368 3-4. Using the storage features
Glove boxThe glove box can be opened by pr essing the lock release button,
locked and unlocked using the mechanical key.
Open
Lock
Unlock
CAUTION
■Caution while driving
Keep the glove box closed. In the event of sudden braking or sudden swerv-
ing, an accident may occur due to an occupant being struck by the open
glove box or the items stored inside.
Glove box
456
4-3. Do-it-yourself maintenance
Air conditioning filter
The air conditioning filter must be changed regularly to maintain air
conditioning efficiency.
■ Removal method
Turn the “POWER” switch off.
Open the glove box and
remove the glove box cover
inside the glove box.
Remove the filter cover.
■ Replacement method
Remove the air conditioning
filter and replace it with a new
one.
The “UP” marks shown on
the filter should be pointing up.
STEP1
STEP2
STEP3
467
4-3. Do-it-yourself maintenance
4
Maintenance and care
■
Under the instrument panel
FuseAmpereCircuit
1 ECU-IG1 NO.2 10 A Shift lock control system, seat
heaters, smart key system, tire
pressure warning system, multiplex
communication system, audio sys-
tem, navigation system, moon roof,
auto anti-glare inside rear view mir-
ror, air conditioning system
2 ECU-IG1 NO.1 10 A Electronically controlled brake sys-
tem, electric cooling fans, stop
lights, steering sensor, Vehicle
Proximity Notification System, rear
window defogger, outside rear view
mirror defogger, back-up lights,
audio system, navigation system
3 PANEL 10 A Switch illumination, air condition-
ing system, shift lever light, glove
box light, audio system, navigation
system, personal lights, interior
lights
4 TAIL 15 A Parking lights, side marker lights,
tail lights, license plate lights, fog
lights
603
Alphabetical index
Garage door opener ................ 391
Gas station information .......... 612
Gauges ..................................... 174
Glove box ................................. 368
Grocery bag hooks ................. 390
Hazard lights
Switch ................................... 484
Head restraints Adjusting ................................ 81
Headlights Replacing light bulbs ............ 471
Switch ................................... 192
Wattage ................................ 560
Heaters Outside rear view mirror ....... 248
Seat heater ........................... 383
Hill-start assist control ........... 207
Hood ......................................... 426
Hooks Grocery bag hooks ............... 390
Horn .......................................... 173
Hybrid system
Emergency shut off system .... 36
Energy monitor/consumption screen .................................. 41
High voltage components ....... 35
Hybrid system indicator ........ 180
“POWER” switch .................. 157
Vehicle Proximity Notification System .............. 31 I/M test.......................................422
Identification number
Electric motor ........................551
Engine ...................................551
Vehicle ..................................551
Ignition switch ..........................157
Illuminated entry system .........366
Immobilizer system..................106
Indicator lights .........................180
Initialization Items to initialize....................582
Inside rear view mirror ..............91
Interior lights Interior lights..........................364
Switch....................................365
Wattage .................................560
Jack Positioning a floor jack ..........427
Vehicle-equipped jack ...........519
Jack handle ..............................519
Keyless entry..............................64
Keys Electronic key ..........................48
If the electronic key does not operate properly............ 535
If you lose your keys .............534
Ignition switch........................157
Key number .............................48
Keyless entry...........................64
Keys ........................................48
Mechanical key .......................48
“POWER” switch ...................157
Wireless remote control key ....64G
