2014 Ram 2500 tailgate

WARNING!
After using the jack and tools, always reinstall them
in the original carrier and location. While driving
you may experience abrupt stopping, rapid accelera-
tion or sharp turns. A loose jack, tools, bracket or
other objects in the vehicle may move around with
force, resulting in serious injury.
Removing The Spare Tire
1. Remove the spare tire before attempting to jack up thetruck. Attach the wheel wrench to the jack extension
tube with the curved angle facing away from the
vehicle. Insert the tube through the access hole be-
tween the lower tailgate and the top of the bumper
and into the winch mechanism tube.
Wheel Wrench And Jack Extension Tube Assembled
624 WHAT TO DO IN EMERGENCIES

3. Attach the wheel wrench to the jack extension tubewith the curved angle facing away from the vehicle.
Insert the tube through the access hole between the
lower tailgate and the top of the bumper and into the
winch mechanism tube.
Pulling The Retainer Through The Center Of The Wheel
And Positioning ItWheel Wrench And Jack Extension Tube Assembled And In Position6
WHAT TO DO IN EMERGENCIES 635

WARNING!
After using the jack and tools, always reinstall them
in the original carrier and location. While driving
you may experience abrupt stopping, rapid accelera-
tion or sharp turns. A loose jack, tools, bracket or
other objects in the vehicle may move around with
force, resulting in serious injury.
Removing The Spare Tire
1. Remove the spare tire before attempting to jack up thetruck. Attach the wheel wrench to the jack extension
tube with the curved angle facing away from the
vehicle. Insert the tube through the access hole be-
tween the lower tailgate and the top of the bumper
and into the winch mechanism tube.
Wheel Wrench And Jack Extension Tube Assembled
642 WHAT TO DO IN EMERGENCIES

2. Lift the spare tire with one hand to give clearance totilt the retainer at the end of the cable and position it
properly across the wheel opening. 3. Attach the wheel wrench to the jack extension tube
with the curved angle facing away from the vehicle.
Insert the tube through the access hole between the
lower tailgate and the top of the bumper and into the
winch mechanism tube.
Reinstalling The RetainerPulling The Retainer Through The Center Of The Wheel
And Positioning It
654 WHAT TO DO IN EMERGENCIES

Protection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by authorized dealer or other
service facilities using recovery and recycling equipment.
NOTE:Use only manufacturer approved A/C system
PAG compressor oil, and refrigerants.
Refrigerant Recovery And Recycling HFO 1234yf
— If Equipped
HFO 1234yf Air Conditioning Refrigerant is a hydro-
fluorocarbon (HFC) that is endorsed by the Environmen-
tal Protection Agency and is an ozone-saving product
with a low GWP (Global Warming Potential). However,
the manufacturer recommends that air conditioning ser-
vice be performed by authorized dealer or other service
facilities using recovery and recycling equipment.
NOTE: Use only manufacturer approved A/C system
PAG compressor oil, and refrigerants.
Front Driveshaft Lubrication — 2500/3500
(Four-Wheel Drive Models Only)
Lubricate the front driveshaft grease fitting at each oil
change. Refer to the “Maintenance Schedule” for the
proper maintenance intervals. Use MOPAR® Type MS-
6560 (lithium-based grease), or equivalent.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, door hinge pivot points and rollers, liftgate,
tailgate, sliding doors and hood hinges, should be lubri-
cated periodically with a lithium based grease, such as
MOPAR® Spray White Lube to assure quiet, easy opera-
tion and to protect against rust and wear. Prior to the
application of any lubricant, the parts concerned should
be wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particular
attention should also be given to hood latching compo-
nents to ensure proper function. When performing other
692 MAINTAINING YOUR VEHICLE

Side Airbag..............................76
Signals, Turn .............................119
Sliding Rear Window Power .............................. .237
SmartBeams ............................ .165
Snow Chains (Tire Chains) ...................552
Snow Plow ............................. .601
Snow Tires ............................. .544
Spare Tire .............................. .546
Spark Plugs ............................ .744
Speed Control (Cruise Control) ................181
Speedometer ............................ .283
Stabilizer/Sway Bar System ..................464
Starting .................................33
Automatic Transmission ..................385
Cold Weather ......................... .387
Engine Fails to Start .....................387
Remote ...............................33
Starting Procedures (Gas Engines) .............384Steering
Power .............................. .509
Wheel, Heated ........................ .178
Wheel, Tilt ........................... .177
Steering Wheel Audio Controls ...............353
Steering Wheel Mounted Sound System Controls . . .353
Storage Compartment, Center Seat .............231
Storage, Vehicle .......................... .375
Storing Your Vehicle ...................... .730
Sun Roof .............................. .216
Supplemental Tire Pressure Information .........551
Suspension, Air .......................... .451
Sway Control, Trailer ...................... .528
Synthetic Engine Oil ...................... .688
System, Remote Starting .....................33
Tachometer ............................. .278
Tailgate ............................... .257
Tilt Steering Column ...................... .177
Tip Start ............................... .385
10
INDEX 783
