2014 TOYOTA HIGHLANDER HYBRID tire pressure reset

21Pictorial index
HIGHLANDER_HV_U (OM48D74U)Inside lock buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 130
Driving position memory switches
*1. . . . . . . . . . . . . . . . . . P. 165
Outside rear view mirror switch . . . . . . . . . . . . . . . . . . . . . . P. 177
Door lock switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 130
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 179
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 180
Tire pressure warning reset switch . . . . . . . . . . . . . . . . . . . P. 414
PCS OFF switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 298
*1: If equipped
*2: Refer to “Navigation and Multimedia System Owner’s Manual”.
1
2
3
4
5
6
7
8

4146-3. Do-it-yourself maintenance
HIGHLANDER_HV_U (OM48D74U)■
How to initialize the tire pressure warning system
Park the vehicle in a safe place and turn the power switch to off.
Initialization cannot be performed while the vehicle is moving.
Adjust the tire inflation pressure to the specified cold tire inflation
pressure level. ( P. 536)
Make sure to adjust the tire pressu re to the specified cold tire infla-
tion pressure level. The tire pressure warning system will operate
based on this pressure level.
Turn the power switch to the ON mode.
Press and hold the tire pres-
sure warning reset switch
until the tire pressure warn-
ing light blinks slowly 3 times.
Wait for a few minutes with the power switch in ON mode and
then turn the power switch off.
1
2
3
4
5

4186-3. Do-it-yourself maintenance
HIGHLANDER_HV_U (OM48D74U)■
The initialization operation
●Make sure to carry out in
itialization after adjusting the tire inflation pres-
sure.
Also, make sure the tires are cold be fore carrying out initialization or tire
inflation pressure adjustment.
●If you have accidentally turned the power switch to off during initializa-
tion, it is not necessary to press th e reset switch again as initialization
will restart automatically when the po wer switch has been turned to the
ON mode for the next time.
●If you accidentally press the reset s witch when initialization is not neces-
sary, adjust the tire inflation pressu re to the specified level when the
tires are cold, and conduct initialization again.
■When initialization of the tire pr essure warning system has failed
Initialization can be completed in a few minutes. However, in the following
cases, the settings have not been recorded and the system will not oper-
ate properly. If repeated attempts to record tire inflation pressure settings
are unsuccessful, have the vehicle inspected by your Toyota dealer.
●When operating the tire pressure wa rning reset switch, the tire pressure
warning light does not blink 3 times.
●After carrying out the initialization procedure, the tire pressure warning
light blinks for 1 minute then stays on after driving for 20 minutes.

4196-3. Do-it-yourself maintenance
HIGHLANDER_HV_U (OM48D74U)
6
Maintenance and care
■Tire pressure warning system certification
FCC ID: PAXPMVC010
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsi-
ble for compliance could void the user ’s authority to operate the equip-
ment.
NOTE:
Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
NOTE:
L’utilisation de ce dispositif est au torisée seulement aux deux conditions
suivantes : (1) il ne doit pas produire de brouillage, et (2) l’utilisateur du
dispositif doit être pr êt à accepter tout brouillage radioé lectrique reçu,
même si ce brouillage est susceptible de comp romettre le fonctionne-
ment du dispositif.
WARNING
■When inspecting or replacing tires
Observe the following precautions to prevent accidents.
Failure to do so may cause damage to parts of the drive train as well as
dangerous handling characteristics, which may lead to an accident
resulting in death or serious injury.
●Do not mix tires of different ma kes, models or tread patterns.
Also, do not mix tires of remarkably different treadwear.
●Do not use tire sizes other than those recommended by Toyota.
●Do not mix differently constructed ti res (radial, bias-belted or bias-ply
tires).
●Do not mix summer, all season and snow tires.
●Vehicles with a compact spare tire: Do not tow if your vehicle has a
compact spare tire installed.
■When initializing the tire pressure warning system
Do not operate the tire pressure warning reset switch without first
adjusting the tire inflation pressure to the specified level. Otherwise, the
tire pressure warning light may not come on even if the tire inflation
pressure is low, or it may come on when the tire inflation pressure is
actually normal.

4617-2. Steps to take in an emergency
7
When trouble arises
HIGHLANDER_HV_U (OM48D74U)
■SRS warning light
This warning light system monitors the airbag sensor assembly, front impact
sensors, side impact sensors (front door), side impact sensors (rear), driver’s
seat position sensor, driver’s seat belt buckle switch, front passenger occu-
pant classification system (ECU and sensors), “AIR BAG ON” indicator light,
“AIR BAG OFF” indicator light, front passenger’s seat belt buckle switch, seat
belt pretensioner, airbags, interconnecting wiring and power sources.
( P. 43)
■ Front passenger detection sensor, seat belt reminder and warning
buzzer
If luggage is placed on the front passenger seat, the front passenger detec-
tion sensor may cause the warning light to flash and the warning buzzer to
sound even if a passenger is not sitting in the seat.
■ If the malfunction indicator la mp comes on while driving
First check the following:
● Is the fuel tank empty?
If it is, fill the fuel tank immediately.
● Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.
■ Electric power steering system warning light (warning buzzer)
When the 12-volt battery charge becomes insufficient or the voltage tem-
porarily drops, the electric power steering system warning light may come
on and the warning buzzer may sound.
■When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level. Push-
ing the tire pressure warning reset switch will not turn off the tire pressure
warning light.
■The tire pressure warning light may come on due to natural causes
The tire pressure warning light may come on due to natural causes such
as natural air leaks and tire inflation pressure changes caused by temper-
ature. In this case, adjusting the ti re inflation pressure will turn off the
warning light (after a few minutes).

600Alphabetical index
HIGHLANDER_HV_U (OM48D74U)
Speech command system*
Speedometer ............................ 103
Steering wheel ......................... 173Adjustment ............................ 173
Audio switches
*
Stop/tail lightsReplacing light bulbs............. 434
Wattage ................................ 539
Storage feature ........................ 342
Stuck If the vehicle becomes
stuck ................................... 525
Sun visors ................................ 351
Sunshade Panoramic roof ..................... 187
Rear ...................................... 357
Roof ...................................... 184
Switches Audio remote control switches
*
Automatic High Beam switch ................................. 248
Back door opener switch ...... 135
BSM (Blind spot monitor) switch ................................. 304
Cruise control switch............. 264
Door lock switches ................ 130
Driving position memory switches.............................. 165
Dynamic radar cruise control switch...................... 269
“ECO MODE” switch ............. 238
Emergency flashers switch ................................. 450
EV drive mode switch ........... 235
Fog light switch ..................... 254
Garage door opener switches.............................. 361
Heated steering wheel switch ................................. 337
Ignition switch ....................... 229
Intuitive parking assist
*
LDA (Lane Departure Alert) switch ................................. 284
Light switches ....................... 244 Meter control switches .......... 112
Moon roof switches............... 183
Outside rear view mirror
switches ............................. 177
Panoramic moon roof
switches ............................. 187
PCS OFF switch ................... 298
Power back door main switch ................................. 136
Power back door opener and closer switch................ 134
Power door lock switch ......... 130
Power switch ........................ 229
Power window switches........ 179
Rear window and outside rear view mirror
defoggers switch ................ 328
Rear window wiper and washer switch..................... 257
Seat heater switches ............ 337
Seat ventilator switches ........ 337
“SOS” button......................... 368
Steering wheel switch ........... 112
Talk switch
*
Telephone switches*
Tire pressure warning reset switch ................................. 414
Vehicle-to-vehicle distance button ................................. 269
VSC OFF switch ................... 293
Window lock switch .............. 180
Windshield wipers and washer switch.............. 255

601Alphabetical index
HIGHLANDER_HV_U (OM48D74U)
Tachometer .............................. 103
Tail lights .................................. 244Light switch ........................... 244
Replacing light bulbs............. 434
Wattage ................................ 539
Talk switch
*
Telephone switches*
Theft deterrent system Alarm ...................................... 93
Immobilizer system ................. 91
Theft prevention labels ............. 96
Tire inflation pressure ............. 421
Maintenance data ................. 536
Warning light ......................... 459
Tire information ....................... 543 Glossary................................ 550
Size ....................................... 546
Tire identification number ..... 545
Uniform Tire Quality Grading............................... 548
Tire pressure warning system .................................... 413 Function ................................ 413
Initializing .............................. 413
Installing tire pressure
warning valves
and transmitters.................. 413
Registering ID codes ............ 415
Tire pressure warning reset switch ................................. 414
Warning light ......................... 459 Tires .......................................... 412
Chains .................................. 318
Checking............................... 412
If you have a flat tire ............. 486
Inflation pressure .................. 536
Information............................ 543
Replacing.............................. 486
Rotating tires ........................ 412
Size....................................... 536
Snow tires ............................. 319
Spare tire .............................. 486
Tire pressure warning
system .......... ...................... 413
Warning light......................... 459
Tools ......................................... 487
Top tether strap ......................... 76
Towing Dinghy towing ....................... 228
Emergency towing ................ 452
Trailer towing ........................ 211
TRAC (Traction Control) ......... 291
Traction battery (hybrid battery)........................ 85
Traction Control (TRAC) ......... 291
Traction motor (electric motor) ........................ 81
Trailer towing .......................... 211
Transmission ........................... 237
Hybrid transmission .............. 237
If the shift lever cannot be shifted from P ..................... 512
S mode ................................. 239
Turn signal lights .................... 242
Replacing light bulbs ............ 434
Turn signal lever ................... 242
Wattage ................................ 539
T
*: Refer to “Navigation and Multimedia System Owner’s Manual”
