TABLE OF cONTENTS
New SYSTe M FeaTureS
Around View® Monitor (if so equipped) ............................. 2
Blind Spot Warning (BSW) System (if so equipped) ................. 3
Advanced climate control System (if so equipped) .................. 4
e SS eNTIaL INFOr MaTION
Tire Pressure Monitoring System (TPMS) with Easy Fill Tire Alert ...... 5
Loose Fuel cap ................................................ 6
Fuel-Filler Door ................................................ 6
FI rST D rIVe Fea TureS
NISSAN Intelligent k ey
® System ................................. 7
Power Sliding Door Release (if so equipped) ....................... 8
Power Liftgate Release (if so equipped) ............................9
Front Power Seat Adjustments (if so equipped) ......................9
2
nd Row Seat Adjustments ...................................... 10
Folding the 2nd Row Seats ...................................... 10
Enter/Exit the 3rd Row Seats .................................... 10
3rd Row Seat Adjustments ...................................... 11
Automatic Drive Positioner (if so equipped) ........................ 11
Outside Mirror control Switch ................................... 12
Starting/Stopping the Engine .................................... 12
Headlight control Switch ....................................... 13
Windshield Wiper and Washer Switch ............................14
Automatic climate controls (if so equipped) ....................... 15
FM/AM/SiriusXM Satellite Radio with c D/DVD Player (if so equipped) ..17
USB/iPod
® Interface (if so equipped) ............................. 18
cruise control ................................................ 18
Power Outlets ................................................ 19
SYST eM GuIDe
Trip computer ................................................ 20
Bluetooth
® Hands-free Phone System (if so equipped) .............. 20
System Operating Tips ...................................... 20
Bluetooth
® System with Navigation (if so equipped) ..............21
Bluetooth® System without Navigation (if so equipped) ...........23
Navigation System (if so equipped) ............................... 24
NISSAN Mobile Entertainment System (MES) (if so equipped) ....... 26
HomeLink
® Universal Transceiver (if so equipped) .................. 27
Please see your Owner’s Manual for important safety
information, and system operation limitations.
• A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• children 12 and under should always ride in the rear seat properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and
supplemental restraint system (section 1)”, the “Monitor, heater, air
conditioner, audio, phone and voice recognition systems (section
4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
Additional information about your vehicle is also available in
your Owner’s Manual, Navigation System Owner’s Manual and at www.nissanusa.com.
To view detailed
instructional videos, go to
www.nissanownersinfo.mobi/2014/quest or snap this barcode with an appropriate barcode reader.
1490690_14_Quest_QRG_072513.indd 57/25/13 9:23 AM
10
FOLDING THe 2ND rOw S eaTS
Secure the seat belts on the seat
belt hooks
01 on the side wall.
To fold down the seatbacks, pull the lever 02 on the
2nd row seat.
To return the seatbacks, lift up each seatback and
push it to the upright position until it is latched.
For more information, refer to the “Safety –– Seats, seat belts and
supplemental restraint system (section 1)” of your Owner’s Manual.
01
02
2ND r Ow S eaT aDJ uSTM eNTS
To slide the seat forward or backward, pull the lever
01 up and hold it while you slide the seat forward
or backward to the desired position.
Release the lever to lock the seat in position.
To adjust the angle of the seatback, pull the lever
02 up and lean back. To bring the seatback forward,
pull the lever up and lean your body forward.
Release the lever to lock the seatback in position.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (section 1)”\
of your
Owner’s Manual.
eNTer /e XIT TH e 3rD rOw S eaTS
The 2nd row seats can tilt and slide forward for easy
entry/exit to/from the 3rd row seats.
To enter or exit the 3rd row seat, pull the lever
01 or 02 up to tilt down the seatback and slide
the seat forward.
Return and lock the 2nd row seats by sliding the seats
to the rearmost position and tilting up the seatback
after use.
For more information, refer to the “Safety –– Seats, seat belts and
supplemental restraint system (section 1)” of your Owner’s Manual.01
02
02
01
first drive features
To view detailed instructional videos regarding these and other features, please go\
to www.nissanownersinfo.mobi
1490690_14_Quest_QRG_072513.indd 107/25/13 9:23 AM
