Composure
|
Comfort
Engineering that takes you forward:
optional Porsche Communication
Management (PCM) with navigation
module and a high-resolution 7-inch
colour touchscreen. PCM is your control
centre for audio, navigation and
communication functions.Instruments.
Sport y not kitsch, practical not fanciful.
The five round instruments have one
purpose above all: to provide information.
They do so efficiently and accurately.
Their st yling is t ypically Porsche with the
rev counter exactly where you would
expect it to be: in the middle.
Another element of the Porsche identit y
is sound. Fit ted as standard, the
CDR audio system with 7-inch colour
touchscreen and the Sound Package Plus
offer outstanding performance with a
total output of 235 wat ts. Available as an
option is the BOSE
® Surround Sound
System with a total output of 445 wat ts.
In short, it delivers powerful audio playback combined with an impressive
spatial sound.

No system promises such high standards
in the 911, and fulfils them, as the
optional High-End Surround Sound
System from Burmester®, the bespoke
manufacturer based in Berlin and one of
the most respected premium audio
manufacturers worldwide. With a total output of 821
wat ts, it ensures an
incredible audio experience.
Our patented integral subwoofer enhances
the bass performance of both optional
sound systems and also saves weight.
Typically Porsche.
Ergonomics, st yle and sound. Sports car
technology, intelligently combined. The instrument cluster with a high-
resolution 4.6-inch TFT colour screen
provides you with a continuous stream of
data from the on-board computer, such
as trip mileage, journey time or average
fuel consumption. It also displays the
navigation system map, delivers various
warnings, including alerts from the Tyre
Pressure Monitoring (TPM) system and,
in 911 Carrera 4 models, tells you
the current front /rear axle torque
distribution. You can also use it to
personalise various in-car settings.
TFT display
Instruments in the 911 Carrera 4S with silver- coloured rev counter

9697
Composure
|
Comfort
CDR audio system.
Fit ted as standard, the CDR audio system
features a 7-inch colour monitor that also
acts as a touchscreen, giving you quick
and easy access to the most important
functions and menus.
The integrated CD radio supports MP3
playback and features an FM t win tuner
with RDS, 30 memory presets, dynamic
autostore and speed -sensitive volume
control. An AUX interface (e. g. for com-
patible MP3 players) is fit ted as standard
in the glove compartment. On request, the CDR audio system can
be combined with the BOSE
® Surround
Sound System or Burmester
® High-End
Surround Sound System.
Sound Package Plus.
The Sound Package Plus is fit ted as
standard. The system comprises a
separate amplifier with a total output of
235 wat ts, seven amplifier channels and
nine loudspeakers, all of which combine
to create the perfect interior sound
experience.

Identity is to do with where you come from.
Sometimes, it’s also to do with where you want to be.

Audio and communication.
CDR Plus audio system.
The CDR Plus audio system is available
on request. All functions can be operated
via the 7-inch high-resolution colour
touchscreen or the optional multifunction
steering wheel.
The radio with t win tuner receives both
digital and analogue signals and scans
in the background for the best signal.
Alongside audio CDs, the single CD/ DVD
autochanger also plays music in MP3
format as well as audio/video DVDs. The
USB stick, MP3 player, iPod® or iPhone® can be connected via a USB port. Your
music collection, podcasts or audio
books are available immediately. Thanks
to the cover art display, they are clearly
organised – and look good too.
Devices connected via USB can be oper
-
ated using CDR Plus or the optional
multifunction steering wheel. An addition -
al AUX interface can be used to connect
other external audio sources – the
sys
tem is then operated via the con
nec-
ted device.
Porsche Communication Management (PCM) including navigation module
Porsche Communication Management
(PCM) including navigation module.
Porsche Communication Management
(PCM) is available as an option for the
911 models. Powerful, multifunctional
and easy to use, PCM is your control
centre for audio, navigation and
communication functions.
The main feature is the intuitive 7-inch
high-resolution colour touchscreen.
Alternatively, you can choose to operate
PCM using conventional rotary pushbutton
controls. With a maximum of five list
items per page, the screen display is very
clearly presented. A useful help function

is displayed at the foot of the screen.
Radio functions include up to 42 memory
presets and an FM t win tuner frequency
diversit y with RDS, which continuously
scans in the background for the best
signal, and a dynamic autostore.

9899
Composure
|
Comfort
Digital radio.
The optional digital radio enables you to
receive digitally broadcast radio stations
and features a DAB t win tuner. It auto -
matically switches bet ween digital and
analogue to ensure optimum reception
of the selected station.
Telephone module.
The optional quadband GSM telephone
module offers convenience and excellent
reception. With a SIM inserted directly
into the integral SIM card reader of
CDR Plus or PCM, calls can be made
using the hands-free facilit y. For even
more convenience, the Bluetooth
®
capabilit y of a mobile phone can be used
to make calls via the SIM Access Profile
(SAP). Once the connection has been
established automatically, the mobile
phone’s aerial is switched off to conserve
battery charge and the phone operates
via the car aerial. Depending on the mobile phone model, this gives access
not only to the numbers on the SIM card,
but also to the phone’s internal memory.
Depending on the phone, it can also be
controlled using CDR Plus, PCM, the
optional multifunction steering wheel or
the optional voice control system, without
it ever leaving your pocket.
The telephone module also enables you to
establish a Bluetooth
® link with those
mobile phones that support only the
Handsfree Profile (HFP). In this case, the
GSM connection is always established
through the aerial of the mobile phone.
CDR Plus or PCM acts as a hands-free
system and you can leave the mobile
phone tucked away.
On request, a Bluetooth
® handset for the
telephone module is also available.
Stored in the centre console, it features
a display and keypad. However, the
handset cannot be used for Bluetooth
®
links established using the Handsfree
Profile (HFP).
Mobile phone preparation.
Mobile phone preparation is available
as an option so that a Bluetooth®
connection can be established with those
mobile phones that support only the
Handsfree Profile (HFP). This function
also enables you to leave your mobile
phone tucked away. The CDR audio
system, CDR Plus and PCM are able to
control only the basic functions of the
mobile phone. The GSM connection
is established through the aerial of the
mobile phone.
Voice control system.
If you require route guidance, need to
make a phone call or want to listen to the
radio, then why not just say so? Almost
all of the functions of PCM can be con -
trolled using the optional voice control
system with word -by
-word input. In the
majorit y of cases, you can simply say
the name of the menu item as seen on
1) TMC Pro is currently available in Germany, Austria and Switzerland.2) In MPEG -2 format.
The DVD-audio drive plays CDs and audio
DVDs and is MP3- compatible. Audio play -
back of video DVDs is also supported.
A six- disc CD/ DVD autochanger integrat -
ed into PCM is available as an option.
The universal audio interface (USB) in
the glove compartment enables you to
connect your iPod
® or any audio source.
Recharging is also supported. Once
connected, your iPod
® or USB stick is
then conveniently and safely operated
via the PCM, the optional multifunction
steering wheel or the optional voice
control system.
You can download the performance
display data from the Sport Chrono
Package and data from the electronic
logbook via the USB port. You can also
transfer up to 5,000 tracks (40 GB) in
MP3 format to the internal hard drive (or Jukebox) of PCM and play them from
there. Podcasts and audiobooks are
recognised and played and cover art is
displayed.
The navigation module in PCM features

a high-speed hard drive and allows you
to choose bet ween a 2D display and
a 3D perspective. In some regions, it is
possible to display the terrain (with an
overlaid satellite map) and buildings in
3D. Split screen mode enables you to
view t wo functions at once, such as the
current navigation map and a list of
symbols that represent the next driving
manoeuvre.
The navigation module also has a
dynamic route guidance function which
takes into account official traffic
messages (TMC) and additional traffic
flow sensors (TMC Pro).
1)
the screen. The voice control system
understands complete addresses when
entered as navigation destinations, as
well as phonebook entries and the names
of radio stations. Even lists can be
browsed by voice command. For added
convenience, there is no need to ‘train’
the system.
Electronic logbook.
An electronic logbook is available for
PCM as an option. It enables automatic
logging on every journey of mileage,
route distance, date, time, starting
location and destination. Data can be
downloaded to a USB stick and evaluated
on your home PC using the soft ware
supplied. The soft ware fulfils all statutory
requirements for automatic logbooks
as specified by the German revenue
authorities.
Speed limit indicator screen
Speed limit indicator.
The speed limit indicator informs the
driver about speed restrictions and the
start and end of no overtaking zones.
The information is recorded using a cam -
era and is shown on the colour TFT dis -
play in the instrument cluster or via the
PCM screen. If a traffic sign is missed –
for example due to heav y rain or dark -
ness – the speed limit stored in the navi -
gation module is automatically displayed. The function allows the driver to concen
-
trate more fully on the road ahead.
TV tuner.
The optional T V tuner is capable of
receiving unencrypted analogue and
digital television broadcasts (DVB-T)
2) to
provide entertainment between journeys.
For your safet y, the T V picture is
switched off while the car is in motion.

100101
Composure
|
Comfort
The sound of a Porsche is a unique
characteristic, and we’re not referring
only to the engine. The optional BOSE
®
Surround Sound System was specially
developed for the 911 and is therefore
perfectly tuned to the car’s specific
interior acoustics.
It has a total output of 445 wat ts and
comprises eight amplifier channels,
12 loudspeakers and a patented integral
100-watt active subwoofer. The combined
effect is a balanced acoustic pat tern that
transforms your 911 into a fast-moving
concert hall.
In combination with the CDR Plus audio
system or Porsche Communication
Management (PCM), the BOSE
® Surround
Sound System enables audio playback
of DVDs and is thus able to make full use
of the impressive sound spectrum of
5.1 digital recordings. Of course, you
can still play other audio sources, such
as CDs and MP3s, in stereo or, at the
push of a but ton, in one of the virtual
surround modes generated by BOSE
®
Centerpoint
® 2. The BOSE
®-patented AudioPilot® noise
compensation technology uses a micro -
phone to continuously measure the
ambient noise inside the vehicle and
adapts music playback instantly and
automatically so that a consistent sound
is maintained – whatever the driving
conditions.
The result is a powerful sound and
captivating 360° acoustic experience.
Cue the applause.
When you are seeking a sporting challenge,
you need the right soundtrack.

BOSE
® Surround Sound System.
1) The HFP function must be enabled in the PCM in
order to use the Aha Radio ser vices with the optional
telephone module.
Online services.
The free Aha Radio app enables you to
listen to Internet radio, news feeds,
podcasts and audiobooks on PCM via
your smartphone. You can also receive
local information, e.g. weather reports.
Points of Interest can be searched for
and then transferred to the navigation
system as destinations. Internet content
is received via your smartphone but you
operate every thing from PCM. Online
services can only be used in conjunction
with the standard-fitted universal audio
interface (iPhone
®) or the optional mobile
phone preparation or telephone module
(Android
® phones). The Aha Radio app
can be obtained from iTunes
® and
Google Play
®.1)
T V tuner

132133
BOSE® Surround Sound System
Burmester
® High
-End Surround Sound System
Porsche Exclusive.
A distinctive identity is another form
of exclusivity.
With the range of options featured in this
catalogue, you can make your Porsche
even more special. Introducing Porsche Exclusive. Have your vehicle individually
and exclusively tailored to your wishes,
even before it leaves the factory.

Aesthetically and technically, inside
and outside, using fine materials
and with customary Porsche qualit y. Our overriding principle? That your car

is uniquely handcrafted to your taste.
You will find a wide range of design options
in the separate Porsche Exclusive 911
catalogue.
Either your Porsche Centre or the
Customer Centre in Zuffenhausen

(tel. +49 (0)711 911-25977, e-mail:
[email protected]) will
be happy to answer any questions about
Porsche Exclusive that you may have.
Product9 11 C a r r e r a
9 11 C a r r e r a S
911 Carrera Cabriolet
911 Carrera S Cabriolet
9 11 C a r r e r a 4
9 11 C a r r e r a 4 S911 Carrera 4 Cabriolet911 Carrera 4S CabrioletI no. Page
Audio and communication options.
CDR Plus audio system including digital radio••••••••P2596
Porsche Communication Management (PCM) including navigation
module
••••••••P23 97
Electronic logbook
••••••••6 41 99
Voice control system
••••••••671 99
Telephone module
••••••••666 98
Bluetooth
® handset for telephone module••••••••669 98
Mobile phone preparation
••••••••619 99
BOSE
® Surround Sound System••••••••680 101
Burmester
® High -End Surround Sound System••••••••682 10 2
Six- disc CD autochanger
••••••••692 98
Six- disc CD/ DVD autochanger
••••••••693 98
T V tuner
••••••••676 99
Online services
••••••••UN1 10 0
Digital radio
••••••••691 98
Personality | Personalisation
– not available I number/extra - cost option • standard equipment ■ available at no extra cost
