2014 NISSAN CUBE change time

2
new system features
NAVIGATION SYSTEM (if so equipped)
Your Navigation System can calculate a route from your current location t\
o a preferred destination. The real-time map display and turn-by-turn voice guidance will lead you
along the route.
The Navigation System will continually update your vehicle’s position. If you have deviated
from the original route, it will recalculate the route from your current\
location.
01 - Press to change the display brightness between day and night modes. Press and
hold to turn the display off. Press again to turn the display on.
02 T ouch screen display.
03 MAP - Press to display the current location map screen.

04 NAV
- Press to access the functions of the Navigation System.
05 TRAF - Press to view traffic information on the route.

06 SETUP - Press to access the system settings.

07 BACK - Press to return to the previous screen.
08 SCROLL KNOB - Turn to scroll through the items in a list. Press to select a menu item.
09 SD-card location - An SD-card with map data must be inserted here for map functions

to operate.
10 V OLUME CONTROL KNOB - Turn right to increase the volume or left to decrease

the volume.
For more information, refer to your Navigation System Owner’s Manual.
01
02
04
03
05
06
07
09
0810
1523989_14_Cube_QRG_091613.indd 29/16/13 3:30 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

Nissan, the Nissan Brand Symbol, Z and
Nissan model names are Nissan trademarks.
©
2 0 13 Nissan North America, Inc.
QR14E 0Z12U0Printing: October 2013 (07)
To view detailed instructional videos,
go to www.nissanownersinfo.mobi/2014/cube
or snap this barcode with an appropriate barcode reader.
This Quick Reference Guide is intended to provide an overview of some of the uniq\
ue features of your new vehicle. See your
Owner’s Manual, which contains important safety warnings and information about the operation and maintenance of yo\
ur vehicle, for
complete details. Nissan North America, Inc. reserves the right to make changes, at any time, without prior notice, in prices, colors,
materials, equipment, specifications, and models and to discontinue mo\
dels or equipment. Due to continuous product development
and other pre- and post-production factors, actual vehicle, materials an\
d specifications may vary. Some vehicles are shown with
optional equipment. See the actual vehicle for complete accuracy. Specifications, options and accessories may differ in Hawaii, U.S.
territories and other countries. For additional information on availability, options or accessories, see your NISSAN dealer or contact
Nissan North America, Inc.
