2014 MERCEDES-BENZ S-Class Exterior lighting

Starting with the Start/Stop button 174
Switching off
.................................. 191
Switching off with the Start/Stop
button ............................................ 191
Switching off with the vehicle key .. 191
Tow-starting (vehicle) ..................... 378
Engine electronics
Problem (malfunction) ...................178
Engine emergency stop ....................381
Engine oil Adding ........................................... 350
Additives ........................................ 426
Checking the oil level ..................... 349
Checking the oil level using the
dipstick .......................................... 349
Display message ............................ 285
Filling capacity ............................... 426
Notes about oil grades ................... 425
Notes on oil level/consumption ....349
Temperature (on-board computer) .264
Viscosity ........................................ 426
ESP ®
(Electronic Stability
Program) AMG menu (on-board computer) ...264
Characteristics ................................. 76
Deactivating/activating ...................77
Display message ............................ 266
ETS/4ETS ........................................ 76
Function/notes ................................ 76
General notes .................................. 76
Important safety information ...........76
Warning lamp ................................. 305
ETS/4ETS (Electronic Traction
System) ................................................ 76
Exhaust see Exhaust pipe
Exhaust check ................................... 194
Exhaust pipe Cleaning ......................................... 359
Exterior lighting
Cleaning ......................................... 357
see Lights
Exterior mirrors
Adjusting ....................................... 131
Dipping (automatic) .......................132
Folding in/out (automatically). ......131
Folding in/out (electrically). ..........131 Out of position (troubleshooting)
...132
Setting ........................................... 131
Storing settings (memory function) 133
Storing the parking position ..........132
Eyeglasses compartment .................317 F
Features ............................................. 322
Filler cap see Fuel filler flap
Flat tire
Changing a wheel/mounting the
spare wheel ................................... 407
MOExtended tires ..........................365
Preparing the vehicle .....................365
TIREFIT kit ...................................... 366
Floormats ........................................... 344
Folding table ...................................... 319
Front-passenger seat Adjusting from the driver's seat ..... 114
Adjusting from the rear
compartment ................................. 114
Front windshield
see Windshield
Fuel
Additives ........................................ 425
Consumption statistics ..................251
Displaying the current
consumption .................................. 251
Displaying the range ......................251
Driving tips .................................... 194
Fuel gauge ....................................... 33
Grade (gasoline) ............................ 424
Important safety notes ..................424
Notes for AMG vehicles .................425
Problem (malfunction) ...................190
Refueling ........................................ 187
Tank content/reserve fuel .............424
Fuel filler flap
Opening ......................................... 188
Fuel level
Calling up the range (on-board
computer) ...................................... 251
Fuel tank
Capacity ........................................ 424
Problem (malfunction) ...................19010
Index

K
KEYLESS-GO Convenience closing feature .......... 101
Locking ............................................ 85
Unlocking ......................................... 85
Key positions
SmartKey ....................................... 171
Start/Stop button .......................... 171
Kickdown
Driving tips .................................... 182
Knee bag .............................................. 49L
Lamps see Warning and indicator lamps
Lane Keeping Assist
see Active Lane Keeping Assist
LATCH-type (ISOFIX) child seat
anchors ................................................ 67
License plate lamp (display
message) ............................................ 281
Light function, active Display message ............................ 282
Lighting
Light switch ................................... 138
Lights
Adaptive Highbeam Assist .............141
Adaptive Highbeam Assist PLUS .... 143
Automatic headlamp mode ............138
Cornering light function .................141
Driving abroad ............................... 138
Fogged up headlamps .................... 144
Hazard warning lamps ...................140
High beam flasher .......................... 140
High-beam headlamps ...................140
Low-beam headlamps ....................139
Parking lamps ................................ 139
Setting exterior lighting .................138
Standing lamps .............................. 139
Switching the daytime running
lamps on/off (on-board computer) 262
Switching the spotlight on/off .......262
Turn signals ................................... 140
see Interior lighting
see Replacing bulbs
Light sensor (display message) .......282 Loading guidelines
............................316
Locking see Central locking
Locking (doors)
Automatic ........................................ 92
Emergency locking ........................... 93
From inside (central locking
button) ............................................. 91
Locking centrally
see Central locking
Low-beam headlamps
Display message ............................ 280
Setting for driving abroad
(symmetrical) ................................. 138
Switching on/off ........................... 139
Lumbar support
Adjusting the 4-way lumbar
support .......................................... 125
Luxury head restraints .....................122 M
M+S tires ............................................ 386
Magic Body Control ...........................213
Malfunction message see Display messages
Matte finish (cleaning instructions) 356
MBC see Magic Body Control
mbrace
Call priority .................................... 336
Display message ............................ 272
Downloading destinations
(COMAND) ..................................... 337
Downloading routes .......................340
Emergency call .............................. 334
General notes ................................ 332
Geo fencing ................................... 340
Locating a stolen vehicle ...............339
MB info call button ........................336
Remote vehicle locking ..................338
Roadside Assistance button ..........335
Search & Send ............................... 337
Self-test ......................................... 333
Speed alert .................................... 340
System .......................................... 333
Triggering the vehicle alarm ........... 341 12
Index

Useful information
i This Operator's Manual describes all
models and all standard and optional
equipment of your vehicle available at the
time of publication of the Operator's
Manual. Country-specific differences are
possible. Please note that your vehicle may
not be equipped with all features
described. This also applies to safety-
related systems and functions.
i Read the information on qualified
specialist workshops: (Y page 27).Panic alarm
X
To activate: press0033button 0043for at
least one second.
An alarm sounds and the exterior lighting
flashes.
X To deactivate: press0033button 0043
again.
or
X Press the Start/Stop button.
The SmartKey must be in the vehicle. Occupant safety
Important safety notes
G
WARNING
Modifications to the restraint systems could
result in them not functioning properly any more. The restraint systems could then no
longer protect vehicle occupants as they are
designed to do and could fail in the event of
an accident or activate unexpectedly, for
example. There is an increased risk of injury.
Never modify parts of the restraint systems.
Do not attempt to modify the wiring as well as
electronic components or their software.
If it is necessary to modify an air bag system
to accommodate a person with disabilities,
contact an authorized Mercedes-Benz center.
USA only: for further information contact our
Customer Assistance Center at
1-800-FOR-MERCedes (1800-367-6372).
In this section, you will learn the most
important facts about the restraint system
components of the vehicle.
The restraint system consists of:
R Seat belts
R Child restraint systems
R LATCH-type (ISOFIX) child seat securing
system
Additional protection is provided by:
R SRS (Supplemental Restraint System)
R PRE-SAFE ®
R Air bag system components with:
-PASSENGER AIR BAG OFF indicator lamp
- Front-passenger seat with Occupant
Classification System (OCS)
Although the systems are independent, their
protective functions work in conjunction with
each other. Not all air bags are deployed in
an accident.
i For information on infants and children
traveling with you in the vehicle as well as
restraint systems for infants and children,
see "Children in the vehicle"
(Y page 63). 44
Occupant safetySafety

R
the exterior mirrors fold in automatically as
soon as you lock the vehicle from the
outside.
R the exterior mirrors fold out automatically
again as soon as you unlock the vehicle.
i If the exterior mirrors have been folded in
manually, they do not fold out.
Exterior mirror pushed out of position This function is only available in vehicles for
Canada.
If an exterior mirror has been pushed out of
position, proceed as follows:
X Press and hold button 0043until you hear a
click and the mirror engages audibly into
position (Y page 131).
The mirror housing is engaged again and
you can adjust the exterior mirrors as usual
(Y page 131). Automatic anti-glare mirrors
The rear-view mirror and the exterior mirror
on the driver's side automatically go into anti-
glare mode if the following conditions are met
simultaneously:
R the ignition is switched on.
R incident light from headlamps strikes the
sensor in the rear-view mirror.
The mirrors do not go into anti-glare mode if
reverse gear is engaged or if the interior
lighting is switched on. Parking position for the exterior
mirror on the front-passenger side
Setting and storing the parking position Using reverse gear
0043
Memory button M
0044 Adjustment button
0087 Button for the front-passenger side
exterior mirror
0085 Button for the driver's side exterior mirror
You can position the front-passenger side
exterior mirror in such a way that you can see
the rear wheel on that side as soon as you
engage reverse gear. You can store this
position.
X Turn the SmartKey to position 2in the
ignition lock ( Ypage 171).
X Press button 0087for the exterior mirror on
the front-passenger side.
X Engage reverse gear.
The exterior mirror on the front-passenger
side moves to the preset parking position.
X Use adjustment button 0044to adjust the
exterior mirror to a position that allows you
to see the rear wheel and the curb.
The parking position is stored.
i If you shift the transmission to another
position, the exterior mirror on the front-
passenger side returns to the driving
position. 132
MirrorsSeats, steering
wheel and mirrors

Useful information
............................138
Exterior lighting ................................ 138
Interior lighting ................................. 144
Replacing bulbs ................................. 146
Windshield wipers ............................146 137Lights and windshield wipers

Useful information
i This Operator's Manual describes all
models and all standard and optional
equipment of your vehicle available at the
time of publication of the Operator's
Manual. Country-specific differences are
possible. Please note that your vehicle may
not be equipped with all features
described. This also applies to safety-
related systems and functions.
i Read the information on qualified
specialist workshops: (Y page 27).Exterior lighting
General notes
For reasons of safety, Mercedes-Benz
recommends that you drive with the lights
switched on even during the daytime. In some
countries, operation of the headlamps varies
due to legal requirements and self-imposed
obligations. Driving abroad
Symmetrical low-beam headlamps Switch the headlamps to symmetrical low
beam in countries in which traffic drives on
the opposite side of the road from the country
where the vehicle is registered. This prevents
glare to oncoming traffic. When using
symmetrical lights, the edge of the road is not
lit as widely and as far ahead as normal.
Have the headlamps converted at a qualified
specialist workshop as close to the border as
possible before driving in these countries.
Asymmetrical low beam Have the headlamps converted back to
asymmetrical low-beam headlamps at a
qualified specialist workshop as soon as
possible after crossing the border again. Setting the exterior lighting
Setting options Exterior lighting can be set using:
R
the light switch
R the combination switch (Y page 140)
R the on-board computer (Y page 262)
Light switch Operation
00470063
Left-hand standing lamps
00480064 Right-hand standing lamps
00490060 Parking lamps, license plate and
instrument cluster lighting
004A0058 Automatic headlamp mode,
controlled by the light sensor
004B0058 Low-beam/high-beam headlamps
If you hear a warning tone when you leave the
vehicle, the lights may still be switched on.
X Turn the light switch to 0058.
The exterior lighting (except the parking/
standing lamps) switches off automatically if
you:
R remove the SmartKey from the ignition lock
R open the driver's door with the SmartKey
in position 0.
Automatic headlamp mode G
WARNING
When the light switch is set to 0058, the low-
beam headlamps may not be switched on
automatically if there is fog, snow or other 138
Exterior lightingLights and windshield wipers

causes of poor visibility due to the weather
conditions such as spray. There is a risk of an
accident.
In such situations, turn the light switch to
0058.
The automatic headlamp feature is only an
aid. The driver is responsible for the vehicle's
lighting at all times.
Only for Canada:
The daytime running lamps improve the
visibility of your vehicle during the day. The
daytime running lamps function is required by
law in Canada. It cannot therefore be
deactivated.
When the engine is running and the vehicle is
stationary: if you move the selector lever from
a drive position to P, the daytime running
lamps/low-beam headlamps go out after
three minutes.
When the engine is running, the vehicle is
stationary and in bright ambient light: if you
turn the light switch to 0060, the daytime
running lamps and parking lamps switch on.
If the engine is running and you turn the light
switch to 0058, the manual settings take
precedence over the daytime running lamps.
USA only:
The daytime running lamps improve the
visibility of your vehicle during the day. To do
this, the daytime running lamps function must
be switched on using the on-board computer
(Y page 262).
If the engine is running and you turn the light
switch to 0060or0058, the manual settings
take precedence over the daytime running
lamps.
0058 is the favored light switch setting. The
light setting is automatically selected
according to the brightness of the ambient
light (exception: poor visibility due to weather
conditions such as fog, snow or spray):
R SmartKey in position 1in the ignition lock:
the parking lamps are switched on or off automatically depending on the brightness
of the ambient light.
R With the engine running: if you have
activated the daytime running lamps
function via the on-board computer, the
daytime running lamps or the low-beam
headlamps and parking lamps are switched
on or off automatically depending on the
brightness of the ambient light.
X To switch on automatic headlamp
mode: turn the light switch to 0058.
Low-beam headlamps
Even if the light sensor does not detect that
it is dark, the parking lamps and low-beam
headlamps switch on when the ignition is
switched on and the light switch is set to the
0058 position. This is a particularly useful
function in the event of rain and fog.
X To switch on the low-beam headlamps:
turn the SmartKey in the ignition lock to
position 2or start the engine.
X Turn the light switch to 0058.
The green 0058indicator lamp in the
instrument cluster lights up.
Parking lamps
! If the battery has been excessively
discharged, the parking lamps or standing
lamps are automatically switched off to
enable the next engine start. Always park
your vehicle safely and sufficiently lit
according to legal standards. Avoid the
continuous use of the 0060parking lamps
for several hours. If possible, switch on the
0064 right or the 0063left standing lamp.
X To switch on: turn the light switch to
0060.
The green 0060indicator lamp in the
instrument cluster lights up.
Standing lamps
Switching on the standing lamps ensures the
corresponding side of the vehicle is
illuminated. Exterior lighting
139Lights and windshield wipers Z

X
To switch on the standing lamps: the
SmartKey is not in the ignition lock or it is
in position 0.
X Turn the light switch to 0063(left-hand side
of the vehicle) or 0064(right-hand side of
the vehicle). Combination switch
Turn signal 0043
High-beam headlamps
0044 Turn signal, right
0087 High-beam flasher
0085 Turn signal, left
X To indicate briefly: press the combination
switch briefly to the pressure point in the
direction of arrow 0044or0085.
The corresponding turn signal flashes three
times.
X To indicate: press the combination switch
beyond the pressure point in the direction
of arrow 0044or0085.
High-beam headlamps X
To switch on the high-beam headlamps:
turn the SmartKey in the ignition lock to
position 2or start the engine.
X Turn the light switch to 0058or0058. X
Press the combination switch beyond the
pressure point in the direction of
arrow 0043.
In the 0058position, the high-beam
headlamps are only switched on when it is
dark and the engine is running.
The blue 0057indicator lamp in the
instrument cluster lights up when the high-
beam headlamps are switched on.
X To switch off the high-beam
headlamps: move the combination switch
back to its normal position.
The blue 0057indicator lamp in the
instrument cluster goes out.
If Adaptive Highbeam Assist is active, it
controls activation and deactivation of the
high-beam headlamps (Y page 141).
If Adaptive Highbeam Assist is active, it
controls activation and deactivation of the
high-beam headlamps (Y page 143).
High-beam flasher X
To switch on: turn the SmartKey in the
ignition lock to position 1or 2, or start the
engine.
X Pull the combination switch in the direction
of arrow 0087. Hazard warning lamps
X
To switch on the hazard warning lamps:
press button 0043.
All turn signals flash. If you now switch on
a turn signal using the combination switch, 140
Exterior lightingLights and
windshield wipers
