15
FOG LIGHT SWITCH (if so equipped)
In order to operate the fog lights, you must have your
headlights on with the low beams selected.
Turn the switch (inside collar) to the position 06
to turn the fog lights on.
Turn the switch (inside collar) to the OFF position to
turn the fog lights off.
LANE CHANGE SIGNAL
To signal a lane change, move the lever up or down to the point where the indicator light \
begins to flash, but the lever does not latch.
The turn signal will flash 3 times automatically.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
WINDSHIELD WIPER AND WASHER SWITCH
Move the lever to the following positions to operate
the windshield wipers:
01 Mist (MIST) – This is a one sweep operation of
the front wipers.
02 Intermittent (INT) – Wipers operate
intermittently by moving the lever down to the
INT position and then rotating the control ring
03 to increase or decrease INT wiper speed.
04 Low (LO) – Front wipers operate at a
continuous low-speed.
05 High (HI) – Front wipers operate at a
continuous high-speed.
06 Pull the lever toward you to activate the
front washer. The front wipers will operate
several times.
WIPER DRIP
Once the wiper spray cycle is finished, there will be a short delay . Then the wipers will
sweep one more time to clear off any remaining drips from the windshield\
.
REAR WINDSHIELD WIPER AND WASHER
07 Intermittent (INT) – Rear wiper
operates intermittently.
08 Low (ON) – Rear wiper operates at a
continuous low-speed.
09 Push the lever forward to activate the rear
washer . The rear wiper will operate several times.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
0301
02
04
05
MIST
OFF
INT
LO
HI
0609
INT
ON07
08
06
1700496_14b_Leaf_QRG_021114.indd 152/11/14 3:48 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
