Contents
Instrument panel 24
Warning and indicator lamps 25
Instrument panel screen 31
Tr i p c o m p u t e r 4 3
Distance recorder 43
Trip distance recorder 43
Ser vice indicator 44
Adjusting vehicle settings 48
Audio-CD system screen 54
Touch screen Audio-CD system screen 56
Touch screen Audio-Telematic system
screen 58
Lighting dimmer 61
Monitoring Familiarisation
Remote control key 62
"Keyless Entry and Starting" system 66
Doors 72
Boot 73
Alarm 75
Electric windows 78
Panoramic sunroof 80
Access
Front seats 81
Rear seats 85
Mirrors 87
Steering wheel adjustment 89
Ventilation 9 0
Manual heating / air conditioning 92
Automatic air conditioning 94
Rear screen demist - defrost 99
Interior fi ttings 100
Boot fi ttings 106
Comfort
Star ting - stopping the engine with the key 108
Starting - stopping the engine with
the Keyless Entry and Starting system 109
Parking brake 112
Manual gearbox 113
Gear shift indicator 114
CVT gearbox 115
Hill start assist 120
Stop & Start (Auto Stop & Go) function 121
Four wheel drive system 124
Cruise control 126
Parking sensors 129
Reversing camera 132
Driving
Lighting controls 133
Daytime running lamps 136
Automatic illumination of headlamps 136
Manual guide-me-home lighting 137
Welcome lighting 138
Headlamp adjustment 139
Wiper controls 140
Automatic rain sensitive wipers 142
Courtesy lamps 144
Boot lamp 146
Panoramic roof lighting 146
Visibility Eco-driving

.
5
Familiarisation

Temporary puncture repair kit

This kit is a complete system, consisting of a
compressor and a sealant cartridge, for the
temporary repair of a tyre.
17 7

Panoramic sunroof

This large glazed area provides incomparable
visibility and light in the passenger
compartment.
80

Reversing camera

This system is activated automatically on
engaging reverse and provides an image in the
colour screen.
132
Exterior


Front and rear parking sensors

This system warns you of the presence of
obstacles in front of or behind the vehicle when
manoeuvring for wards or backwards.

129

.
11
Familiarisation
Centre console




A.
Rear view mirror, manual or automatic.

B.
Courtesy lamp / Map reading lamps.

C.
Microphone for Audio- CD or touch screen
Audio- CD or touch screen Audio-telematic
system.

D.
Control for panoramic sunroof blind.

E.
Sunshine/rain sensor.




1.
Central adjustable air vents.

2.
Screen for the Audio- CD system or colour
screen for the Audio-telematic system.

3.
Ignition switch.
START/STOP
button (with "Keyless Entry
and Starting" system).

4.
Audio- CD system or touch screen Audio-
CD or touch screen Audio-telematic
system.

5.
Central switch panel.

6.
Temperature sensor.

7.
Manual or digital heating / air conditioning
controls.

8.
Gear lever, manual or CVT gearbox.

9.
Cigarette lighter / 12 V accessory socket.

10.
Portable ashtray.

11.
Control for 4 wheel drive system.

12 .
Cup holder.

13.
Front armrest.

18
Familiarisation
Monitoring



A.
Manual headlamp adjustment.


Side switch panel



1.
Open the glove box.

2.
Insert the key.

3.
Select the position:

"OFF"
(deactivation), with "rear facing" child seat,
"ON"
(activation), with front passenger or
"for wards facing" child seat.

4.
Remove the key keeping the switch in the
new position.



Passenger's front airbag


B.
Deactivation of the ASC/ TCL system.

C.
Deactivation of the parking sensors.

Passenger safety


D.
Deactivation of the Stop & Start
(Auto Stop & Go) function.


Starting



- Position 1: LOCK


- Position 2: ACC


- Position 3: ON


- Position 4: START



Each press on the START/STOP
button,
without action on the pedals, changes the
mode of the vehicle.


- First press: ACC mode


- Second press: ON
mode


- Third press: OFF mode





Ignition switch

START/STOP button
139
15 0
131
122157108
109

89
3
Comfort





Rear view mirror

Adjustable mirror providing a central rear ward view.
Equipped with an anti-dazzle system, which darkens the mirror glass and reduces the nuisance to
the driver caused by the sun, headlamps from other vehicles...


Manual day/night model

Adjustment



)
Adjust the mirror so that the glass is
directed correctly in the "day" position.

As a safety measure, the mirrors should be adjusted to reduce the "blind spot".


In order to ensure optimum visibility
during your manoeuvres, the mirror
lightens automatically when reverse
gear is engaged.



Day / night position



)
Pull the lever to change to the "night"
anti-dazzle position.

)
Push the lever to change to the normal
"day" position.










Automatic day/night model

By means of a sensor, which measures the
light from the rear of the vehicle, this system
automatically and progressively changes
between the day and night uses.








Steering wheel adjustment




)
When stationary
, lower the control lever
to release the steering wheel adjustment
mechanism.

)
Adjust the height and reach to suit your
driving position.

)
Pull the control lever to lock the steering
wheel adjustment mechanism.
As a safety precaution, these
operations should only be carried out
while the vehicle is stationary.

90
Comfort








Vent ilat i on


Air intake

The air circulating in the passenger
compartment is filtered and originates either
from the outside via the grille located at the
base of the windscreen or from the inside in air
recirculation mode.


Air treatment

The incoming air follows various routes
depending on the controls selected by the
driver:


- direct arrival in the passenger
compartment (air intake),

- passage through a heating circuit (heating),

- passage through a cooling circuit (air
conditioning).



Control panel

The controls of this system are grouped
together on control panel A
on the centre
console.

1.
Windscreen demisting-defrosting vents.

2.
Front side window demisting-defrosting
vents.

3.
Side adjustable air vents.

4.
Central adjustable air vents.
5.
Air outlets to the front footwells.

6.
Air outlets to the rear footwells.

7.
Temperature sensor.

8.
Sunshine / rain sensor.



Air distribution

91
3
Comfort
In order for these systems to be fully effective, follow the operation and maintenance
guidelines below:


)
To obtain an even air distribution, take care not to obstruct the exterior air intake grilles
located at the base of the windscreen, the nozzles, the vents and the air outlets, as well
as the air extractor located in the boot.

)
Do not cover the sunshine sensor, located on the dashboard; this is used for regulation
of the air conditioning system.

)
Operate the air conditioning system for at least 5 to 10 minutes, once or twice a month
to keep it in per fect working order.

)
Ensure that the passenger compartment filter is in good condition and have the filter
elements replaced regularly.
We recommend the use of a combined passenger compartment filter. Thanks to its
special active additive, it contributes to the purification of the air breathed by the
occupants and the cleanliness of the passenger compartment (reduction of allergic
symptoms, bad odours and greasy deposits).

)
To ensure correct operation of the air conditioning system, you are also advised to have
it checked regularly as recommended in the warranty and maintenance record.

)
If the system does not produce cold air, switch it off and contact a PEUGEOT dealer or
a qualified workshop.











Recommendations for ventilation and air conditioning


If after an extended stop in sunshine,
the interior temperature is very high, first
ventilate the passenger compartment for
a few moments.
Put the air flow control at a setting high
enough to quickly change the air in the
passenger compartment.
The air conditioning system does not
contain chlorine and does not present
any danger to the ozone layer.

The condensation created by the air
conditioning results in a discharge
of water under the vehicle which is
per fectly normal.

When towing the maximum load on a steep gradient in high temperatures, switching off the
air conditioning increases the available engine power and so improves the towing ability.

129
4
Driving





Parking sensors


This function cannot, in any
circumstances, take the place of the
vigilance and responsibility of the driver.



Rear parking sensors

This system indicates the proximity of an
obstacle (person, vehicle, tree, gate, etc.)
which comes within the field of detection of
sensors located in the bumper.
Certain types of obstacle (stake, roadworks
cone, etc.) detected initially will no longer be
detected at the end of the manoeuvre due to
the presence of blind spots.


Audible assistance

The proximity information is given by an
intermittent audible signal, the frequency of
which increases as the vehicle approaches the
obstacle.
When the distance between the vehicle and
the obstacle becomes less than approximately
thirty centimetres, the audible signal becomes
continuous.

The system is switched on by engaging reverse
gear. This is accompanied by an audible signal.
The indicator lamp in the button comes on to
confirm that the system is active.
The system is deactivated when you come out
of reverse gear.
