2014 TOYOTA LAND CRUISER navigation

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
23
OVERVIEW
Instrument panel
Steering wheel audio controls1
Telephone controls1
Voice command button1
Multi-Information Display button
Distance switch2
Headlight, turn signal and front fog light controls
Multi-Information Display
Wiper and washer controls
Audio system
1
“AIR BAG ON” and “AIR BAG OFF” indicator
Clock1
Front passenger seat belt reminder light
Theft deterrent system/Engine immobilizer indicator
Emergency flasher button
Outside rearview mirrors/Rear window defogger button
Air Conditioning controls
1
Steering wheel controls
Type AType A
Type B
Type B
“ENGINE START STOP” switch
Four-wheel drive control switch
VIEW switch (multi-terrain monitor)
2
Cruise control2/Dynamic radar cruise control2
Tire Pressure Monitoring (warning) System reset
Headlight leveling dial
Power outside rearview mirror controls
Instrument panel light control
Tilt and telescopic steering control
Intuitive parking assist switch
Center differential lock/unlock switch
Roll Sensing of Curtain shield Airbag OFF switch
Heated steering wheel switch
2
VSC/TRAC OFF switch
Headlight cleaner2
1
For vehicles with navigation system, refer to the “Navigation System Owner’s
Manual” for details.
2 If equipped

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
19
18
FEATURES/OPERATIONS
AudioiPod®/USB/AUX port
“ ”
Use to search within the
selected audio medium
(radio, CD, iPod
®, etc.).
“MODE”
Push to turn audio ON and to
select an audio mode. Push and
hold to turn audio system OFF.
Steering wheel switches
MODE
Volume
control
vv
Push to
turn ON/
OFF
Eject disc Mute/PauseDisc slotTurn to
search
selected
media (radio,
CD, DVD,
iPod
®, etc.)
Display
audio
control
screen
Display
audio
setup
screen
Function tabs:
Select media
mode
NOTE: For more information, refer to the Owner’s Manual or “Navigation System
Owner’s Manual.”
Seek station/
track/presets
or rewind/FF
Type A
Type B


Eject disc
Mode
View CD text
Push to turn
ON/OFF
Preset buttons-functions in other
modes indicated above number
Seek station/
CD track selectStation/CD track scan
Load CD(s)
Traffic
information
Changing
program type/
CD selection
Turn to tune
radio station
manually or
select tracks
or files
iPod®/USB port
By connecting a USB-compatible portable audio device or USB memory to the
USB port, you can listen to music from the portable audio device or USB memory
through the vehicle’s speaker system.
AUX port
By inserting a mini plug into the AUX port, you can listen to music from a portable
audio device through the vehicle’s speaker system while in AUX mode.

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
21
20
FEATURES/OPERATIONS
Air Conditioning/Heating
Rear Air Conditioning
Temperature selector (left side)
Temperature selector (right side)
Climate control OFF
Airflow vent
Fan speed
Automatic climate control ON
NOTE: For more information, refer to the Owner’s manual or “Navigation System
Owner’s Manual.”
Front Air Conditioning
Driver side temperature display
Airflow controls (touch to change air outlets)
Passenger side temperature display
Rear AC control button (touch to display rear AC control screen)
Fan speed
Air Conditioning ON/OFF
“4-ZONE” button (touch to set the temperatures independently for driver,
front passenger and rear seats)
Windshield wiper de-icer (if equipped)
Temperature controls (driver side)
CLIMATE (push to display AC control screen)
Automatic climate control ON
Adjusting the temperature setting will cause the airflow vents, air intake and
fan to adjust automatically.
Climate control OFF
Windshield airflow/defogger (fresh air only)
Outside rearview mirror/Rear window defogger
Micro dust and pollen removal mode ON/OFF
Rear Air Conditioning operation mode ON/OFF
Air intake control (switch between outside air and recirculated air mode)
Temperature controls (passenger side)
Type A
Type B

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
27
26
FEATURES/OPERATIONS
Multi-Information Display
Push “DISP” to scroll through the following information screens:
(1) Front tire angle
(2) Miles left on remaining fuel
(3) Average gas mileage after refueling
(4) Current gas mileage
(5) Average gas mileage and Eco Driving Indicator Zone Display
(6) Average vehicle speed
(7) Speedometer
(8) Turn-by-turn navigation setting screen (vehicles with navigation system)
(9) Tire inflation pressure
(10) Display OFF
Bluetooth® technology allows dialing or receipt of calls without taking hands from
the steering wheel or using a cable to connect the telephone and the system.
Refer to “Hands-free system (for cellular phone),” Section 4 in the Navigation
System Owner’s Manual , for more information about phone connections and
compatibility.
MicrophoneDisplay
Type BType A
Steering wheel telephone switches
Start callStart call
End callEnd call
Voice
command
button
Voice
command
button
Door locks
LockUnlock
Telephone controls (Bluetooth®)
Up
Toward
driver
Down
NOTE: Do not attempt to adjust while the vehicle is in motion.
Tilt and telescopic steering wheel
Away
from
driver
Control switch

OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
29
28
FEATURES/OPERATIONS
Cup holders
Parking brake
(2) Push
SetRelease
(1) Pull slightly
(3) Lower
Pull
COOLBOX
PWR
Cooler box (if equipped)
Push “PWR” button to turn cooler box ON; indicator will illuminate.
Indicator
Front audio system (DVD player)
DVD screen
Remote control
Headphone volume control and headphone jacks
A/V input adapter
120V AC Power outlet
For details, refer to the “Navigation System Owner’s Manual .”
Rear
Front
Power outlets-12V DC
The “ENGINE START STOP” switch must be in “ACCESSORY” or “IGNITION ON”
mode to be used.
Power outlet-120V AC
The “ENGINE START STOP” switch must be in “IGNITION ON” mode to be used.
Front
Type A
Rear
Rear seat entertainment system
(if equipped)
Type B
