2014 TOYOTA 4RUNNER seat memory

TABLE OF CONTENTS2
4RUNNER (U)_(OM35A83U)For your information....................... 8
Reading this manual .................... 12
How to search .............................. 13
Pictorial index .............................. 14
1-1. For safe use
Before driving ...................... 26
For safety drive ................... 28
Seat belts ............................ 30
SRS airbags ........................ 35
Front passenger occupant classification system ......... 46
Safety information for children ............................. 52
Child restraint systems ........ 53
Installing child restraints ...... 57
Exhaust gas precautions ..... 69
1-2. Theft deterrent system Engine immobilizer system............................... 70
Alarm ................................... 72 2. Instrument cluster
Warning lights and indicators ........................... 76
Gauges and meters ............. 81
Multi-information display ...... 83
Accessory meter .................. 89
3-1. Key information Keys..................................... 94
Side doors ......................... 100
3-2. Opening, closing and locking the doors
Smart key system .............. 107
Automatic running boards ............................. 114
Back door .......................... 117
3-3. Adjusting the seats Front seats......................... 122
Rear seats ......................... 125
Driving position memory ........................... 135
Head restraints .................. 139
3-4. Adjusting the steering wheel and mirrors
Steering wheel ................... 142
Inside rear view mirror ....... 144
Outside rear view mirrors ............................. 146
3-5. Opening, closing the windows and moon
roof
Power windows.................. 148
Power back window ........... 151
Moon roof .......................... 155
1For safety and security
2Instrument cluster
3Operation of
each component

93
Operation of
each component
3
4RUNNER (U)_(OM35A83U) 3-1. Key information
Keys .................................... 94
Side doors ......................... 100
3-2. Opening, closing and locking the doors
Smart key system ............. 107
Automatic running boards ............................. 114
Back door .......................... 117
3-3. Adjusting the seats Front seats ........................ 122
Rear seats......................... 125
Driving position memory ........................... 135
Head restraints.................. 139
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 142
Inside rear view mirror ...... 144
Outside rear view mirrors ............................. 146
3-5. Opening, closing the windows and moon roof
Power windows ................. 148
Power back window .......... 151
Moon roof .......................... 155

1353-3. Adjusting the seats
3
Operation of each component
4RUNNER (U)_(OM35A83U)
Your preferred driving position (the position of the driver’s seat) can
be recorded and recalled by pressing a button.
Two different driving positions can be recorded into memory.
■Recording procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Adjust the driver’s seat to the desired positions.
While pressing the “SET” but-
ton, or within 3 seconds after
the “SET” button is pressed,
press button “1” or “2” until the
buzzer sounds.
If the selected button has already
been preset, the previously
recorded position will be overwrit-
ten.
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press one of the buttons for the
driving position you want to
recall until the buzzer sounds.
Driving position memor y
: If equipped
This feature automatically adjusts the driver’s seat to suit your
preferences.
Driving position memory
1
2
3
4
Recall procedure
1
2
3

1363-3. Adjusting the seats
4RUNNER (U)_(OM35A83U)
■To stop the position recall operation part-way through
Perform any of the following:
●Press the “SET” button.
● Press button “1” or “2”.
● Operate any of the seat adjustment switches (only cancels seat position
recall).
■ Seat positions that can be memorized ( P. 122)
All adjusted positions can be recorded.
■ Operating the driving position memory after turning the engine switch
off
Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.
■ In order to correctly use the dr iving position memory function
If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be slightly different
when it is recalled.
Each electronic key can be registered to recall your preferred driving
position.
■Registering procedure
Record your driving position to button “1” or “2” before performing
the following:
Carry only the key you want to re gister, and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
recorded properly.
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
Memory recall function
1
2
3

1373-3. Adjusting the seats
3
Operation of each component
4RUNNER (U)_(OM35A83U)
While pressing the recalled
button, press and hold the
door lock switch (either lock
or unlock) until the buzzer
sounds.
If the button could not be regis-
tered, the buzzer sounds contin-
uously for approximately 3
seconds.
■
Recall procedure
Carry the electronic key that has been registered to the driving
position, and then unlock and open the driver’s door using the
smart system or wire less remote control.
The driving position will move to the recorded position.
If the driving position is in a position that has already been recorded, the
seat will not move.
■
Cancelation procedure
Carry only the key you want to cancel and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
canceled properly.
Turn the engine switch to IGNITION ON mode.
While pressing the “SET” button, press and hold the door lock
switch (either lock or unlock) until the buzzer sounds twice.
If the button could not be canceled, the buzzer sounds continuously for
approximately 3 seconds.
■Recalling the driving position us ing the memory recall function
● Different driving positions can be registered for each electronic key. There-
fore, the driving position that is recalled may be different depending on the
key being carried.
● If a door other than the driver’s door is unlocked with the smart system, the
driving position cannot be recalled. In this case, press the driving position
button which has been set.
■ Customization
The unlock door settings of the memory recall function can be customized.
(Customizable features: P. 485)
4
1
2

4908-2. Customization
4RUNNER (U)_(OM35A83U)■
Intuitive parking assist (
P. 226)
■Driving position memory ( P. 135)
■Seat belt reminder ( P. 421)
FunctionDefault settingCustomized
setting
Buzzer volumeMax.Min. to Max.
FunctionDefault settingCustomized
setting
Selecting the door linking driv-
ing position memory with door
unlock operation
Driver’s doorAll doors
FunctionDefault settingCustomizedsetting
Vehicle speed linked seat belt
reminder buzzerOnOff

516Alphabetical index
4RUNNER (U)_(OM35A83U)
Child safety ................................ 52Airbag precautions .................. 37
Back door precautions .......... 119
Battery precautions ....... 368, 454
Child restraint system ............. 53
How your child should
wear the seat belt ................. 31
Installing child restraints ......... 57
Moon roof precautions .......... 158
Power window lock switch .... 148
Power window precautions ... 150
Rear door child-protectors .... 103
Removed electronic key battery precautions ...... 387
Seat belt extender precautions ........................... 34
Seat belt precautions .............. 56
Seat heater precautions........ 293
Child-protectors....................... 103
Cleaning ........................... 342, 344 Aluminum wheels.................. 342
Exterior ................................. 342
Interior................................... 344
Seat belts .............................. 345
Clock ......................................... 311
Compass .................................. 335
Condenser ................................ 363
Console box ............................. 299
Cooling system Engine overheating ............... 455
Crawl Control ........................... 250
Cruise control .......................... 222
Cup holders.............................. 300
Curtain shield airbags ............... 35
Customizable features ............ 485 Daytime running light
system.................................... 209
Defogger Front windshield ................... 288
Outside rear view
mirrors ........................ 282, 288
Rear window ................. 282, 288
Dimension ................................ 460
Dinghy towing.......................... 191
Display Multi-information display ......... 81
Trip information................. 83, 90
Warning message................. 426
Do-it-yourself maintenance .... 353
Door courtesy lights Wattage ................................ 469
Doors Automatic door locking and unlocking system......... 104
Back door ............................. 117
Door windows ....................... 148
Door lock ...................... 102, 118
Open door warning buzzer ... 109
Open door warning light ....... 420
Outside rear view mirrors ..... 146
Rear door child-protector ...... 103
Side doors ............................ 100
Downhill assist control system.................................... 247
Driver’s seat position memory .................................. 135
Driving ...................................... 160
Break-in tips.......................... 161
Correct driving posture ........... 28
Driving assist systems .......... 260
Off-road precautions ............. 273
Procedures ........................... 160
Winter drive tips .................... 269D

518Alphabetical index
4RUNNER (U)_(OM35A83U)
Flat tire...................................... 433
Floor mats .................................. 26
FluidAutomatic transmission......... 467
Brake .................................... 467
Power steering ...................... 468
Washer ................................. 370
Fog lights ................................. 211 Replacing light bulbs............. 391
Switch ................................... 211
Wattage ................................ 469
Four-wheel drive system ............................ 232, 236
Front passenger occupant classification system .............. 46
Front personal lights ............... 296
Front seats ............................... 122
Adjustment ............................ 122
Cleaning................................ 344
Correct driving posture ........... 28
Driving position memory ....... 135
Head restraints ..................... 139
Seat heaters ......................... 293
Seat position memory ........... 135
Seat ventilators ..................... 293
Front side marker lights.......... 205
Light switch ........................... 205
Replacing light bulbs............. 398
Wattage ................................ 469 Front turn signal lights ........... 203
Replacing light bulbs ............ 396
Turn signal lever ................... 203
Wattage ................................ 469
Fuel ........................................... 219
Capacity................................ 462
Fuel gauge.............................. 81
Fuel pump shut off system ... 417
Information............................ 470
Refueling .............................. 219
Type.............................. 219, 462
Warning light......................... 420
Fuel filler door ......................... 219 Refueling .............................. 219
Fuel pump shut off system..... 417
Fuses ........................................ 388
Garage door opener ................ 323
Gauges ....................................... 81
Glove box ................................. 299
Grocery bag hooks.................. 308
F
G
