*Some models.4–25
When Driving
Instrument Cluster and Display
Signal Indicator Lights Page
* Shift Position Indication 4-31
* SPORT Mode Indicator Light 4-89
Headlight High-Beam Indicator Light 4-45 ,
4-45
Turn Signal/Hazard Warning Indicator Lights 4-51 ,
4-58
Security Indicator Light *1 3-42
(Green)
* Mazda Radar Cruise Control (MRCC) Indicator Light 4-95
(Amber)
* Cruise Main Indicator Light 4-101
(Green)
* Cruise Set Indicator Light 4-101
Lights-On Indicator Light 4-41
*1 The light turns on when the ignition is switched on for an operation check, and turns off a few seconds later or
when the engine is started. If the light does not turn on or remains turned on, have the vehicle inspected at an
Authorized Mazda Dealer.
/C\FCA&('#*A'FKVKQPKPFD

4–33
When Driving
Transaxle
5. Take the vehicle to an Authorized
Mazda Dealer to have the system
checked.
Manual Shift Mode
The manual shift mode gives you the feel
of driving a manual transaxle vehicle by
allowing you to operate the selector lever
manually. This allows you to control
engine rpm and torque to the drive wheels
much like a manual transaxle when more
control is desired.
To change to manual shift mode, shift the
lever from D to M.
NOTE



y(For vehicles with type C instrument
cluster*1 )  If the engine speed is about to exceed
the permissible engine speed, the buzzer
sounds.
  Refer to Over Rev. Buzzer on page
7-39 .
*1 To determine which instrument
cluster is equipped on your Mazda,
Refer to Meters and Gauges on page
4-12 .



y Changing to manual shift mode while
driving will not damage the transaxle.
To return to automatic shift mode, shift the
lever from M to D.
NOTE



y If you change to manual shift mode
when the vehicle is stopped, the gear
will shift to M1.



y If you change to manual shift mode
without depressing the accelerator
pedal when driving in D range, 5th
gear/6th gear, the gear will shift to M4/
M5.
Indicators
Manual shift mode indication
In manual shift mode, the “M” of the shift
position indication in the instrument panel
illuminates.
Gear position indication
The numeral for the selected gear
illuminates.
Type A
Manual shift mode indication
Gear position indication
/C\FCA&('#*A'FKVKQPKPFD

4–98
When Driving
Mazda Radar Cruise Control (MRCC)
NOTE



y When accelerating using the SET
switch while in headway control, the set
vehicle speed can be adjusted but
acceleration is not possible. If there is
no longer a vehicle ahead, acceleration
continues until reaching the set vehicle
speed. Check the set vehicle speed by
viewing the set vehicle speed display in
the active driving display.



y When depressing the accelerator pedal,
the inter-vehicle distance display in
the display in the instrument cluster
changes to the white-line display.



y The minimum settable speed is 30 km/h
(19 mph). If the set vehicle speed
reaches 30 km/h (19 mph) using the
switch operation, constant speed travel
is maintained at about 30 km/h (19
mph) even if the SET
switch is
pressed. The Mazda Radar Cruise
Control (MRCC) system is not
canceled.
To Deactivate
The Mazda Radar Cruise Control (MRCC)
is canceled when the OFF switch is
pressed.
When the system is temporarily
canceled
In the following cases, the Mazda Radar
Cruise Control (MRCC) system is
temporarily canceled and the “MRCC
Cancelled” indication is displayed in
the display in the instrument cluster.
The Mazda Radar Cruise Control
(MRCC) indicator light (green) turns off
simultaneously.



y The CANCEL switch is pressed.



y The brake pedal is depressed.



y The parking brake is applied.



y The selector lever is shifted to park (P),
neutral (N) or reverse (R) (automatic
transaxle).



y The shift lever is in the reverse (R)
position (manual transaxle).



y In the following cases, the “MRCC
Cancelled” indication is displayed and
the beep sounds one time.


y
 The vehicle speed decreases to less
than 25 km (16 mph).


y
 The DSC has operated.


y
 The TCS has operated for a certain
period of time.


y
 The Smart City Brake Support (SCBS)
has operated.


y
 When traveling on a down slope for a
long period of time.


y
 There is a problem with the system.


y
 The engine stalls.

(Manual transaxle)



y
 The shift lever is shifted to neutral (N)
for a certain period of time.


y
 The clutch is depressed for a certain
period of time.
/C\FCA&('#*A'FKVKQPKPFD

5–2
Interior Features
Climate Control System
Operating Tips













y Operate the climate control system with
the engine running.



y To prevent the battery from being
discharged, do not leave the fan control
dial on for a long period of time with the
ignition switched ON when the engine is
not running.



y Clear all obstructions such as leaves,
snow and ice from the hood and the air
inlet in the cowl grille to improve the
system effi ciency.




y Use the climate control system to defog
the windows and dehumidify the air.



y The recirculate mode should be used
when driving through tunnels or while in
a traffi c jam, or when you would like to
shut off outside air for quick cooling of
the interior.



y Use the outside air mode for ventilation
or windshield defrosting.



y If the vehicle has been parked in direct
sunlight during hot weather, open the
windows to let warm air escape, then
run the climate control system.



y Run the air conditioner about 10 minutes
at least once a month to keep internal
parts lubricated.



y Have the air conditioner checked before
the weather gets hot. Lack of refrigerant
may make the air conditioner less
effi cient.

 The refrigerant specifi cations are
indicated on a label attached to the
inside of the engine compartment. Check
the label before refi lling the refrigerant.
If the wrong type of refrigerant is used,
it could result in a serious malfunction
of the air conditioner.
  For details, consult an Authorized
Mazda Dealer.
Label
/C\FCA&('#*A'FKVKQPKPFD

5–130
Interior Features
Bluetooth®
Symptom Cause Solution method
Pairing cannot
be performed
again The pairing
information
programmed
to the
Bluetooth
®
unit or
device is not
recognized
correctly. Perform
pairing using
the following
procedure.y Clear “Mazda”
stored in the
device.
y Perform pairing
again.
Unable to
perform pairing The
Bluetooth
®
function
and the Find
Mode/Visible
setting
*1 on
the device
may turn off
automatically
after a period
of time has
elapsed
depending on
the device. Check whether
the Bluetooth
®
function and
the Find Mode/
Visible setting
*1
on the device
are turned on
and pairing or
reconnect. Does not
connect
automatically
when starting
the engine
Automatically
connects,
but then
disconnects
suddenly
Disconnects
intermittently The device is
in a location
in which
radio wave
interference
can occur
easily, such
as inside a
bag in a rear
seat, in a rear
pocket of a
pair of pants. Move the device
to a location in
which radio wave
interference is
less likely to
occur.
Does not
connect
automatically
when starting
the engine The
programmed
pairing
information is
updated when
the device OS
is updated. Perform pairing
again.
*1 Setting which detects the existence of a device
external to the Bluetooth
® unit
NOTE



y When you update the operating
system of your mobile device (such
as Windows/Android/iOS) the pairing
information may be invalidated.
Therefore, the device may need to be
reprogrammed to the hands-free unit.



y If you pair your phone which has
already been paired to your vehicle
more than once in the past, you need to
delete “Mazda” on your mobile device.
Then, execute the Bluetooth
® search
on your mobile device once again, and
pair to a newly detected “Mazda”.



y Before you pair your device, make sure
that Bluetooth ® is “ON”, both on your
phone and on the vehicle.
Voice recognition related problems
Symptom Cause Solution
method
Poor voice
recognition
y Excessive, slow
speech.
y Excessive,
forceful speech
(shouting).
y Speaking before
the beep sound
has ended.
y Loud noise
(speaking or
noise from
outside/inside
vehicle).
y Airfl ow from
A/C is blowing
against the
microphone.
y Speaking in
off-standard
expressions
(dialect). Regarding the
causes indicated
on the left, be
careful with
how you speak.
In addition,
when numbers
are spoken in
a sequence,
recognition
ability will
improve if no
stop is placed
between the
numbers. False
recognition
of numbers
/C\FCA&('#*A'FKVKQPKPFD

6–23
Maintenance and Care
Owner Maintenance
WARNING
Do not perform maintenance work if you lack suffi cient knowledge and experience
or the proper tools and equipment to do the work. Have maintenance work done by a
qualifi ed technician:
Performing maintenance work on a vehicle is dangerous if not done properly. You can be
seriously injured while performing some maintenance procedures.

If you must run the engine while working under the hood, make certain that you
remove all jewelry (especially rings, bracelets, watches, and necklaces) and all
neckties, scarves, and similar loose clothing before getting near the engine or cooling
fan which may turn on unexpectedly:
Working under the hood with the engine running is dangerous. It becomes even more
dangerous when you wear jewelry or loose clothing.
Either can become entangled in moving parts and result in injury.

Switch the ignition to off and make sure the fan is not running before attempting
to work near the cooling fan:
Working near the cooling fan when it is running is dangerous. The fan could continue
running indefi nitely even if the engine has stopped and the engine compartment
temperature is high. You could be hit by the fan and seriously injured.

Do not leave items in the engine compartment:
After you have fi nished checking or doing servicing in the engine compartment, do not
forget and leave items such as tools or rags in the engine compartment.
Tools or other items left in the engine compartment could cause engine damage or a fi re
leading to an unexpected accident.
/C\FCA&('#*A'FKVKQPKPFD

7–19
If Trouble Arises
Overheating
Overheating
If the High engine coolant temperature
warning light illuminates, the vehicle loses
power, or you hear a loud knocking or
pinging noise, the engine is probably too
hot.
WARNING
Switch the ignition to off and make
sure the fan is not running before
attempting to work near the cooling
fan:
Working near the cooling fan when it
is running is dangerous. The fan could
continue running indefi nitely even if
the engine has stopped and the engine
compartment temperature is high. You
could be hit by the fan and seriously
injured.

Do not remove either cooling
system cap when the engine and
radiator are hot:
When the engine and radiator are hot,
scalding coolant and steam may shoot
out under pressure and cause serious
injury.

Open the hood ONLY after steam is no
longer escaping from the engine:
Steam from an overheated engine is
dangerous. The escaping steam could
seriously burn you.
If the High engine coolant temperature
warning light illuminates:
1. Drive safely to the side of the road and
park off the right-of-way.
2. Put a vehicle with an automatic
transaxle in park (P), a manual
transaxle in neutral.
3. Apply the parking brake.
4. Turn off the air conditioner.
5. Check whether coolant or steam is
escaping from the engine compartment.
If steam is coming from the engine
compartment:
Do not go near the front of the vehicle.
Stop the engine.
Wait until the steam dissipates, then
open the hood and start the engine.
If neither coolant nor steam is escaping:
Open the hood and idle the engine until
it cools.
CAUTION
If the cooling fan does not operate
while the engine is running, the engine
temperature will increase. Stop the
engine and call an Authorized Mazda
Dealer.
6. Make sure the cooling fan is operating,
then turn off the engine after the
temperature has decreased.
7. When cool, check the coolant level.
If it is low, look for coolant leaks from
the radiator and hoses.
/C\FCA&('#*A'FKVKQPKPFD

7–25
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning
Electronic Brake Force
Distribution System
Warning If the electronic brake force distribution control unit determines that some components
are operating incorrectly, the control unit may illuminate the brake system warning
light and the ABS warning light simultaneously. The problem is likely to be the
electronic brake force distribution system.WARNING
Do not drive with both the ABS warning light and brake warning light illuminated.
Have the vehicle towed to an Authorized Mazda Dealer to have the brakes
inspected as soon as possible:
Driving when the brake system warning light and ABS warning light are
illuminated simultaneously is dangerous.
When both lights are illuminated, the rear wheels could lock more quickly in an
emergency stop than under normal circumstances.
Charging System
Warning Light If the warning light illuminates while driving, it indicates a malfunction of the
alternator or of the charging system.
Drive to the side of the road and park off the right-of-way. Consult an Authorized
Mazda Dealer.CAUTION
Do not continue driving when the charging system warning light is illuminated
because the engine could stop unexpectedly.
Engine Oil Warning
Light This warning light indicates low engine oil pressure.
CAUTION
Do not run the engine if the oil pressure is low. Otherwise, it could result in extensive
engine damage.
If the light illuminates or the warning indication is displayed while driving:
1. Drive to the side of the road and park off the right-of-way on level ground.
2. Turn off the engine and wait 5 minutes for the oil to drain back into the oil pan.
3. Inspect the engine oil level 6-28 . If it's low, add the appropriate amount of engine oil
while being careful not to overfi ll.
CAUTION
Do not run the engine if the oil level is low. Otherwise, it could result in extensive
engine damage.
4. Start the engine and check the warning light.
If the light remains illuminated even though the oil level is normal or after adding oil,
stop the engine immediately and have your vehicle towed to an Authorized Mazda
Dealer.
/C\FCA&('#*A'FKVKQPKPFD
