. 438
SRS airbag system ............... 438
Tire pressure ......................... 439
Tire pressure warning
system ................................ 439
Warning messages
Back door .............................. 450
Cruise control ........................ 449
EV drive mode ...................... 450
Hybrid system ....................... 448
Hybrid system overheat ........ 450
Maintenance ......................... 450
Moon roof .............................. 450
N position .............................. 450
Open door ............................. 450
P position .............................. 450
Parking brake ........................ 450
Smart key system ......... 449, 455
Traction battery ..................... 450
Washer Checking ............................... 378
Preparing and checking
before winter ....................... 231
Switch ........................... 210, 214
Washing and waxing ............... 346
Weight Cargo capacity ...................... 226
Load limits ............................. 230
Weight ................................... 496
Wheels ...................................... 396
Window lock switch................... 98V
W
