Start the engine of the second vehicle. Increase the engine speed
slightly and maintain at that level for approximately 5 minutes to
recharge the battery of your vehicle.
Vehicles with a smart key system: Open and close any of the doors
of your vehicle with the engine switch off.
Vehicles without a smart key system:
Maintain the engine speed of the second vehicle and turn the
engine switch to the “ON” position, then start the vehicle's engine.
Vehicles with a smart key system:
Maintain the engine speed of the second vehicle and turn the
engine switch to IGNITION ON mode, then start the vehicle's
engine.
Once the vehicle’s engine has started, remove the jumper cables in
the exact reverse order from which they were connected.
Once the engine starts, have the vehicle inspected at your Toyota
dealer as soon as possible.4
5
6
7

5358-2. Steps to take in an emergency
8
When trouble arises
COROLLA_TMMMS_TMMC_U (OM12F00U)
■Starting the engine when the battery is discharged
The engine cannot be started by push-starting.
■To prevent battery discharge
●Turn off the headlights and the audio system while the engine is off.
●Turn off any unnecessary electrical components when the vehicle is running
at a low speed for an extended period, such as in heavy traffic.
■Charging the battery
The electricity stored in the battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of cer-
tain electrical appliances. If the vehicle is left for a long time, the battery may
discharge, and the engine may be unable to start. (The battery recharges
automatically during driving.)
■When recharging or replacing the battery
●Vehicles with a smart key system: In some cases, it may not be possible to
unlock the doors using the smart key system when the battery is dis-
charged. Use the wireless remote control or the mechanical key to lock or
unlock the doors.
●The engine may not start on the first attempt after the battery has recharged
but will start normally after the second attempt. This is not a malfunction.
●Vehicles with a smart key system: The engine switch mode is memorized by
the vehicle. When the battery is reconnected, the system will return to the
mode it was in before the battery was discharged. Before disconnecting the
battery, turn the engine switch off.
If you are unsure what mode the engine switch was in before the battery dis-
charged, be especially careful when reconnecting the battery.
●Make sure that the key is not inside the vehicle when recharging or replac-
ing the battery. The key may be locked in the vehicle if the alarm is acti-
vated. (P. 69)

603Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12F00U)
Eco drive mode ........................ 175
Eco Driving Indicator ................ 89
Electric Power Steering
(EPS)....................................... 211
Function ................................ 211
Warning light ......................... 493
Electronic key ............................ 92
Battery-saving function ......... 114
If the electronic key does not
operate properly ................. 529
Replacing the battery ............ 464
Emergency, in case of
If a warning buzzer
sounds ................................ 492
If a warning light turns on...... 492
If a warning message or
indicator is displayed .......... 504
If the battery is discharged.... 532
If the electronic key does not
operate properly ................. 529
If the engine will not start ...... 526
If the shift lever cannot be
shifted from P ..................... 528
If you have a flat tire ............. 514
If you think something is
wrong.................................. 490
If your vehicle becomes
stuck ................................... 540
If your vehicle has to be
stopped in an emergency ... 483
If your vehicle needs to be
towed .................................. 485
If your vehicle overheats ....... 537Emergency flashers ................ 482
Engine ...................................... 546
Compartment ........................ 435
Engine switch ............... 161, 164
Hood ..................................... 431
How to start the
engine ........................ 161, 164
Identification number ............ 545
If the engine will not start ...... 526
Ignition switch
(engine switch) ........... 161, 164
Overheating .......................... 537
Engine coolant......................... 440
Capacity................................ 548
Checking............................... 440
Preparing and checking
before winter ...................... 216
Engine coolant temperature
gauge ................................. 77, 82
Engine immobilizer system ...... 66
Engine oil ................................. 436
Capacity................................ 546
Checking............................... 436
Preparing and checking
before winter ...................... 216
Engine switch .................. 161, 164
EPS
(Electric Power Steering) ..... 211
Function ................................ 211
Warning light......................... 493
E

609Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12F00U)
Shift lever ......... 172, 174, 176, 180
Automatic transmission......... 172
Continuously variable
transmission ............... 174, 176
If the shift lever cannot
be shifted from P ................ 528
Manual transmission ............. 180
Shift lock system ..................... 528
Side airbags ............................... 34
Side marker lights ................... 184
Light switch ........................... 184
Replacing light bulbs..... 475, 477
Wattage ................................ 553
Side mirrors ............................. 131
Adjusting and folding ............ 131
Side turn signal lights ............. 182
Replacing light bulbs............. 480
Turn signal lever ................... 182
Wattage ................................ 553
Smart key system .................... 111
Antenna location ................... 111
Entry functions ................ 97, 106
Starting the engine................ 164
Snow tires ................................ 218
Spare tire .................................. 514
Inflation pressure .................. 552
Storage location .................... 515
Spark plug ................................ 548
Specifications .......................... 548
Speech command system*
Speedometer ........................ 77, 82
Steering lock
Column lock release ..... 162, 169
Steering lock system warning
message ............................. 510
Steering wheel ......................... 127
Adjustment ............................ 127
Audio switches ...................... 226
Stop lights
Replacing light bulbs............. 477Storage feature ........................ 398
Stuck
If the vehicle becomes
stuck ................................... 540
Sun visors ................................ 403
Sun shade
Roof ...................................... 138
Switches
Audio remote control
switches ............................. 226
Compass switch ................... 407
Cruise control switch ............ 197
“DISP” switch .................... 79, 84
Door lock switches................ 100
“ECO MODE” switch............. 175
Emergency flashers
switch ................................. 482
Engine switch ............... 161, 164
Fog light switch ..................... 191
Ignition switch ............... 161, 164
Light switches ....................... 184
Moon roof switches............... 137
Outside rear view mirror
switches ............................. 131
Paddle shift switches .... 177, 178
Power door lock switch ......... 100
Power window switches........ 133
Rear window and outside
rear view mirror
defoggers switch ........ 381, 389
Seat heater switches ............ 411
Sport mode switch ................ 177
Talk switch ............................ 376
Telephone
switches ..................... 260, 354
Tire pressure warning reset
switch ................................. 450
VSC OFF switch ................... 212
Window lock switch .............. 133
Windshield wiper and
washer switch..................... 192
*: For vehicles with a navigation system, refer to the
“Navigation System Owner’s Manual”.
