467
4-3. Do-it-yourself maintenance
4
Maintenance and care
■
Under the instrument panel
FuseAmpereCircuit
1 ECU-IG1 NO.2 10 A Shift lock control system, seat
heaters, smart key system, tire
pressure warning system, multiplex
communication system, audio sys-
tem, navigation system, moon roof,
auto anti-glare inside rear view mir-
ror, air conditioning system
2 ECU-IG1 NO.1 10 A Electronically controlled brake sys-
tem, electric cooling fans, stop
lights, steering sensor, Vehicle
Proximity Notification System, rear
window defogger, outside rear view
mirror defogger, back-up lights,
audio system, navigation system
3 PANEL 10 A Switch illumination, air condition-
ing system, shift lever light, glove
box light, audio system, navigation
system, personal lights, interior
lights
4 TAIL 15 A Parking lights, side marker lights,
tail lights, license plate lights, fog
lights
469
4-3. Do-it-yourself maintenance
4
Maintenance and care
26 S/ROOF
10 A Moon roof
27 P/SEAT FR 30 A Power seats
28 PSB 30 A No circuit
29 D/L-AM1 20 AMultiplex communication system,
power door lock, trunk opener
switch
30 TI&TE 20 A No circuit
31 A/B 10 AOccupant classification system,
SRS airbag system
32 ECU-IG2 NO.1 7.5 A Hybrid system
33 ECU-IG2 NO.2 7.5 A Electronically controlled brake sys-
tem, smart key system
34 CIG&P/
OUTLET 15 A Power outlet
35 ECU-ACC 7.5 A Clock, outside rear view mirrors,
multiplex communication system,
audio system, navigation system
36 S/HTR&FAN F/
R 10 A Seat heaters
37 S/HTR RR 20 A No circuit
FuseAmpereCircuit
5
When trouble arises
527
5-2. Steps to take in an emergency
CAUTION
■When using the compact spare tire
●
Remember that the compact spare tire provided is specifically designed
for use with your vehicle. Do not use your compact spare tire on another
vehicle.
● Do not use more than one compact spare tire simultaneously.
● Replace the compact spare tire with a standard tire as soon as possible.
● Avoid sudden acceleration, deceleration and braking, as well as sharp cor-
nering.
■
When storing the compact spare tire
Be careful not to catch fingers or other body parts between the compact
spare tire and the body of the vehicle.
■When the compact spare tire is attached
The vehicle speed may not be correctly detected, and the following sys-
tems may not operate correctly:
●ABS & Brake assist
●Cruise control
●VSC
●TRAC
●EPS
●Navigation system (if equipped)
■Speed limit when using the compact spare tire
Do not drive at speeds in excess of 50 mph (80 km/h) when a compact
spare tire is installed on the vehicle.
The compact spare tire is not designed for driving at high speeds. Failure
to observe this precaution may lead to an accident causing death or seri-
ous injury.
576
6-2. Customization
Customizable features
Customizable FeaturesChanging by using the Entune Audio system
*1:
Press the “SETUP” button.
Press the “Vehicle” button on the “Setup” screen.
Various setting can be changed. Refer to the list of settings
that can be changed for details.
Changing by using the Entune Audio Plus system
*2 or Entune Pre-
mium Audio with Navigation system
*2:
Press the “APPS” button.
Select “Setup” on the “Apps” screen and select “Vehicle”.
Various setting can be changed. Refer to the list of settings
that can be changed for details.
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O = Available, — = Not available
*1: Audio system with “CAR” button
*2: Audio system with “APPS” button
Your vehicle includes a variety of electronic features that can be per-
sonalized to suit your preferen ces. The settings of these features
can be changed on the audio system screen or at your Toyota dealer.
STEP1
STEP2
STEP1
STEP2
