2014 OPEL ASTRA SALOON engine

34Keys, doors and windowsHeated mirrors
Operated by pressing the Ü button.
Heating functions with the engine running and is switched off
automatically after a short time.
Interior mirrors
Manual anti-dazzle
To reduce dazzle, adjust the lever on the underside of the mirror housing.
Automatic anti-dazzle
Dazzle from following vehicles at
night is automatically reduced.

38Keys, doors and windowsHeated rear window
Operated by pressing the Ü button.
Heating functions with the engine running and is switched off
automatically after a short time.
Astra TwinTop: The heated rear
window and heated exterior mirrors are deactivated when the roof is
open.
Depending on the engine type, the
heated rear window comes on
automatically when the diesel particle filter is being cleaned.
Sun visors
The sun visors can be folded down or swivelled to the side to prevent
dazzling.
If the sun visors have integral mirrors, the mirror covers should be closed
when driving.
Panoramic windscreen
To open roof lining: Turn handle to the right and move roof lining rearward to
a suitable position.
To close roof lining: Move forward to
a suitable position. When moved all
the way forward, the roof lining
engages in position.
Note
Close the sun visors before sliding
the roof lining.

42Keys, doors and windows
With vehicle stationary unlock the
vehicle. Press button q again and
keep pressed until the roof has
opened fully and the boot lid has
closed.
During operation with the remote
control, the door windows are opened completely.
Close
Hold button < in the roof console
depressed until the roof and boot lid are completely closed.
An acoustic signal sounds at the end
of the closing procedure.
The door windows are opened slightly before the roof is closed. If button
< is pressed again after the
acoustic signal sounds, the door
windows will close.
Close with remote control
With vehicle stationary, lock the
vehicle. Press button p again and
keep pressed until the roof and boot
lid have closed completely.
Note ■ Do not open the load compartment until the acoustic signal indicating
the end of the roof opening or
closing procedure has sounded.
■ The load compartment blind must always be closed during roof
operation.
■ There must be no one and no objects at the covers behind the
rear head restraints.
■ The roof can only be operated at temperatures above -20 °C. If the
temperature is below this limit, a
gong will sound three times when
roof operation is requested.
■ Frequent operation of the roof with the engine off discharges the
battery.
■ Repeated operation of the roof without breaks can cause
overloading and therefore
malfunctions.
■ The roof can be held in an intermediate position for 9 minutes
to facilitate cleaning of roof spaces.
This is done by disengaging the
actuation switch. One minute
before the end of this period, a
continuous buzzer sounds as a
warning that the hold period is
almost over and the roof could start to move.

Seats, restraints53Heating
Adjust heating to the desired setting
by pressing the ß button for the
respective seat one or more times
with the ignition on. The control
indicator in the button indicates the
setting.
Prolonged use of the highest setting
for people with sensitive skin is not
recommended.
Seat heating is operational when the
engine is running.
Rear seats
Armrest
Saloon and Station wagon
Fold down the armrest, pulling the
strap obliquely down (45°).
TwinTop
Pull the armrest by the strap, pivot it
down and position on the sit with the
flat side up.
The armrest is held in place on the
backrest with a retaining strap. To
fully remove the armrest, disengage
the bracket at the retaining strap.

78Storage
Note■ Do not place objects on or near the
load compartment blind
■ The folded roof can only be lowered
when the blind is closed.
Otherwise, a warning buzzer will
sound three times
■ The movement of the tilted roof can
be stopped by pressing the loading aid button and another longer press
reverses the direction of the
movement
■ A confirmation buzzer is heard in the upper and lower roof end
positions when the roof is tilted
■ Only close the tailgate once the confirmation signal has sounded to
indicate that the loading aid is in its
lower end position
■ If the loading aid is not in its lower end position when the boot lid is
closed, a warning tone sounds or
the tailgate is blocked mechanically 3 41
■ Do not touch moving parts■ One minute before the end of the hold time for the raised loading aid,a warning buzzer will sound to
remind you to lower the roof
■ The loading aid is only operable when the vehicle is unlocked
■ Frequent operation of the loading aid with the engine off discharges
the battery
■ Repeated operation of the loading aid can cause malfunctions
Safety net The safety net is available on the
Station wagon and can be installed
behind the rear seats or, if the rear
seat backrests are folded and the
seat cushions raised, behind the front seats.
Passengers must not be transported
behind the safety net.Installation
There are two installation openings in the roof frame: suspend and engage
rod of net at one side, compress rod and suspend and engage at other
side.

Instruments and controls91
Connecting electrical accessorieswhile the engine is off will discharge
the battery.
Do not exceed the maximum power
consumption of 120 Watts.
Electrical accessories connected to
the socket must comply with the
electromagnetic compatibility
requirements laid down in
DIN VDE 40 839.
Do not connect any current-delivering
accessories, e.g. electrical charging
devices or batteries.
Do not damage the power outlets by
using unsuitable plugs.Cigarette lighter
The cigarette lighter is located behind
the ashtray cover. Press ashtray
cover to open.
Press in cigarette lighter. Switches off automatically once the element is
glowing. Pull out lighter.
Ashtrays
Caution
To be used only for ash and not forcombustible rubbish.

Instruments and controls93Warning lights, gauges
and indicators
Instrument cluster
In some versions, the needles of the
instruments briefly rotate to the end
position when the ignition is switched on.
Speedometer
Indicates vehicle speed.
Odometer
The bottom line displays the recorded distance.
Trip odometer The top line displays the counted
kilometres since the last reset.
To reset, hold the reset knob
depressed for a few seconds with the ignition on.
Tachometer
Displays the engine speed.
Drive in a low engine speed range for each gear as much as possible.
Caution
If the needle is in the red warning
zone, the maximum permitted
engine speed is exceeded. Engine at risk.

Instruments and controls979Danger
If a child restraint system is fitted
and the control indicator is not
illuminated while driving, the front
and side airbag for the front
passenger seat are not
deactivated.
Flashes
Fault in system or child restraint system with transponders defective
or improperly fitted 3 60.
9 Danger
Flashing of the control indicator
while driving indicates a fault.
Have the cause of the fault
remedied by a workshop
immediately.
Child restraint system with transponders 3 65.
Charging system
p illuminates red.
Illuminates when the ignition is
switched on and goes out shortly after
the engine starts.
Illuminates when the engine is
running
Stop, switch off engine. Battery is not
charging. Engine cooling may be
interrupted. In diesel engines, power
to the brake servo unit may be cut.
Seek the assistance of a workshop.
Malfunction indicator light
Z illuminates or flashes yellow.
Illuminates when the ignition is
switched on and goes out shortly after the engine starts.
Illuminates when the engine is
running Fault in the emission control system.
The permitted emission limits may be
exceeded. Immediately seek the
assistance of a workshop.Flashes when the engine is
running
Fault that could lead to catalytic
converter damage. Ease up on the
accelerator until the flashing stops.
Seek the immediate assistance of a
workshop.
Service vehicle soon A illuminates or flashes yellow.
Illuminates when the engine is
running
Fault in engine or transmission
electronics 3 140, 3 144. The
electronics switch to an emergency
running programme. Fuel
consumption may be increased and
the vehicle handling may be impaired.
If the fault persists after restarting thevehicle, consult a workshop.
Illuminates together with InSP4 in the service display Seek the assistance of a workshop for
draining the diesel fuel filter 3 110.
