2014 TOYOTA CAMRY HYBRID turn signal

484
5-1. Essential information
Emergency flashers
NOTICE
■To prevent 12-volt battery discharge
Do not leave the emergency flashers on longer than necessary when the
hybrid system is not operating.
Use the emergency flashers if th e vehicle malfunctions or is
involved in an accident.
Press the switch to flash all
the turn signal lights. To turn
them off, press the switch
once again.

496 5-2. Steps to take in an emergency
■When a tire is replaced with a spare tire (vehicles with a tire pres-
sure warning system)
The compact spare tire is not equipped with a tire pressure warning
valve and transmitter. If a tire goes flat, the tire pressure warning light will
not turn off even though the flat tire has been replaced with the spare
tire. Replace the spare tire with the re paired tire and adjust the tire infla-
tion pressure. The tire pressure wa rning light will go off after a few min-
utes.
■If the tire pressure warning system is not functioning (vehicles with
a tire pressure warning system)
The tire pressure warning system will be disabled in the following condi-
tions:
(When the condition becomes normal, the system will work properly.)
●If tires not equipped with tire pressure warning valves and transmit-
ters are used
●If the ID code on the tire pressure warning valves and transmitters is
not registered in the tire pressure warning computer
●If the tire inflation pressure is 51 psi (350 kPa, 3.6 kgf/cm2 or bar) or
higher
The tire pressure warning system may be disabled in the following condi-
tions:
(When the condition becomes normal, the system will work properly.)
●If electronic devices or facilities using similar radio wave frequencies
are nearby
●If a radio set at a similar frequency is in use in the vehicle
●If a window tint that affects the radio wave signals is installed
●If there is a lot of snow or ice on the vehicle, particularly around the
wheels or wheel housings
●If non-genuine Toyota wheels are used. (Even if you use Toyota
wheels, the tire pressu re warning system may not work properly with
some types of tires.)
●If tire chains are used

560 6-1. Specifications
Light bulbs
*: If equipped
A: H11 halogen bulbs B: HB3 halogen bulbs
C: D4S discharge bulbs D: Wedge base bulbs (clear)
E: Wedge base bulbs (amber) F: Double end bulbs
Light bulbsBulb No.WTy p e
ExteriorHeadlights
Low beam
(halogen bulbs)*
Low beam
(discharge bulbs)*
High beam 

9005 55
35
60A
C B
Front side marker
lights 
5D
Rear side marker
lights 
5D
Front turn signal/park-
ing lights 
28/8 E
Rear turn signal lights 21 E
Stop/tail lights 21/5 D
License plate lights 5D
Back-up lights 921 16 D
Fog lights* 55 A
Interior Interior/front personal
lights

5D
Interior/rear personal
lights* 
8D
Rear interior light* 8F
Door courtesy lights 168 5 D
Vanity lights* 8D
Trunk light 194 3.8 D

602 Alphabetical index
EngineAccessory mode.................... 157
Compartment ........................ 429
Hood...................................... 426
How to start the
hybrid system...................... 157
Identification number ............. 550
If the hybrid system will not start ............................... 531
Ignition switch........................ 157
Overheating........................... 542
“POWER” switch ................... 157
Engine coolant Capacity ................................ 555
Checking ............................... 434
Preparing and checking before winter ....................... 229
Engine coolan t temperature
display .................................... 174
Engine oil
Capacity ................................ 553
Checking ............................... 430
Preparing and checking before winter ....................... 229
Engine/power control unit coolant
Capacity ................................ 555
Checking ............................... 434
Preparing and checking before winter ....................... 229
EPS ............................................ 207
EV drive mode .......................... 165
Event data recorder ...................23 Floor mat .................................. 388
Fluid
Brake..................................... 436
Washer.................................. 438
Fog lights
Replacing light bulbs ............. 471
Switch ................................... 198
Wattage................................. 560
Front fog lights Switch ................................... 198
Wattage................................. 560
Front passenger occupant classification system ............ 125
Front passenger's seat belt
reminder light ........................ 493
Front seats Adjustment .............................. 76
Front side marker lights Replacing light bulbs ............. 471
Wattage................................. 560
Front turn signal lights Replacing light bulbs ............. 471
Wattage................................. 560
Fuel Capacity ................................ 552
Fuel gauge ............................ 174
Gas station information ......... 612
Information ............................ 561
Refueling ............................... 102
Type ...................................... 552
Fuel door .................................. 102
Fuel filler door .......................... 102
Fuses ........................................ 460F

604 Alphabetical index
License plate lightsReplacing light bulbs ............. 471
Wattage ................................. 560
Light bulbs Replacing .............................. 471
Wattage ................................. 560
Lights Door courtesy lights .............. 364
Emergency flasher switch ..... 484
Fog light switch ..................... 198
Hazard light switch ................484
Headlights switch .................. 192
Interior light switch ................365
Personal light switch ............. 366
Replacing light bulbs ............. 471
Turn signal lever.................... 170
Vanity lights ........................... 377
Wattage ................................. 560
Load capacity ........................... 228
Lock steering column .............. 161
Maintenance Do-it-yourself maintenance ....................... 423
General maintenance ............ 418
Maintenance data.................. 550
Maintenance requirements.... 416
Reset the maintenance
data ..................................... 416
Meter Instrument panel light
control ................................. 177
Meters ................................... 174
Mirrors
Inside rear view mirror.............91
Outside rear view mirror defogger.............................. 248
Outside rear view mirrors ........93
Vanity mirrors ........................ 377 Moon roof ................................... 98
MP3 disc ................................... 274
Multi-information display ........ 185
Noise from under vehicle .......... 20
Odometer .................................. 174
Oil
Engine oil .............................. 430
Opener Fuel filler door ....................... 102
Hood ..................................... 426
Trunk ....................................... 72
Outside rear view mirrors Adjusting and folding............... 93
Defogger ............................... 248
Outside temperature display .................................... 379
Overheating, Hybrid system .................................... 542
Parking brake ........................... 172
Parking lights Switch ................................... 192
Wattage................................. 560
Personal lights
Switch ................................... 366
Wattage................................. 560
Power outlet ............................. 381
“POWER” switch ..................... 157
“POWER” switch light ............. 364
Power windows .......................... 95L
M
N
O
P

605
Alphabetical index
Radiator.................................... 436
Radio ........................................ 272
Rear seats
Folding down .......................... 79
Rear side marker lights
Replacing light bulb .............. 471
Switch ................................... 192
Wattage ................................ 560
Rear turn signal lights Replacing light bulbs ............ 471
Wattage ................................ 560
Rear view mirror Compass .............................. 398
Rear window defogger............ 248
Replacing
Fuses.................................... 460
Key battery ........................... 458
Light bulbs ............................ 471
Tires ..................................... 519
Reporting safety defects for
U.S.A. owners........................ 584 Safety Connect .........................402
Seat belts
Adjusting the seat belt .............83
Automatic Locking Retractor ...............................85
Child restraint system installation ...........................135
Cleaning and maintaining
the seat belts ......................414
Emergency Locking Retractor ...............................85
How to wear your seat belt......83
How your child should wear the seat belt ..........................86
Pregnant women, proper seat belt use ..............85
Reminder light .......................493
Seat belt extenders .................86
Seat belt pretensioners ...........84
Seat heaters..............................383
Seating capacity.......................228RS

607
Alphabetical index
Tail lights
Replacing light bulbs ............ 471
Switch ................................... 192
Wattage ................................ 560
Theft deterrent system
Alarm .................................... 108
Immobilizer system............... 106
Tire inflation pressure ............ 449
Tire information
Glossary ............................... 570
Size ...................................... 567
Tire identification number ..... 566
Uniform tire quality grading ............................... 568
Tires Chains .................................. 229
Checking .............................. 443
If you have a flat tire ............. 519
Inflation pressure .................. 449
Inflation pressure sensor ...... 444
Replacing ............................. 519
Rotating tires ........................ 443
Size ...................................... 558
Snow tires............................. 229
Spare tire .............................. 519
Tire pressure warning system........................ 443, 493
Warning light ........................ 493 Tools .........................................519
Total load capacity...................228
Towing
Dinghy towing........................234
Trailer towing.........................233
TRAC .........................................208
Traction control........................208
Transmission Hybrid transmission...............168
If the shift lever cannot be shifted from P......................533
Trip information .......................185
Trip meter .........................174, 185
Trunk Opener ....................................72
Trunk light Trunk light ...............................73
Wattage .................................560
Turn signal lights Replacing light bulbs .............471
Switch....................................170
Wattage .................................560
Vanity lights Vanity lights ...........................377
Wattage .................................560
Vanity mirrors...........................377
Vehicle data recordings ............22
Vehicle identification number ...................................550
Vehicle stability control...........208
VSC............................................208T
V
