Indicators
Features and controls 5-121
5
N00519900127 N00520000216
The arrows will flash in
time with the corre-
sponding exterior turn signals when the turnsignal lever is used. Both arrows will flas
h when the hazard warn-
ing flasher switch is pressed.
N00520100086
A blue light comes on when the headlightsare on high beam.
N00520200191
This indicator comes on while the front foglights are on.
N00551300026
This indicator light illuminates while theposition lights are on.
Screen
Do this
Park the vehicle in a safe place, turn off the engine, and take a rest. Use this display as rough guide for taking rests during a long drive.The interval from the start of your trip until this message is displayed can be set.Refer to “Changing the function settings (When
the ignition switch is in the “ON” position)”
on page 5-103. The display and buzzer alert the driver when the
set time is reached. If you continue to drive
without having a rest, the buzzer sounds about every 5 minutes to encourage you to take a rest.  In the following cases, the time driven is reset and the display returns to the previous dis- play screen. After this, when the set time is reached again, the display and buzzer encourage you to take a rest. • The buzzer sounds 3 times.• The ignition switch is turned to the “OFF” position. • The multi-information meter switch is held (for about 2 seconds or more).
Indicators Turn signal indicators/Hazard warning lights
NOTE
 If the indicator flashes faster than usual or if the indicator stays on without flashing, checkfor a malfunctioning turn signal light bulb or turn signal connection.
High beam indicator
Front fog light indicator Position indicator
BK0200800US.book
121 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Turn signal lever
Features and controls 5-131
5
N00522601558
When changing lanes, or to making a gradual turn, hold the lever in
the “lane change” posi-
tion (1). It will return to the neutral position when you let go. Use the full position (2) when making a normal turn. The lever willreturn to the neutral position when the turn is complete. There may be times when the lever does not return to the neutral position. Thisusually happens when the steering wheel isturned only slightly. You can easily return the lever by hand. Also, when you move the lever to (1) slightlythen release it, the turn signal lights and the indicator light in the instrument cluster will flash three times.
N00522700288
If you press the flasher switch, the front andrear turn signals will flash intermittently, and so will the hazard warning lights. This is an emergency warning system and should not beused when the vehicle is in motion, except for emergencies.
If you need to leave your vehicle, the flashers will keep working after the ignition switch is turned off.
N00522800351
The front fog lights illuminate only when the headlights are on low beam. Turning the knob in the direction of the “ON” position turns on the front fog lights as wellas the indicator in the instrument cluster. To turn them off, turn the knob in the direction of the “OFF” position.
Turn signal lever
NOTE
 A light in the instrument panel flashes to show when the front and rear turn signal lights are working properly. If this light flashes faster than usual, check for a burned out turn signal light bulb or mal-functioning connection in the signal. If the panel light does not come on when the lever is moved, check for a blown fuse or aburned out bulb in the panel. Have the system inspected by your autho- rized Mitsubishi Motors dealer or a repairfacility of your choice.  It is possible to modify functions as follows: • Deactivate the turn signal light 3-flash function for lane changes. • Adjust the time required to operate the lever for the 3-flash function. For further information, please contact your authorized Mitsubishi Motors dealer.
Hazard warning flasher switch
NOTE
 If the flashers are used for several hours, the battery will run down. This could make it difficult or impossible to restart your vehicle.
Front fog light switch
BK0200800US.book
131 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Replacement of light bulbs
Vehicle care and maintenance 9-29
9
[Except for vehicles with high intensity dis- charge headlights]
[For vehicles with high intensity discharge headlights][For vehicles with high intensity discharge headlights]
Description
Wattage
ANSI Trade No. or Bulb type
1- Front turn
signal light
21 W WY21W
2- Headlight,
high beam
60 W
9005 HB3
3-
Headlight, low beam
51 W
9006 HB4
4- Front fog
light
55 W H11
5- Front side-
marker and parking light
5 W WY5W
6- Side turn sig-
nal light
5 W —
Description
Wattage or Can-
dle power
ANSI Trade No. or Bulb type
1- Front turn
signal light
21 W WY21W
2-
Daytime run- ning light
27 W 32 cp
1156
3-
Headlight, low/high beam (Dis- charge bulb)
35 W —
4- Front fog
light
55 W H11
5- Front side-
marker and parking light
5 W WY5W
6- Side turn sig-
nal light
5 W —
WA R N I N G Check with an authorized Mitsubishi Motors dealer or a repair facility of your choice when it is necessary to repair a dis- charge headlight or to replace the bulb. The power circuit, bulb and electrodesgenerate high voltages that may cause a severe electrical shock.NOTE
 It is not possible to re
pair or replace only the
bulb for the side turn signal light. Check with an authorized Mitsubishi Motors dealer or a repair facility of your choicewhen the light needs to be repaired or replaced.Rear
SC00001000-7.f
m 29 ページ ２０１３年２月１９日　火曜日　午前８時２９分

Replacement of light bulbs 9-30 Vehicle care and maintenance
9
N00950400558
N00901800105
1. When replacing the bulb on the driver’s side, remove the bo
lt (A) holding down
the relay box and move the relay boxtoward the rear of the vehicle.
Description
Wattage
ANSI Trade No. or Bulb type
7- High-
mounted stop light
——
8-
License plate light
5 W W5W
9- Back-up light 21 W W21W 10- Tail light 5 W W5W 11-
Tail and stop light
21/5 W W21/5W
12- Rear turn sig-
nal light
21 W W21W
13- Rear side-
marker light
5 W W5W
NOTE
 The high-mounted stop light uses LEDs rather than bulbs. For repair and replace- ment, contact an authorized Mitsubishi Motors dealer or a repair facility of yourchoice.
Inside
Description
Wattage
1- Trunk area light 5 W2- Dome light (rear) (if so
equipped)
8 W
3- Dome light (front)/Reading
light
8 W
Headlights (low beam, except for vehicles with high intensity discharge headlights) * - Front of the vehicle
SC00001000-7.f
m 30 ページ ２０１３年２月１９日　火曜日　午前８時２９分

Replacement of light bulbs
Vehicle care and maintenance 9-31
9
2. When replacing the bulb on the passen- ger’s side, lift up the coolant reserve tank (B). 3. Turn the bulb (C) counterclockwise, and then remove the headlight bulb with holder.
4. While pressing the tab (D), pull out the bulb (E). 5. To install the bulb, perform the removal steps in reverse.
N00901900076
1. Turn the cap (A) counterclockwise toremove it.
* - Front of the vehicle * - Front of the vehicle
CAUTIONHandle halogen light bulb with care. The gas inside a halogen light bulb is highly pressur-ized, so dropping, knocking, or scratching a halogen light bulb can cause it to shatter. Never hold the halogen light bulb with a bare hand, dirty glove, etc. The oil from your hand could cause the bulb to break the nexttime the headlights are used. If the glass surface is dirty, clean it with alcohol and let it dry completely beforeinstalling the bulb.
Headlights (high beam, except for vehicles with high intensity discharge headlights) * - Front of the vehicle
BK0200800US.bo
ok 31 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Replacement of light bulbs 9-32 Vehicle care and maintenance
9
2. Turn the bulb (B) counterclockwise to remove it. 3. While pressing the tab (C), pull out the bulb (D).
4. To install the bulb, perform the removal steps in reverse.
N00902000016
Do not attempt to disassemble or repair head- lights, and do not attempt to replace their bulbs.
N00943200121
The alignment of the headlights should be checked by an authorized Mitsubishi Motors dealer or a repair facility of your choice.
* - Front of the vehicle
CAUTIONHandle halogen light bulb with care. The gas inside a halogen light bulb is highly pressur-ized, so dropping, knocking, or scratching a halogen light bulb can cause it to shatter. Never hold the halogen light bulb with a bare hand, dirty glove, etc. The oil from your hand could cause the bulbto break the next time the headlights are used. If the glass surface is dirty, clean it withalcohol and let it dry completely before installing the bulb.
Headlights (low/high beam, for vehicles with high intensity dis- charge lights)
WA R N I N G A high voltage is present in the power cir- cuit and in the bulbs and bulb terminals.To avoid the risk of an electric shock, con- tact an authorized Mitsubishi Motors dealer or a repair facility of your choicewhenever repair or replacement is neces- sary.
Adjustment of headlight aim
BK0200800US.bo
ok 32 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Replacement of light bulbs
Vehicle care and maintenance 9-33
9
N00900300129
1. Turn the cap (A) counterclockwise to remove it.
2. Turn the socket (B) counterclockwise to remove it. 3. Turn the bulb counterclockwise while pressing it and pull it out of the socket. 4. To install the bulb, perform the removal steps in reverse.
N00917300482
1. When replacing the bulb on the driver’s side, remove the bolt (A) holding downthe relay box and move the relay box toward the rear of the vehicle.
Daytime running lights (for vehicles with high intensity dis- charge headlights) * - Front of the vehicle
*- Front of the vehicle
Front side-marker and parking lights (except for vehicles with high intensity discharge head- lights) * - Front of the vehicle
BK0200800US.bo
ok 33 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Replacement of light bulbs 9-34 Vehicle care and maintenance
9
2. When replacing the bulb on the passen- ger’s side, lift up the coolant reserve tank (B). 3. Turn the socket (C) counterclockwise to remove it.
4. Pull the bulb out of the socket. 5. To install the bulb, perform the removal steps in reverse.
N00917300466
1. To create enough work space, turn the steering wheel all the way in the direction opposite to the side you wish to replace.
2. Remove the clips (A), clip (B) and screw (C) to turn up the cover (D). 3. Turn the socket (E) counterclockwise to remove it.
* - Front of the vehicle * - Front of the vehicle
Front side-marker and parking lights (for vehicles with high intensity discharge headlights)
