2014 TOYOTA CAMRY engine oil capacity

556 6-1. Specifications
Lubrication system
*: The engine oil capacity is a reference quantity to be used when changing theengine oil. Warm up and turn off the engine, wait more than 5 minutes, and
check the oil level on the dipstick.
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Oil capacity
(Drain and refill
 refer-
ence*) With filter
Without filter 2.5 L 4-cylinder (2AR-FE) engine
4.6 qt. (4.4 L, 3.9 Imp. qt.)
3.5 L V6 (2GR-FE) engine
6.4 qt. (6.1 L, 5.4 Imp. qt.)
2.5 L 4-cylinder (2AR-FE) engine
4.2 qt. (4.0 L, 3.5 Imp. qt.)
3.5 L V6 (2GR-FE) engine
6.0 qt. (5.7 L, 5.0 Imp. qt.)
Outside temperature

575
6-1. Specifications
6
Vehicle specifications
Warning: The temperature grades of a tire assume that it is properly
inflated and not overloaded.
Excessive speed, underinflation, or
excessive loading, either sepa-
rately or in combination, can caus e heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

609
Alphabetical index
Electric power steering........... 209
Electronic key
If the electronic key does not operate properly ........... 536
Emergency flashers
Switch ................................... 498
Emergency, in case of If a warning light turns on ..... 505
If the electronic key does
not operate properly ........... 536
If the engine will not start...... 532
If the shift lever cannot be
shifted from P ..................... 534
If the vehicle has
discharged battery ............. 539
If the warning buzzer sounds ............................... 505
If you have a flat tire ............ 520
If you lose your keys............. 535
If you think something is wrong ................................. 503
If your vehicle becomes stuck................................... 547
If your vehicle has to be stopped in an emergency... 548
If your vehicle needs to
be towed ............................ 499
If your vehicle overheats ...... 544 Engine
Compartment ........................440
Engine switch ................147, 150
Hood......................................437
How to start the
engine .........................147, 150
Identification number .............552
If the engine will not start ......532
Ignition switch................147, 150
Overheating...........................544
Engine coolant
Capacity ................................558
Checking ...............................447
Preparing and checking before winter .......................229
Engine coolan t temperature
display ....................................172
Engine immobilizer system.......96
Engine oil Capacity ................................556
Checking ...............................442
Preparing and checking before winter .......................229
Engine switch light ..................371
EPS ............................................209
Event data recorder ...................24E

612 Alphabetical index
Noise from under vehicle ..........21
Odometer .................................. 172
OilEngine oil .............................. 442
Opener Fuel filler door .........................91
Hood...................................... 437
Trunk .......................................61
Outside rear view mirrors
Adjusting and folding ...............82
Defogger ............................... 253
Outside temperature
display .................................... 387
Overheating, Engine ................544
Parking brake ........................... 170
Parking lights Replacing light bulbs ............. 486
Switch.................................... 191
Wattage ................................. 563
Personal lights Switch.................................... 373
Wattage ................................. 563
Power outlet ............................. 390
Power windows ..........................84
Radiator .................................... 448
Radio ......................................... 278
Rear seats Folding down ...........................68
Rear side marker lights
Replacing light bulb ............... 486
Switch.................................... 191
Wattage ................................. 563
Rear turn signal lights Replacing light bulbs ............. 486
Wattage ................................. 563 Rear view mirror
Compass ............................... 408
Rear window defogger ............ 253
Replacing Fuses .................................... 474
Key battery ............................ 469
Light bulbs............................. 486
Tires ...................................... 520
Reporting safety defects for U.S.A. owners ........................ 590
Safety Connect......................... 412
Seat belts Adjusting the seat belt............. 72
Automatic Locking Retractor ............................... 74
Child restraint system installation........................... 126
Cleaning and maintaining
the seat belts ...................... 424
Emergency Locking Retractor ............................... 74
How to wear your seat belt ..... 72
How your child should wear the seat belt .......................... 74
Pregnant women, proper seat belt use .............. 74
Reminder light ....................... 508
Seat belt extenders ................. 75
Seat belt pretensioners ........... 73
Seat heaters ............................. 393
Seating capacity ...................... 228N
O
P
R
S

615
Alphabetical index
Warning buzzers
Brake system........................ 505
Downshifting ................. 160, 166
Electric power steering system................................ 506
Open door ............................ 508
Seat belt reminder ................ 508
Warning lights
Anti-lock brake system ......... 506
Blind Spot Monitor ................ 506
Brake assist system ............. 506
Brake system........................ 505
Charging system .... .............. 506
Cruise control indicator
light .................................... 506
Electric power steering system................................ 506
Engine coolant temperature........................ 506
Engine oil pressure............... 506
Low fuel level........................ 508
Maintenance reminder light .................................... 508
Malfunction indicator lamp.... 506
Open door ............................ 508
Pretensioners ....................... 506
Seat belt reminder light ........ 508
Slip indicator ......................... 506
Smart key system ... .............. 512
SRS airbags ......................... 506
Tire pressure warning light .................................... 508
Washer fluid ......................... 508 Washer
Preparing and checking
before winter .......................229
Refilling .................................453
Switch....................................200
Washing and waxing ...............420
Weight Cargo capacity ......................224
Load limits .............................228
Weight ...................................552
Wheels ......................................464
Window glasses ........................84
Window lock switch ...................84
Windows
Power windows .......................84
Rear window defogger ..........253
Washer ..................................200
Windshield wipers ...................200
Wireless remote control key Replacing the battery ............469
Wireless remote control ..........49
WMA disc ..................................280W

620
GAS STATION INFORMATION
Auxiliary catch leverP. 437Trunk openerP. 6 1Fuel filler door P. 9 1
Hood lock release lever
P. 4 3 7
Fuel filler door opener P. 9 1Tire inflation pressure
P. 561
Fuel tank capacity
(Reference) 17.0 gal. (64.35 L, 14.2 Imp. gal.)
Fuel type
P. 555
Cold tire inflation pressureP. 561
Engine oil
capacity
(Drain and refill

reference)
2.5 L 4-cyl-
inder
(2AR-FE)
engine qt. (L, Imp. qt.)
With filter 4.6 (4.4, 3.9)
Without filter 4.2 (4.0, 3.5)
3.5 L V6
(2GR-FE)
engine With filter 6.4 (6.1, 5.4)
Without filter 6.0 (5.7, 5.0)
Engine oil type
P. 556
