unless the parking brake is applied or a brake fault is
detected. If the light does not illuminate, have the light
inspected by an authorized dealer.
The light also will turn on when the parking brake is
applied with the ignition switch in the ON/RUN posi-
tion.
NOTE:This light shows only that the parking brake is
applied. It does not show the degree of brake application.
7. High Beam Indicator
This light shows that the high beam headlights
are on. Push the multifunction control lever
away from you to switch the headlights to high
beam. Pull the lever toward you to switch the headlights
back to low beam. If the driver’s door is open, and the
headlights or park lights are left on, the high beam
indicator light will remain illuminated and a chime will
sound. 8. Seat Belt Reminder Light
When the ignition switch is first turned to
ON/RUN, this light will turn on for four to
eight seconds as a bulb check. During the bulb
check, if the driver’s seat belt is unbuckled, a
chime will sound. After the bulb check or when driving,
if the driver’s seat belt remains unbuckled, the seat belt
reminder light will flash or remain on continuously. Refer
to “Occupant Restraints” in “Things To Know Before
Starting Your Vehicle” for further information.
9. Air Bag Warning Light
This light will turn on for four to eight seconds
as a bulb check when the ignition switch is first
turned to ON/RUN. If the light is either not on
during starting, stays on, or turns on while
driving, have the system inspected at an authorized
204 UNDERSTANDING YOUR INSTRUMENT PANEL
Alarm.............................. .205
Anti-Lock ............................ .200
Anti-Lock Warning ..................... .332
Automatic Headlights ....................151
Brake Assist Warning ....................341
Brake Warning ........................ .202
Bulb Replacement ...................... .495
Cap Top Clearance ..................... .501
Cargo .............................. .159
Center Mounted Stop ....................499
Check Engine (Malfunction Indicator) .........200
Courtesy/Reading ..................... .157
Daytime Running ...................... .152
Electronic Stability Program (ESP) Indicator .....341
Exterior ..............................114
Fog ................................ .155
Four-Wheel Drive Indicator ................315
Hazard Warning Flasher ..................420
Headlights ........................... .151High Beam
........................... .161
High Beam Indicator .....................204
High Beam/Low Beam Select ...............161
Illuminated Entry ........................23
Instrument Cluster ..................... .200
Interior ............................. .156
Oil Pressure .......................... .205
Passing ............................. .161
Seat Belt Reminder ..................... .204
Security Alarm ........................ .205
Service .............................. .495
Tire Pressure Monitoring (TPMS) ............206
Traction Control ....................... .341
Transfer Case ......................... .315
Turn Signal ............................114
Warning (Instrument Cluster Description) ......200
Limited-Slip Differential ....................322
Loading
Vehicle ......................... .387
Tires ............................... .351
