5509-1. Specifications
COROLLA_TMMMS_TMMC_U (OM12F00U)
*: The fluid capacity is a reference quantity.
If replacement is necessary, contact your Toyota dealer.
Automatic transaxle
Fluid capacity (Reference) 6.9 qt. (6.5 L, 5.7 Imp. qt.)
Fluid type Toyota Genuine ATF WS
NOTICE
■Automatic transmission fluid type
Using automatic transmission fluid other than “Toyota Genuine ATF WS”
may cause deterioration in shift quality, locking up of your transmission
accompanied by vibration, and ultimately damage the transmission of your
vehicle.
Continuously variable transaxle
Fluid capacity*7.9 qt. (7.5 L, 6.6 Imp. qt.)
Fluid typeToyota Genuine CVTF FE
NOTICE
■Continuously variable transaxle fluid type
Using continuously variable transaxle fluid other than “Toyota Genuine
CVTF FE” may cause deterioration in shift quality, locking up of the trans-
mission accompanied by vibration and, ultimately, damage to the vehicle’s
transmission.
Clutch
Pedal free play 0.2 0.6 in. (5 15 mm)
Fluid type SAE J1703 or FMVSS No.116 DOT 3
604Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12F00U)
Flat tire
Vehicles with a spare tire ...... 514
Floor mats .................................. 24
Fluid
Automatic transmission......... 550
Brake .................................... 551
Continuously variable
transmission ....................... 550
Washer ................................. 447
Fog lights ................................. 191
Replacing light bulbs............. 473
Switch ................................... 191
Wattage ................................ 553
Front interior light ................... 396
Front passenger occupant
classification system .............. 46
Front seats ............................... 120
Adjustment ............................ 120
Cleaning................................ 417
Correct driving posture ........... 26
Head restraints ..................... 124
Seat heaters ......................... 411
Front turn signal lights ........... 182
Replacing light bulbs............. 476
Turn signal lever ................... 182
Wattage ................................ 553Fuel ........................................... 194
Capacity................................ 546
Fuel gauge........................ 77, 82
Fuel pump shut off system ... 491
Information............................ 554
Refueling .............................. 194
Type.............................. 194, 546
Warning light......................... 494
Fuel filler door ......................... 194
Refueling .............................. 194
Fuel pump shut off system..... 491
Fuses ........................................ 467
Gauges ................................. 77, 82
Glove box ................................. 399
