2014 MAZDA MODEL 3 5-DOOR tow

2–22
Essential Safety Equipment
Child-Restraint
Child-Restraint Precautions
Mazda strongly urges the use of child-restraint systems for children small enough to use \
them.
You are required by law to use a child-restraint system for children in t\
he U.S. and Canada.
Check your local and state or provincial laws for specifi c requirements regarding the safety
of children riding in your vehicle.
Whatever child-restraint system you consider, please pick the appropriate one for the age
and size of the child, obey the law and follow the instructions that com\
e with the individual
child-restraint system.
A child who has outgrown child-restraint systems should sit in the rear a\
nd use seat belts,
both lap and shoulder. If the shoulder belt crosses the neck or face, move the child closer
to the center of the vehicle in the outboard seats, and towards the buck\
le on the right if the
child is seated on the center seat.
Statistics confi rm that the rear seat is the best place for all children up to 12 years \
of age,
and more so with a supplemental restraint system (air bags).
A rear-facing child-restraint system should NEVER be used on the front seat with the air
bag system activated. The front passenger's seat is also the least preferred seat for other
child-restraint systems.
(With Front Passenger Occupant Classifi cation System)
To reduce the chance of injuries caused by deployment of the front passen\
ger air bag, the
front passenger seat weight sensors work as a part of the supplemental r\
estraint system. This
system deactivates the front passenger front and side air bags and also \
the front passenger
seat belt pretensioner system when the front passenger air bag deactivat\
ion indicator light
illuminates.
When an infant or small child sits on the front passenger seat, the syst\
em shuts off the front
passenger front and side air bags and seat belt pretensioner system, so \
make sure the front
passenger air bag deactivation indicator light illuminates.
Even if the front passenger air bag is shut off, Mazda strongly recommends that children be
properly restrained and child-restraint systems of all kinds are properl\
y secured on the rear
seats which are the best place for children.
For more details, refer to "Front passenger seat weight sensors" (page \
2-56 ).
.B[EB@%$&""@&EJUJPOJOEC







*Some models.3–1
3Before Driving
Use of various features, including keys, doors, mirrors and windows.


Keys ...................................................... 3-2 Keys ............................................... 3-2
Keyless Entry System .................... 3-3
Advanced Keyless Entry System ........ 3-9
Advanced Keyless Entry
System
* ........................................... 3-9
Operational Range ....................... 3-10
Doors and Locks ................................ 3-11 Door Locks ................................... 3-11
Liftgate/Trunk Lid ........................ 3-20
Inside Trunk Release Lever
(4-Door)
* ...................................... 3-25
Fuel and Emission ............................. 3-27 Fuel and Engine Exhaust
Precautions ................................... 3-27
Fuel-Filler Lid and Cap ................ 3-30
Steering Wheel................................... 3-32 Steering Wheel ............................. 3-32
Mirrors ............................................... 3-33 Mirrors ......................................... 3-33
Windows ............................................. 3-36 Power Windows ........................... 3-36
Moonroof
* ................................... 3-39 Security System ................................. 3-41
Modifi cation and Add-On
Equipment .................................... 3-41
Immobilizer System ..................... 3-41
Theft-Deterrent System
* .............. 3-43
Driving Tips ....................................... 3-45 Break-In Period ............................ 3-45
Money-Saving Suggestions ......... 3-45
Hazardous Driving ....................... 3-46
Floor Mat ..................................... 3-46
Rocking the Vehicle ..................... 3-47
Winter Driving ............................. 3-47
Driving In Flooded Area .............. 3-49
Overloading .................................. 3-50
Driving on Uneven Road ............. 3-51
Towing ................................................ 3-52 Trailer Towing .............................. 3-52
Recreational Towing .................... 3-52
.B[EB@%$&""@&EJUJPOJOEC







3–12
Before Driving
Doors and Locks
 y(Door unlock (control) system with
collision detection)
 This system automatically unlocks the
doors in the event the vehicle is involved
in an accident to allow passengers to
get out of the vehicle immediately and
prevent being trapped inside. While the
ignition is switched ON and in the event
the vehicle receives an impact strong
enough to infl ate the air bags, all the
doors are automatically unlocked after
about 6 seconds have elapsed from the
time of the accident.
 The doors may not unlock depending on how an impact is applied, the force of
the impact, and other conditions of the
accident.
 If door-related systems or the battery is malfunctioning, the doors will not
unlock.
Locking, Unlocking with Key
All doors and the liftgate lock
automatically when the driver's door is
locked with the key.
All doors and the liftgate unlock when the
driver's door is unlocked and the key is
held in the unlock position for one second
or longer.
Turn the key toward the front to lock,
toward the back to unlock.
Lock Unlock
NOTE
Holding the key in the unlocked position in
the driver's door lock for about a second
unlocks all doors and the liftgate. To
unlock only the driver's door, insert the
key into the driver's door lock and turn
the key briefl y to the unlock position and
then immediately return it to the center
position.
Locking, Unlocking with Request
Switch (With the advanced keyless
function)
All doors and the liftgate can be locked/
unlocked by pressing the request switch
on the front doors while the key is being
carried.
(5–door)
The request switch on the liftgate can only
be used to lock all doors and the liftgate.
Front doors
Reque st switch
.B[EB@%$&""@&EJUJPOJOEC







3–52
Before Driving
Towing
Trailer Towing
YourMazda is not designed for towing.
Never tow a trailer with your Mazda.
Recreational Towing
An example of "recreational towing" is
towing your vehicle behind a motorhome.
The transaxle is not designed for towing
this vehicle on all 4 wheels.
When doing recreational towing refer
to "Towing Description" (page 7-21 )
and "Tiedown Hooks" (page 7-22 ) and
carefully follow the instructions.
.B[EB@%$&""@&EJUJPOJOEC







4–36
When Driving
Switches and Controls
Headlight High-Low Beam
Press the lever forward to turn on the high
beams.
Pull the lever back to its original position
for the low beams.
High beam
Low beam
The headlight high-beam indicator light
in the instrument cluster illuminates while
the high beams are turned on.
Flashing the Headlights
To fl ash the headlights, pull the lever fully
towards you (the headlight switch does not
need to be on).
OFF
Flashing
The headlight high-beam indicator light
in the instrument cluster illuminates
simultaneously. The lever will return to the
normal position when released.
.B[EB@%$&""@&EJUJPOJOEC







4–38
When Driving
Switches and Controls
Turn and Lane-Change
Signals
The ignition must be switched ON to use
the turn and lane-change signals.
Turn Signals
Move the signal lever down (for a left
turn) or up (for a right turn) to the stop
position. The signal will self-cancel after
the turn is completed.
If the indicator light continues to fl ash
after a turn, manually return the lever to its
original position.
Right tur n
Left tur n
Right lane change
Left lane change OFF
The turn signal indicators (green) in the
instrument cluster fl ash according to the
operation of the turn signal lever to show
which signal is working.
NOTE
 y
 If an indicator light stays on without
fl ashing or if it fl ashes abnormally, one
of the turn signal bulbs may be burned
out.
 y A personalized function is available to
change the turn indicator sound volume.
(page 9-10 )
Lane-Change Signals
Move the lever halfway toward the
direction of the lane change—until the
indicator fl ashes— and hold it there. It will
return to the off position when released.
Three-Flash Turn Signal
To signal a lane change, operate the turn
signal lever up or down slightly and
release. After releasing the lever, the turn
signal indicator fl ashes three times.
NOTE
The three-fl ash turn signal function can be
switched to operable/inoperable using the
personalization function.
Refer to Personalization Features on page
9-10 .
.B[EB@%$&""@&EJUJPOJOEC







*Some models.4–42
When Driving
Switches and Controls
Windshield Washer
Pull the lever toward you and hold it to
spray washer fl uid.
Washer
OFF
NOTE
With the wiper lever in the or
intermittent position/
position, the
wipers will operate continuously until the
lever is released.
If the washer does not work, inspect the
fl uid level (page 6-31 ). If the fl uid level
is normal, consult an Authorized Mazda
Dealer.
Rear Window Wiper and
Washer
*
The ignition must be switched ON to use
the wiper.
Rear Window Wiper
Turn the wiper on by turning the rear
wiper/washer switch.
Switch
Position Wiper operation
INT Intermittent ON Normal
Rear Window Washer
To spray washer fl uid, turn the rear wiper/
washer switch to the
position. After the
switch is released, the washer will stop.
If the washer does not work, inspect the
fl uid level (page 6-31 ). If the fl uid level is
normal and the washer still does not work,
consult an Authorized Mazda Dealer.
.B[EB@%$&""@&EJUJPOJOEC







4–45
When Driving
Switches and Controls
Hazard Warning Flasher
The hazard warning lights should always
be used when you stop on or near a
roadway in an emergency.
The hazard warning lights warn other
drivers that your vehicle is a traffi c hazard
and that they must take extreme caution
when near it.
Depress the hazard warning fl asher and
all the turn signals will fl ash. The hazard
warning indicator lights in the instrument
cluster fl ash simultaneously.
NOTE
 y  The turn signals do not work when the
hazard warning lights are on.
 y Check local regulations about the use of
hazard warning lights while the vehicle
is being towed to verify that it is not in
violation of the law.
