2014 TOYOTA CAMRY engine old

554 6-1. Specifications
Engine
Model2AR-FE 2GR-FE
Ty pe4-cylinder in line,
4-cycle, gasoline 6-cylinder V type,
4-cycle, gasoline
Bore and stroke
3.54 
3.86 in.
(90.0  98.0 mm) 3.70 
3.27 in.
(94.0  83.0 mm)
Displacement 152.2 cu.in. (2494 cm3) 210.9 cu.in. (3456 cm3)
Drive belt tension Automatic adjustment
Valve clearance
(engine cold) Automatic adjustment
NOTICE
■
Drive belt type (2.5 L 4-cy linder [2AR-FE] engine only)
The high strength drive belt is used for the generator side drive belt.
When replacing the drive belt, use Toyota genuine drive belt or equivalent
high strength drive belt. If the high strength drive belt is not used, durability
of the belt may become less than expected. The high strength drive belt is a
belt with Aramid core which has higher strength compared to usually avail-
able belts with PET or PEN core.

556 6-1. Specifications
Lubrication system
*: The engine oil capacity is a reference quantity to be used when changing theengine oil. Warm up and turn off the engine, wait more than 5 minutes, and
check the oil level on the dipstick.
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy
the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Oil capacity
(Drain and refill
 refer-
ence*) With filter
Without filter 2.5 L 4-cylinder (2AR-FE) engine
4.6 qt. (4.4 L, 3.9 Imp. qt.)
3.5 L V6 (2GR-FE) engine
6.4 qt. (6.1 L, 5.4 Imp. qt.)
2.5 L 4-cylinder (2AR-FE) engine
4.2 qt. (4.0 L, 3.5 Imp. qt.)
3.5 L V6 (2GR-FE) engine
6.0 qt. (5.7 L, 5.0 Imp. qt.)
Outside temperature

557
6-1. Specifications
6
Vehicle specifications
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allows
cold startability. Oils with a lower value before the W allow for easier
starting of the engine in cold weather.
• The 20 in 0W-20 indicates the viscosity characteristic of the oil when the oil is at high temperature. An oil with a higher viscosity (one with a
higher value) may be better suited if the vehicle is operated at high
speeds, or under extreme load conditions.
How to read oil container label:
The International Lubricant Spec ification Advisory Committee
(ILSAC) Certification Mark is added to some oil containers to help
you select the oil you should use.

566 6-1. Specifications
■Recommendation of the use of gaso line containing detergent additives
● Toyota recommends the use of gasoline that contains detergent additives
to avoid the build-up of engine deposits.
● All gasoline sold in the U.S.A. contains minimum detergent additives to
clean and/or keep clean intake systems, per EPA’s lowest additives con-
centration program.
● Toyota strongly recommends the use of Top Tier Detergent Gasoline. For
more information on Top Tier Detergent Gasoline and a list of marketers,
please go to the official website www.toptiergas.com.
■ Recommendation of the use of cleaner burning gasoline
Cleaner burning gasoline, including reformulated gasoline that contains oxy-
genates such as ethanol or MTBE (Methyl Tertiary Butyl Ether) is available in
many areas.
Toyota recommends the use of cleaner burning gasoline and appropriately
blended reformulated gasoline. These types of gasoline provide excellent
vehicle performance, reduce vehicle emissions and improve air quality.
■ Non-recommendation of the use of blended gasoline
●If you use gasohol in your vehicle, be sure that it has an octane rating no
lower than 87.
● Toyota does not recommend the use of gasoline containing methanol.
●Use only gasoline containing up to 15%
ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 15% etha-
nol, including from any pump labeled
E30, E50, E85 (which are only some
examples of fuel containing more than
15% ethanol).DO NOT use gasoline
containing more than 15%
ethanol.
(30% ethanol)
(50% ethanol)
(85% ethanol)

575
6-1. Specifications
6
Vehicle specifications
Warning: The temperature grades of a tire assume that it is properly
inflated and not overloaded.
Excessive speed, underinflation, or
excessive loading, either sepa-
rately or in combination, can caus e heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

608 Alphabetical index
Child safetyAirbag precautions ................111
Battery precautions ....... 451, 542
Child restraint system............ 122
Child-protectors .......................57
How your child should wear
the seat belt ..........................74
Installing child restraints ........ 126
Moon roof precautions ............90
Power window lock switch.......84
Power window precautions .....86
Removed key battery
precautions ......................... 472
Seat belt extender
precautions ...........................78
Seat belt precautions ..............76
Seat heater precautions ........ 394
Trunk precautions ...................63
Cleaning Exterior .................................. 420
Interior ................................... 423
Seat belts .............................. 424
Clock ......................................... 386
Coat hooks ............................... 397
Coin holder ............................... 378
Compass ................................... 408
Condenser ................................ 448
Console box ............................. 377
Cooling system
Engine overheating ............... 544
Cruise control........................... 205
Cup holder ................................ 380
Curtain shield airbags ............. 104
Customizable features............. 581 Daytime running light
system .................................... 195
Defogger Outside rear view mirror........ 253
Rear window ......................... 253
Dimensions .............................. 552
Dinghy towing .......................... 234
Do-it-yourself maintenance .......................... 434
Door courtesy light Door courtesy light ................ 371
Wattage................................. 563
Doors Door lock ..................... 34, 49, 55
Door windows ......................... 84
Outside rear view mirrors ........ 82
Driver's seat belt reminder
light ......................................... 508
Driving Break-in tips .......................... 137
Correct posture ..................... 102
Procedures............................ 136
Winter driving tips ................. 229D

612 Alphabetical index
Noise from under vehicle ..........21
Odometer .................................. 172
OilEngine oil .............................. 442
Opener Fuel filler door .........................91
Hood...................................... 437
Trunk .......................................61
Outside rear view mirrors
Adjusting and folding ...............82
Defogger ............................... 253
Outside temperature
display .................................... 387
Overheating, Engine ................544
Parking brake ........................... 170
Parking lights Replacing light bulbs ............. 486
Switch.................................... 191
Wattage ................................. 563
Personal lights Switch.................................... 373
Wattage ................................. 563
Power outlet ............................. 390
Power windows ..........................84
Radiator .................................... 448
Radio ......................................... 278
Rear seats Folding down ...........................68
Rear side marker lights
Replacing light bulb ............... 486
Switch.................................... 191
Wattage ................................. 563
Rear turn signal lights Replacing light bulbs ............. 486
Wattage ................................. 563 Rear view mirror
Compass ............................... 408
Rear window defogger ............ 253
Replacing Fuses .................................... 474
Key battery ............................ 469
Light bulbs............................. 486
Tires ...................................... 520
Reporting safety defects for U.S.A. owners ........................ 590
Safety Connect......................... 412
Seat belts Adjusting the seat belt............. 72
Automatic Locking Retractor ............................... 74
Child restraint system installation........................... 126
Cleaning and maintaining
the seat belts ...................... 424
Emergency Locking Retractor ............................... 74
How to wear your seat belt ..... 72
How your child should wear the seat belt .......................... 74
Pregnant women, proper seat belt use .............. 74
Reminder light ....................... 508
Seat belt extenders ................. 75
Seat belt pretensioners ........... 73
Seat heaters ............................. 393
Seating capacity ...................... 228N
O
P
R
S

613
Alphabetical index
Seats
Adjustment ............................. 65
Adjustment precautions .......... 67
Child seats/child restraint system installation.............. 126
Cleaning ............................... 423
Head restraint ......................... 70
Properly sitting in the seat .... 102
Rear seat folding down........... 68
Seat heaters ......................... 393
Service reminder
indicators .............................. 185
Shift lever Automatic
transmission ............... 157, 161
If the shift lever cannot be shifted from P ................ 534
Shift lock system..................... 534
Side airbags ............................. 104
Side marker lights Replacing light bulbs ............ 486
Switch ................................... 191
Wattage ................................ 563
Side mirror Adjusting and folding .............. 82
Defogger............................... 253
Smart key system Entry function ......................... 34
Starting the engine ............... 150
Spare tire Inflation pressure .................. 460
Storage location ................... 520
Spark plug................................ 558
Specifications .......................... 552
Speedometer ........................... 172 Steering
Column lock release......148, 154
Steering wheel Adjustment ..............................79
Stop lights
Replacing light bulbs .............486
Wattage .................................563
Storage feature.........................375
Storage precautions ................224
Stuck If your vehicle becomes
stuck ...................................547
Sun visors.................................384
Sunshade Roof.........................................88
Switch Emergency flasher switch .....498
Engine switch ................147, 150
Fog light switch .....................198
Hazard light switch ................498
Ignition switch................147, 150
Light switches........................191
Power door lock switch ...........55
Power window switch ..............84
Window lock switch .................84
Wiper and washer switch ......200
