NEW SYSTEM FEATURES
AROUND VIEW® MONITOR WITH MOVING OBJECT DETECTION
(MOD) (if so equipped)
With the ignition switch in the ON position, the Around
V
iew® Monitor is activated by pressing the CAMERA
button
01, located on the control panel, or by moving
the shift lever to the R (REVERSE) position. The
monitor displays various views of the position of
the vehicle.
When the shift lever is in the P (PARK), N (NEUTRAL) or D (D RIVE) position and the
CAMERA button
01 is pressed, the following views will display in order:
01
When the shift lever is in the R (REVERSE) position and the CAMERA button 01 is
pressed, the following views will display in order:
Start from any Control Panel screen
Rear view & bird’s-eye view Front view & front-side view
Press
Press
Press
Press
Press
Front view & bird’s-eye view
Rear view & front-side view
The colored guide lines on the display screen indicate vehicle width and \
approximate distances
to objects with reference to the vehicle body line.
• Red 1.5 ft (0.5 m); Y
ellow 3 ft (1 m); Green 7 ft (2 m) and 10 ft (3 m).
For information regarding how to access additional viewing cycles, please\
see your
Owner ’s Manual.
